Connection help

Don’t know if you’re connecting via router or extender?

• The easiest way is to compare the signal strength displayed on your device with the

extender switched on and off. The extender simply relays the data from your hub/router.

It’s your device that controls which signal it connects to.

Can’t connect extender to router

• If the range lights continue to scroll back and forth for more than 1 minute after

connection attempt. Check your hub/router is switched on and try moving your

extender closer to it.

• If your device often loses internet access and the extender’s Too far or a bit too far light

is on, try moving the extender to another socket.

• If you are trying to use WPS but it doesn’t work (Too far Too close and (red) lights

continue to ﬂash), it may be that it’s incompatible with the WPS function in the extender.

Try switching the extender Off then On and repeat Method 1. If it still fails, follow the

steps in Method 2, to connect without using the WPS button.

• If you’re unable to connect using Method 2, check you have selected the correct

wireless network and you’ve entered the correct wireless key.

Can’t connect to internet

• Check your router is connected to the internet and your wi-ﬁ is working correctly.

Can’t connect your device to wireless

• Make sure your device is correctly set-up to connect to your hub/router before trying

to use the extender.

• Microwaves and some electrical equipment may interfere with the wireless signal.

• Check the lights on your extender and make sure you are in Good range, if not see the

section ‘Move extender to optimum location’.

• Thick/concrete walls and ceilings will affect wireless performance.

All lights are off

• Check the power socket is working and switched on.

• Check the extender is turned on (the button is on the top).On/Off

Light status

Light Status What’s happening

Power On Extender running normally

Off Extender turned off

Red

Flashing

Extender not conﬁgured to connect to hub/router

Go to step

Red/

Blue

Scrolling

Extender connecting to hub/router

If scrolling for more than 1 min, check your hub/

router is switched on and try moving your extender

closer to it

WPS On WPS connection successful (goes off after

30 seconds)

Flashing Authentication in progress or faster ﬂashing

indicates connection error

Off No WPS session in progress

Ofﬁces worldwide

The services described in this publication are subject to availability and may be modiﬁed from time to time.

Services and equipment are supplied subject to British Telecommunications plc’s respective standard conditions of contract.

Nothing in this publication forms any part of a contract.

Registered in England No. 1800000.

Designed and produced by The Art & Design Partnership Ltd.

Printed in China / Issue 3 / ADP10-14

Extender default settings

General information

For information on safety instructions,

technical information or setting up the

extender, please see the Frequently

Asked Questions at bt.com/producthelp

Guarantee

Your Dual-Band Wi-Fi Extender 1200 is guaranteed for

a period of 3 years from the date of purchase. Subject

to the terms listed below, the guarantee will provide

for the repair of, or at BT’s or its agent’s discretion, the

option to replace the Dual-Band Wi-Fi Extender 1200

or any component thereof which is identiﬁed as faulty or

below standard, or as a result of inferior workmanship or

materials. Products over 28 days old from the date

of purchase may be replaced with a refurbished or

repaired product.

The conditions of this guarantee are:

• the guarantee shall only apply to defects that

occur within the 3 year guarantee period

• proof of purchase is required

• the equipment is returned to BT or its agent

as instructed.

This guarantee does not cover any faults or defects

caused by accidents, misuse, fair wear and tear, neglect,

tampering with the equipment, or any attempt at

adjustment or repair other than through approved agents.

This guarantee does not affect your statutory rights.

To ﬁnd out what to do if your extender is in or

outside of the 3 year guarantee, please see the FAQ

at bt.com/producthelp

Find out more

• If you need more help, go to bt.com/producthelp where you can view

Frequently Asked Questions.

• If you cannot ﬁnd the answer to your problem in the Frequently

Asked Questions, then please call our free Helpline on *. 0808 100 6116

Our dedicated advisors are more likely to be able to help you than the

retailer where you made your purchase.

* Calls made from within the UK mainland network are free. Mobile and international call costs may vary.

Dual-Band Wi-Fi Extender 1200

User Guide

Box contents

Dual-Band Wi-Fi

Extender 1200

Ethernet cable

How to recycle your equipment

The symbol shown here and on the product

means that the product is classed as electrical

or electronic equipment, so DO NOT put it in your

normal rubbish bin.

It’s all part of the Waste Electrical and Electronic Equipment

(WEEE) Directive to recycle products in the best way – to be

kinder to the planet, get rid of dangerous things more safely

and bury less rubbish in the ground.

You should contact your retailer or supplier for advice

on how to dispose of this product in an environmentally

friendly way.

R&TTE Directive & Declaration of Conformity

This equipment complies with the essential requirements

for the Radio Equipment and Telecommunications Terminal

Equipment Directive (1999/5/EC).

For a copy of the Declaration of Conformity

please refer to bt.com/producthelp

This product uses open source codes available

from bt.com/help/gplcode

Turn over for set-upTurn over for set-up

Reset to factory settings

If you need to access advanced settings, have

forgotten your password or if the extender stops

working you can reset it to its factory settings.

1 Make sure the extender is plugged

in and switched on.

2 Press the Reset button for 1 second

to restore factory default settings.

Using the ethernet cable

You can connect an additional device to the ethernet port that will use the wi-ﬁ extension

at the same time as your wireless devices.

Connect your device to the extender’s ethernet port using an ethernet cable.

Reset button

The band switch

This switch sets the frequency band your extender uses to connect to the hub/router.

By default your extender uses the 2.4GHz band for maximum range and compatibility.

If you have a dual-band hub/router (e.g. BT Home Hub 4 or 5), selecting the 5GHz

band may improve performance (speed) as there is less wireless congestion.

