2 Navigating the menus

All your phone’s functions and settings can be accessed through the main menu on

the handset. The menu map below shows all the menu options you can choose from.

1. Press

to enter the main menu.

2. Use the

and buttons to scroll through the available options (when you reach the

end of the list, the ﬁrst option is displayed again). Press

to select an option, or press

to return to the previous menu.

To exit a menu and return to standby press

repeatedly.

Menu map

You can also access the phonebook directly by pressing the button.

3 Making and receiving calls

Make/end a call

1. Press . When you hear the dial tone, dial the number. To end the call, press , or

replace the handset on the base or charger.

Handsfree

Press

to switch the call between the earpiece and the loudspeaker.

Earpiece/handsfree volume

During a call, use and to adjust the volume of the caller’s voice.

Secrecy

You can mute the handset microphone and talk without your caller hearing you.

1. During a call, press .

MUTE

is displayed and your caller cannot hear you. Press

again to resume your call.

Receiving calls

When you receive a call, the phone will ring and

CALL

and the icon will ﬂash in the display.

1. To answer the call press . Or if the handset is on the base or charger, simply lift it to

answer the call.

Redial

The last 10 numbers dialled are stored in the redial list.

1. Press

to open the redial list, the most recently dialled number is displayed. Press

or to scroll through the list.

2. Press

to redial the number, or press to access further options such as delete

numbers from the list or copy numbers to the phonebook.

4 Special features

Your BT Graphite 1100 has some special features, these include a handsfree facility (see

above), 10 number redial (see above), a 50 number phonebook, a calls list and Call Waiting.

Phonebook

You can store up to 50 names and numbers in the phonebook to make dialling quick and easy.

For multi-pack users, each handset has its own phonebook.

Store a new phonebook entry

1. From the standby screen, press

PHONEBOOK

is displayed, press again.

2. If there are already entries stored in the phonebook the ﬁrst entry will be displayed and

you will need to press

again. Otherwise, the display shows

ADD ENTRY

. Press .

3. The display shows

ADD NAME

. Using the letters on the keypad, enter the name.

You may need to press the same button a few times until the letter you want is displayed.

For example, press

2 once for

,or twice for

. Press .

4. The display shows

ADD NUMBER

. Enter the phone number and press to conﬁrm.

Dial a phonebook entry

1. Press

. The ﬁrst entry is displayed.

2. Press and to scroll through the list. When the entry you want to dial is displayed,

you can switch between the name and number by pressing

3. Press to dial the entry displayed or press to return to standby.

1 Getting started

Place your BT Graphite 1100 close enough to a mains power and telephone socket so that

the cables will reach. Make sure it is at least 1 metre away from other electrical appliances

to avoid interference.

Your BT Graphite 1100 works by sending radio signals between the handset and the base.

The strength of the handset signal depends on where you site the base. Putting it as high as

possible can help provide the best signal.

The handset range is up to 300m outdoors and 50m indoors (in ideal conditions). The

icon

in the handset display will ﬂash and you hear a warning beep when you go out of range.

Setting up

1. Plug the mains power adaptor and telephone cables into the back of the base. Only use

the cables provided with the product.

2. Plug the power adaptor into the wall socket and switch the power on – the base will beep.

3. Insert the two batteries supplied into the handset, observing the polarity markings inside

the battery compartment, and slide the compartment cover shut.

4. Place the handset on the base to charge. The handset will beep and the battery icon

will ﬂash in the display to indicate charging. Charge the handset for at least 24 hours

5. Once fully charged, plug the telephone line cord into the telephone wall socket.

Set up your additional handsets (2, 3 and 4-Pack owners only)

For each additional handset and charger:

1. Plug the mains power adaptor into the back of the charger and plug the other end into

the wall socket and switch the power on.

2. Insert the two batteries supplied into the battery compartment and slide the

compartment cover shut.

3. Place the handset on the charger to charge. The handset will beep and the battery icon

will ﬂash in the display to indicate charging. Charge the handset for at least 24 hours

Additional handsets supplied as part of a multipack are pre-registered to the base so, once

charged, are ready for use. Each handset will display its own handset number: 1, 2, 3 and so on.

