Side 1/6
CCTV | KBN and KBE Series Prepackaged Cameras
The KBN and KBE Series Prepackaged Cameras are
complete surveillance systems that include a camera and
lens installed and pre-wired into a Bosch housing which
includes a feed-through wall-mount.
All packages feature Bosch’s signature line of Dinion,
DinionXF, or Dinion 2X cameras. Each package offers
choices of a varifocal lens to fit a wide range of surveillance
applications. Outdoor models are enclosed in a Bosch
housing with an IP66 enclosure rating.
The Dinion Series cameras deliver unsurpassed pictures
under even the most difficult light and scene conditions.
The 20-bit digital signal processing found in the Dinion 2X
Day/Night camera series enhances sensitivity; the 2X
Dynamic extends the dynamic range. This unique
combination provides a sharper, more detailed image with
outstanding accuracy in color reproduction even under
harsh light conditions.
Dinion IP network cameras are designed to ensure the
highest possible image quality at all times, providing DVD-
like, high-quality MPEG-4 video, at up to 30 images per
second. Dinion IP is a true hybrid camera with both Ethernet
and BNC connections for network and analog video.
Each camera is equipped with Bosch’s innovative Bilinx bi-
directional communication for remote programming. Bilinx
uses standard video cable to transmit alarm and status
messages, providing superior performance and simplified
installation.
The true advantage of the Bosch prepackaged cameras lie
with the plug-and-play design. Installation is quick and easy,
since these units include a factory-installed camera and lens
with adjusted back-focus - all of which are pre-wired
through the housing base. Coax and power cable (1 1/2 m
or 5 ft) are fed through the included mount to the
connection point.
Camera packages are also available with transmitters for
sending video signals over fiber optic or unshielded twisted
pair (UTP) cable.
Everything about the KBN and KBE Series Prepackaged
Cameras, from the installer-friendly design, coupled with
the Dinion, DinionXF or the Dinion 2X Series Cameras and a
wide range of options make the KBN and KBE Series
Prepackaged cameras an ideal solution for every
surveillance requirement.
KBN and KBE Series Prepackaged Cameras
▶General purpose, high performance, and Day/Night
cameras
▶Network and analog cameras
▶Various lens options available
▶Bilinx bi-directional communication
▶Indoor or outdoor versions (Outdoor IP66 enclosure
rating)
▶Camera and lens are pre-wired into a Bosch housing
▶Plug and Play design includes feed through mount and
1.5 m (5 ft) of cabling
▶Coax, Fiber, UTP, and IP outputs
www.boschsecurity.com
2 | KBN and KBE Series Prepackaged Cameras
Certifications and Approvals
Electro Magnetic Compatibility
Emission EN55022 class B, FCC part 15 class B, EN6100-3,
EN50121-4
Immunity EN50130-4 (CE), EN50121-4 (CE)
Vibration Camera with 500 gr (1.1 lbs) lens according
to IEC60068-2-6
Safety
LTC0498/11: UL1950-1, CSA 22.2 No. 950-1, EN60950-1 (CE),
UL60950, CAN/CSA No. 60950
LTC0498/51: UL1950-1, CSA 22.2 No. 950-1, EN60950-1 (CE),
EN61000-3-2 2000 +A2:2005,
EN61000-3-3 1995 +A1:2001 +A2:2005
LTC0498/21 and LTC0498/61: UL1950-1, CSA 22.2 No. 950-1,
EN60950-1 (CE), UL60950, CAN/CSA No. 60950
Installation/Configuration Notes
Figure 1: Indoor Models
8.9
0.35
88.9
3.50
mm
in
306.8
12.08
23.9
0.94
25.4
1.00
12.7
0.50
6.9
0.27
74.7
2.94
37.3
1.47
88.9
3.50
73.2
2.88
7.9
0.31
138.3
5.45
Figure 2: Indoor Mount
Figure: 3 Outdoor Models
88.9
3.50
8.9
0.35
mm
in
179.8
7.08
138.3
5.45
23.9
0.94
25.4
1.00
12.7
0.50
6.9
0.27
74.7
2.94
37.3
1.47
7.9
0.31
73.2
2.88
88.9
3.50
Figure 4: Outdoor Mount
Ordering Guide
Use the following charts to create your order numbers.
Sample: KBE-498V75-20
KBE Prepackaged Outdoor Model
498 1/3 in. High Resolution Day/Night
V75 7.5–50 mm Varifocal Lens
20 24 VAC
6
V41
V14
30
KBE
U
F
10 - 40 mm
4 - 12 mm
20
UTP Transmitter
Fiber Transmitter
1, 3
1, 2
1/2-inch Day/Night High Resolution Prepackaged Cameras
