Side 1/2

Description

The SAH5 (5-watt), SAH15 (15-watt), and SAH30 (30-watt) horn loudspeakers incorporate digital switching amplifier technology, which provides

low DC current draw and low heat dissipation.This in turn makes the loudspeakers more tolerant of long cable runs and allows them to run

cooler, withstand higher ambient temperatures, and use fewer power supplies than conventional analog self-amplified horn loudspeakers.

The flared shape of the horn provides a controlled and consistent dispersion of sound, making for better intelligibility.The horn flare can rotate on its

axis, offering wider dispersion patterns, vertically or horizontally, depending on its position. The horn typically offers 120º horizontal dispersion and

90º vertical dispersion. By rotating the horn 90º on its axis, a 90º horizontal and 20º vertical dispersion pattern is achieved.1

Installation Instructions

1. Use the base as a template for the mounting holes. Drill three mounting holes and attach the

base using appropriate hardware (not included).

IMPORTANT: Make sure the base sits flat on the mounting surface.Tightening the base down on an

uneven surface could cause the base to fracture.

An electrical box strap is included to allow easy mounting of the horn to an electrical box and

cover. (See separate instruction sheet included.) The base can also be mounted to an I-beam

flange using Bogen's BC beam clamp. The slot in the base allows strapping to be used as a1

means of mounting the horn (use a strapping material capable of supporting the weight of the

speaker and any external loads on the horn such as wind). See Figure 1.

2. Assemble the horn on the mounting base and slide the tapered pin through the hole in the

swivel mount. Secure the pin and assembly using the wing nut, but leave loose to allow

positioning of the horn (See Figure 2).

3. Position the horn so that the access cover is easily accessible. Make the audio connections to

the "T" and "R" terminals and the 24V DC connections to the "+" and "-" terminals.The horn

will also work properly if the "+" and "-" connections are reversed.

4. Adjust the output level of the horn using the volume control knob and position the wires so

that they exit through the bump in the front of the cover. Slide the cover into place and

tighten the cover screw. Do not over tighten.

5. Tilt and swivel the horn to the desired orientation before tightening the wing nut*. If necessary,

the horn flare can be rotated on its axis by loosening the band clamp wing nut, rotating the flare

to the desired position, and retightening the band clamp wing nut* (See Figure 3).The horn will

provide a wider horizontal angle of dispersion ( 20º) when its wider dimension is horizontal and1

a narrower horizontal dispersion angle (90º) when its narrow dimension is horizontal.

IMPORTANT: The horn is designed to be weatherproof only when the bump on the access cover is on

a downward slope.The access cover is not sealed and is designed to shed water.This downward position

assures that any water that enters the covered area will drain away. Depending on how it is mounted, the

horn flare may need to be rotated to achieve this orientation.The rest of the horn is fully sealed against

water infiltration.

*Hand tighten wing nuts. Do not use pliers or tools.

Package Contents:

SAH5, SAH15, or SAH30 horn speaker Access Cover

Mounting Base Electrical Box Strap

Tapered Pin Instruction Sheet

Wing Nut Electrical Box Strap Mounting Instruction Sheet

Specifications subject to change without notice.

54-2 4-011 1C 0608

Figure .1Mounting Base

Figure 2

Figure 3

BC1Beam Clamp (optional accessory)

SAH5, SAH 5, SAH301

High-Efficiency, Digital Switching,

Self-Amplified Horn Loudspeakers

www.bogen.com

The SAH5, SAH 5, and SAH30 are warranted to be free from defects in material or workmanship for two (2) years from the date of sale1

to the original purchaser.Any part of the product covered by this warranty that, with normal installation and use, becomes defective will

be repaired or replaced by Bogen, at our option, provided the product is shipped insured and prepaid to: Bogen Factory Service

Department, 50 Spring Street, Ramsey, NJ 07446, USA.The product will be returned to you freight prepaid.This warranty does not extend

to any of our products that have been subjected to abuse, misuse, improper storage, neglect, accident, improper installation or have been

modified or repaired or altered in any manner whatsoever, or where the serial number or date code has been removed or defaced.

THE FOREGOING LIMITED WARRANTY IS BOGEN'S SOLE AND EXCLUSIVE WARRANTY AND THE PURCHAS-

ER'S SOLE AND EXCLUSIVE REMEDY. BOGEN MAKES NO OTHER WARRANTIES OF ANY KIND, EITHER

EXPRESS OR IMPLIED,AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICU-

LAR PURPOSE ARE HEREBY DISCLAIMED AND EXCLUDED TO THE MAXIMUM EXTENT ALLOWABLE BY LAW.

Bogen's liability arising out of the manufacture, sale or supplying of products or their use or disposition, whether based upon warranty,

contract, tort or otherwise, shall be limited to the price of the product. In no event shall Bogen be liable for special, incidental or conse-

quential damages (including, but not limited to, loss of profits, loss of data or loss of use damages) arising out of the manufacture, sale or

supplying of products, even if Bogen has been advised of the possibility of such damages or losses. Some States do not allow the exclu-

sion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.This warranty gives

you specific legal rights, and you may also have other rights which vary from State to State.

Products that are out of warranty will also be repaired by the Bogen Factory Service Department -- same address as above or call 201-

934-8500. The parts and labor involved in these repairs are warranted for 90 days when repaired by the Bogen Factory Service

Department. All shipping charges in addition to parts and labor charges will be at the owner's expense. All returns require a Return

Authorization number.

08/ 0/20041

Limited Warranty

Technical

Specifications

SAH5 SAH 5 SAH301

Typical Current Consumption: 4 CU (200 mA) 9 CU (450 mA) 7 CU (850 mA)1

Power Supply Voltage (nominal) 24V DC 24V DC 24V DC

Max. Power Rating: 5W 15W 30W

Max. Sound Level: 9 dBspl 24 dBspl 27 dBspl11 1 1

Input Sensitivity: 25 mVrms 25 mVrms 25 mVrms1 1 1

Frequency Response: 275 Hz - 4 kHz 275 Hz - 4 kHz 275 Hz - 4 kHz1 1 1

Input Impedance: 2k ohms 2k ohms 2k ohms

Dispersion: 120° x 90º 120° x 90º 120° x 90º

Dimensions (W x H x D): 10-5/8" x 2" x 1 11-1/2" 0-15/8" x 2" x 1 11-1/2" 0-15/8" x 2" x 1 11-1/2"

Weight: 6 lb. 6 lb. 6 lb.
