Description
Our NPA100DA networked audio zone amplier delivers advanced
audio integration within a commercial or residential AV installation.
The NPA100DA features a 2x 50W digital amplier (1 x 100W mono) or
70V / 100V hi-level constant voltage output, dedicated LFE sub-woofer
output, Dante audio integration and 2ch balanced / unbalanced
audio outputs.
The NPA100DA supports a variety of inputs including 2ch Dante
audio, HDMI ARC, MIC audio with 48V Phantom power support,
optical audio and 2ch balanced / unbalanced analogue audio.
The NPA100DA can be powered via PoE++ from a compatible network
switch, or locally should the switch not support PoE++. The unit also
includes the ability to lower the amplier power output subject to
PoE capabilities, support for combined or independent LAN and
Dante connections, DSP with a 31 band EQ, audio delay for lip sync
correction, independent gain control for audio inputs and control via
front panel, IR, RS-232, TCP/IP, Web Gui or 12V trigger.
NPA100DA
250mm 250mm
Networked Power Amplier with Dante
Blustream cannot be held responsible for errors in typography or photography. Specications are subject to change without notice.
ON OFF
5V 12V
TCP/IP
DANTE PoE
OPT
RS-232 TRG IR IN
HDMI (ARC)
LINE MIC
L+ L
-
-
R
-
R+ +L+ L
- -
R
-
R+ +
LINE
48V
HI-70V
LO-Z HI-100V
SUB
IR
+
-
BRIDGED
AUDIO INPUT AUDIO OUTPUT
CONTROL
SPEAKER OUTPUT
100V COM70V
RXTX T S V
L
-
R
-
R+ L+
MODE 1 MODE 2
NETWORK
36V 5.5A
Networked Power Amplifier with Dante
LOCK DANTE OPT HDMI LINE
+
-
MIC GAIN
VOLUME
-10
0dB
AUDIO INPUT VOLUME
NPA100DA
+10
45mm
Key Features
•
Advanced network audio amplier with Dante Integration
• Supports 2x 50W @ 4 / 8 ohm, 1x 100W @ 4 / 8 ohm or 70 / 100V
constant output for multiple speakers with longer cable runs
• Supports power via PoE++ on Dante LAN connection or Local
power supply*
• Dual network option - Independent Dante and LAN control ports
or combined to a single LAN port
• Audio inputs include:
- 2ch Dante / AES67 audio input
- HDMI ARC with CEC volume control
- MIC audio input with phantom power and auto-ducking
- 2ch Analogue audio input – unbalanced & balanced
- 1x Optical audio input
• Audio outputs include:
- 2ch Dante / AES67 audio output
- 2ch variable/xed analogue output, balanced / unbalanced
- 1x LFE sub-woofer output
• Independent gain control for input channels
• DSP with 31 band EQ with + / -10dB and audio delay
• Local 12V input trigger for automated power control
• Control via front panel, IR, RS-232 and IP
• Auto standby mode with signal sensing
• In-built web gui for setup and control
*Amp power limited when using PoE++ or PoE+
