2
Getting Ready ........................................... 3
Connecting the Equipment ............................... 3
Turning the Power On/O ................................. 3
Auto O Function ........................................ 3
Panel Descriptions ........................................ 5
Selecting the Instrument (Guitar/Bass) to Use (MODE
SETTING) ................................................. 6
Specifying the Device Connected to OUTPUT Jacks (OUTPUT
SELECT) .................................................. 6
Making Pickup Settings (GK SETTING) ..................... 7
Specifying the Pickup Type ............................... 7
Specifying Your Guitar’s (Bass’s) Scale Length .............. 8
Specifying the Pickup Position (Bass Mode Only) ........... 8
Specifying the Distance from the Bridge ................... 9
Adjusting the Pickup Sensitivity. . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Tuning the Guitar (TUNER) ................................ 9
Making Tuner Settings ................................... 9
Basic Operation ......................................... 10
Display (Play Screen) ...................................... 10
About the Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Screen Operations ........................................ 11
Operating Example 1 (INST Screen) ....................... 11
Operating Example 2 (INST Edit Screen) ................... 11
Operating Example 3 (EFFECT Edit Screen) ................. 11
Switching Patches (Tone) ............................... 12
The Structure and Patches of the SY-1000. . . . . . . . . . . . . . . . . . 12
Types of Bank ............................................ 12
Types of Patch ........................................... 12
Selecting a Patch ......................................... 12
Editing a Patch .......................................... 13
Changing the INST ........................................ 13
Editing the INST .......................................... 13
Viewing All Parameters While You Edit ..................... 13
Saving the Edited INST Settings (VARIATION) .............. 14
Recalled a Saved INST Variation ........................... 14
Editing the Eects ........................................ 15
Basic Operation for Eect Editing ......................... 15
Editing While Viewing All Parameters ...................... 15
Changing the Eect Order ................................ 15
Saving the Edited Eect Settings (VARIATION) ............. 16
Recalled a Saved Eect Variation .......................... 16
Assigning Functions to the Foot Switches and Expression
Pedal ..................................................... 17
Making Assignments from the Eect Edit Screen (Quick
Assign) .................................................. 17
Saving a Patch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Settings for the Entire SY-1000 (System Parameters) ... 19
Settings for the SY-1000 .................................. 19
Restoring the Factory Default Settings (Factory Reset) ...... 19
Turning O the Auto O Function ......................... 19
Main Specications ..................................... 20
USING THE UNIT SAFELY ................................ 21
IMPORTANT NOTES ..................................... 21
Contents
