PS165 & PS330 User Manual Issue AA
General Information
Congratulations on the purchase of your new PS scale. Please read this guide to become familiar with the operation of
this product. Save this guide for future reference.
• Do not put excess weight or drop items on the scale. This could damage the weighing mechanism and or
• affect the scale accuracy.
• Do not use or store the scale in a high temperature, high humidity or high vibration area.
• The batteries should be replaced when the low voltage is indicated.
• Use a mild soap solution with a cloth to clean the scale, by spraying the cloth and wiping the scale.
• Do not use any harsh chemical cleaner.
• Do not wash down or immerse the scale in any way as this would cause permanent damage.
Specifications
• Weighing Platform: 390 x 310mm stainless steel
• Indicator: Rugged ABS housing, LCD display with backlit
• Maximum Capacity:
• Division: 0.1 lb / 0.05 kg, 0.2 lb / 0.1 kg
• Weighing Unit: kg, lb, lb:oz
• Operation keys: ON/OFF/ZERO, UNIT, COUNT, TARE
• Power: A/C adapter; Output 6vdc, 500ma (included)
• 4x AA batteries (not included)
• Auto off Time:5 Minutes or disable the function. Default setting is 5 minutes
• Overload Indication: overload
Basic Operations
Battery Installation and Power Supply
The scale can be powered by using the supplied external power supply or by installing 4 AA batteries (not included) into
the battery compartments on the rear of the indicator. If using batteries, be sure to observe battery polarity before
installing.
Power on
Place the scale on a hard, flat and level surface. Use a short press of the ON/OFF/ZERO key to power on the scale.
The display will show 88888, then show 0.00kg for BPS75 and 0.0kg for BPS150 a few seconds later, the scale will now
be ready to use.
Power off
Press and hold the ON/OFF/ZERO key to power the scale off. The scale is set to automatically power off after 5 minutes
if the scale is not in use. To disable this function…
1. Press and hold the TARE key, until 300 is displayed.
2. Press the TARE key again and NOOFF will be displayed.
3. Press the UNIT key to return to normal weighing mode.
The scale will now remain on until manually powered off.