To change to the 5GHz band, unplug the

extender, move the band switch to the

5 position and go to step

Method 2 -

Without WPS button.

Selecting the 5GHz band may reduce the range and you

will need to move the extender closer to your hub/router.

2.4GHz

Range

5GHz

Performance

Method 1 - Using WPS button

Connection to your router is very easy if it supports WPS; most recent routers do

(e.g. BT Home Hub 3 and later, or any other router that has a WPS button). If your router

doesn’t support WPS or this method fails, go to ‘Method 2 - Without WPS button’ opposite.

1 Plug the extender into a power socket near your broadband wireless router

(e.g. in the same room). Check the extender button on the top is switched on. On/Off

Wait 20 seconds for the extender to boot up. The light will be steady blue and Power

the Too close Too far and red lights will be ﬂashing together.

2 Press the button on your router.WPS

3 Press the button on the extender (for 1 second) within 2 minutes.WPS

4 Wait until the light stops ﬂashing and one of the range lights is solid. The extender WPS

is now conﬁgured with your hub/router, and you’re ready to ﬁnd its optimum location,

see

below.

If this fails (WPS light stops ﬂashing and the Too far Too close and red

lights continue to ﬂash), please use ‘Method 2 - Without WPS button’ opposite.

Note: the WPS button on your extender is only used to connect to the router and can’t

be used to connect devices.

Method 2 - Without WPS button

If you don’t have a WPS button on your hub/router, you can set up your extender

using the web based set-up with an internet browser.

Important: Before following these instructions, make sure your computer is

not connected to the internet (unplug its ethernet cable or disconnect from

your wi-ﬁ network).

1 Plug the extender into a power socket near your broadband wireless router

(e.g. in the same room). Check the extender button on the top is switched On/Off

on. Wait 20 seconds for the extender to boot up. The light will be steady Power

blue and the Too close Too far and red lights will be ﬂashing together.

2 Connect your computer to the extender using option A or B below:

Option A - Connect wirelessly

- Use the wireless connection software or settings on your computer to display

the list of available wireless networks in your area.

- Find your extender in the list and select it; it’s called .BTWiﬁExt1200-XXX

- Enter your extender’s wireless key (printed on the back of this guide).

- Complete the connection on your computer.

Option B - Connect using the ethernet cable

- Insert the ethernet cable into the extender and the other end into

your computer.

3 Open your internet browser and enter in the address ﬁeld.http://192.168.1.1

- Enter your extender’s (printed on the back of this guide), Admin password

then click .Login

- Click at the bottom then follow the on-screen connection wizard.Start

4 When you click your browser will lose connection to the extender Finish

(ignore browser errors). The extender’s range indicator light will stop ﬂashing

on successful connection. The extender is now conﬁgured with your hub/router,

and you’re ready to ﬁnd its optimum location, see

below.

Full instructions on how to connect devices using different operating systems

are in the Frequently Asked Questions, available at .bt.com/producthelp

1 Plug in the extender halfway between your hub/router and the area you wish to

extend wi-ﬁ to.

2 Give the extender 20 seconds to boot up, then the range lights will scroll back and forth

while it searches and connects to your router. After about 30 seconds, the ﬂashing

will stop and the signal quality will be shown. Ideally the light will become Good range

solid blue and you can go to point 5.

If the range lights continue to scroll back and forth for more than 1 minute.

Check your hub/router is switched on and try moving your extender closer to it.

3 Check the lights and if necessary move the extender closer or further away

from your hub/router depending on the light status below. Then check the

light status again. A range light will be steady blue or red.

The extender gives you two new wireless networks, one on the 2.4GHz band and

one on the 5GHz band.

The 5GHz band will give the best performance when close to the extender, (EXT5)

the 2.4GHz band is best for range.(EXT2)

1 The extender’s network name is the same as your hub/router with

EXT2 EXT5- (2.4GHz band) and - (5GHz band) added to the front.

For example:

Hub/router wireless network name: BTHub5-1234

New extended network names: and EXT2- BTHub5-1234 EXT5- BTHub5-1234

2 From your device, select the network you wish to connect to.

3 Enter the wireless key – this is the same as your hub/router.

2 Move extender to optimum location Connect your devices3

Too close (red)

Move the extender further from the hub and

closer to the area you want to receive wi-ﬁ.

A bit too close (blue)

The extender will work but there’s less

wi-ﬁ extension.

Good range (blue)

Good router signal strength. Ideal location for

maximum performance.

A bit too far (blue)

The extender will work but a bit too far from

your hub/router for best performance.

Too far (red) or scrolling back and forth

for more than 1min

Move the extender closer to your hub/router.

It’s normal for the range lights to change occasionally. This is because wireless

signals can vary due to other factors e.g. electrical appliances/devices.

1 Connect to your hub/router

Produkt Specifikationer

Mærke:	British Telecom
Kategori:	Wifi repeater
Model:	Dual-Band Wi-Fi Extender 1200
Type:	Netværksgentager
Vekselstrømsindgangsspænding:	230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	120 mm
Dybde:	70 mm
Højde:	75 mm
Vægt:	179 g
Brugervejledning:	Ja
Produktfarve:	Hvid
Wi-Fi:	Ja
Relativ luftfugtighed ved opbevaring (H-H):	10 - 90 %
Ethernet LAN-porte (RJ-45):	1
Wi-Fi-standarder:	802.11a, 802.11b, 802.11g
Strømforbrug (typisk):	12 W
Driftstemperatur (T-T):	0 - 40 °C
Sikkerhedsalgoritmer:	WPA, WPA2
Kabler inkluderet:	LAN (RJ-45)
Maksimal overførselsafstand:	- m
