new d

Extractor hood

DFM06… DFL06… DFL09…

[en]

User manual and installation instructions

en Safety

Table of contents

INFORMATION FOR USE

1 Safety....................................................................2

2 Avoiding material damage...................................4

3 Environmental protection and saving en-

ergy .......................................................................4

4 Operating modes .................................................5

5 Familiarising yourself with your appliance ........6

6 Basic operation ....................................................6

7 Cleaning and servicing........................................7

8 Troubleshooting...................................................8

9 Customer Service.................................................9

10 Accessories..........................................................9

11 Disposal................................................................9

12 INSTALLATION INSTRUCTIONS .......................10

12.3 Secure installation ..........................................

...10

1 Safety

Observe the following safety instructions.

1.1 General information

¡Read this instruction manual carefully.

¡Keep the instruction manual and the

product information safe for future refer-

ence or for the next owner.

¡Do not connect the appliance if it has been

damaged in transit.

1.2 Intended use

Only use this appliance:

¡For extracting cooking vapour.

¡In private households and in enclosed

spaces in a domestic environment.

¡Up to an altitude of max. 2000m above

sea level.

Do not use the appliance:

¡With an external timer.

1.3 Restriction on user group

This appliance may be used by children aged

8 or over and by people who have reduced

physical, sensory or mental abilities or inad-

equate experience and/or knowledge,

provided that they are supervised or have

been instructed on how to use the appliance

safely and have understood the resulting

dangers.

Do not let children play with the appliance.

Children must not perform cleaning or user

maintenance unless they are at least 15 years

old and are being supervised.

Keep children under the age of 8 years away

from the appliance and power cable.

1.4 Safe use

WARNING‒Risk of suffocation!

Children may put packaging material over

their heads or wrap themselves up in it and

suffocate.

▶Keep packaging material away from chil-

dren.

▶Do not let children play with packaging ma-

terial.

Children may breathe in or swallow small

parts, causing them to suffocate.

▶Keep small parts away from children.

▶Do not let children play with small parts.

WARNING‒Risk of poisoning!

Risk of poisoning from flue gases being

drawn back in. Room-air-dependent heat-pro-

ducing appliances (e.g. gas, oil, wood or coal-

operated heaters, continuous flow heaters or

water heaters) obtain combustion air from the

room in which they are installed and dis-

charge the exhaust gases into the open

through an exhaust gas system (e.g. a chim-

ney). With the extractor hood switched on, air

is extracted from the kitchen and the adjacent

rooms. Without an adequate supply of air, the

air pressure falls below atmospheric pressure.

Toxic gases from the flue or the extraction

shaft are sucked back into the living space.

▶Always ensure adequate fresh air in the

room if the appliance is being operated in

exhaust air mode at the same time as a

room-air-dependent heat-producing appli-

ance is being operated.

▶It is only possible to safely operate the ap-

pliance if the pressure in the room in which

Produkt Specifikationer

Mærke:	Bosch
Kategori:	Emhætter
Model:	DFM063W56B
Type:	Semi indbygget (træk ud)
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	598 mm
Dybde:	290 mm
Vægt:	8700 g
Produktfarve:	Sølv
Kontroltype:	Knapper
Antal hastigheder:	2
Indbygget skærm:	Ingen
Strøm:	10 A
Ledningslængde:	1.75 m
Årligt energiforbrug:	41.1 kWh
Husmateriale:	Metal
Installationsrum bredde:	526 mm
Installationsrum dybde:	290 mm
Installationsrum højde:	162 mm
Tilsluttet belastning:	93 W
Lampetype:	LED
Støjniveau:	64 dB
Energieffektivitetsskala:	A+++ til D
Vaskbart filter:	Ja
Pæreeffekt:	1.5 W
Farvetemperatur:	3500 K
Antal lyskilder:	2 pære(r )
Maksimal ekstraktionseffekt:	328 m³/t
Udsugningsforbindelse, diameter:	150 mm
Motor inkluderet:	Ja
Fedtfilter type:	Aluminium
Aftageligt filter:	Ja
Ekstraktionstype:	Aftræk/Recirkulerende
Belysningsstyrke:	131 Lux
Højde (maks.):	203 mm
Væske - dynamisk effektivitetsklasse:	D
Lys - effektivitetsklasse:	A
Fedt - filtrering effektivitetsklasse:	C
Belysningsposition:	Tilbage
Antal filtre:	2 stk
Maksimal recirkulerende effekt:	231 m³/t
Minimum afstand fra elektrisk komfur:	430 mm
Minimum afstand fra gaskomfur:	650 mm