Your BT Graphite 1100 is now ready for use.

Welcome

This Quick Start Guide provides all the information

you need to get your product up and running.

Please fully unfold this guide and follow the numbered

steps below. If you need more detailed instructions,

a full user guide is available to download in PDF format

from www.bt.com/help/userguides

We haven’t printed a full user guide as we’re working to make our

products greener, so please consider the environment before printing.

If you cannot ﬁnd the answer to your problem in the full online

user guide, then please call the on Helpline 0870 242 6652

* Calls provided by BT will be charged at up to 8 pence per minute. A Call

Set-Up Fee of up to 6 pence per call applies to calls from Residential

lines. Prices correct at time of going to press. See www.bt.com/pricing

for details. Mobile and other providers’ costs may vary.

Telephone

line cord

Mains power

adaptor

PHONEBOOK

(Menu only appears when

phonebook is empty. With

entries stored, press

again to enter the menu).

ADD ENTRY

MODIFY ENTRY

DELETE ENTRY

DELETE ALL

CLOCK /ALARM

DATE / TIME

ALARM

ALARM TONE

SETTINGS

HANDSET TONE

HANDSET NAME

AUTO ANSWER

BASE TONES

ADVANCED SET

REGISTRATION

DE-REGISTER

PIN CODE

PHONE RESET

Quick Start Guide

Ofﬁces worldwide

The services described in this publication are subject to availability and made be

modiﬁed from time to time. Services and equipment are supplied subject to British

Telecommunication’s plc’s respective standard conditions of contract. Nothing in

this publication forms any part of a contract.

Registered Ofﬁce: 81 Newgate Street, London EC1A 7AJ.

Registered in England No. 1800000.

Designed and produced by The Art & Design Partnership Ltd.

Printed in China / Issue 1 / ADP11-07

Caller Display and the calls list

You must subscribe to a Caller Display service for this feature to work. Your network provider

may charge you for this service.

Caller Display lets you see the number of the person calling you before you answer the phone.

The calls list holds details of your last 40 callers, including the phone number, date and time

of the call. If a number matches a stored directory entry, the caller’s name is displayed instead.

When you have new missed calls the

icon will be displayed on the handset.

View and dial from the calls list

1. From standby, press

to open the calls list. Press or to scroll through the entries.

From within the calls list:

Press

repeatedly to view details of the call: caller’s number, time and date.

Press to dial the entry displayed.

Press to access further options such as delete numbers from the list or copy

numbers to the phonebook.

Call Waiting

You must subscribe to a Call Waiting service for this feature to work. Your network provider

may charge you for this service.

With Call Waiting, during a call, if another caller is trying to reach you, you will hear a

soft beep every 5 seconds. Instead of the engaged tone, the second caller will hear an

announcement to hold as you are aware that they are waiting.

If you have also subscribed to a Caller Display service, the caller’s number (or name if stored

in the phonebook) will be shown on the display for 20 seconds, after this time the display

will return to your ﬁrst caller’s details.

To speak to the second caller

1. Press

to answer the second call and put your current caller on hold. Press to

switch between both callers.

Or, press

to end the current call. The handset will then ring. Press to connect to

the waiting caller.

Other functions

Your BT Graphite 1100 has a number of other features, including: switching your handset

on and off, switching the keypad lock on and off and paging the handset so you can locate

it or alert a handset user that they are wanted.

If you have bought a multiple pack and therefore have more than one handset registered

to your base, you can: make internal calls, transfer an external call from one handset to

another, hold a conference call and make an internal call between two handsets while a

third is on an external call.

For a full explanation of features and instructions, please see the main

user guide online at www.bt.com/help/userguides

For information on safety instructions,

cleaning, technical information or

connecting to a switchboard, please refer to

the ‘General Information’ section in the full

user guide at www.bt.com/help/userguides

Guarantee

Your BT Graphite 1100 is guaranteed for a period of

12 months from the date of purchase.

Subject to the terms listed below, the guarantee

will provide for the repair of, or at BT’s or its agent’s

discretion the option to replace the BT Graphite

1100, or any component thereof, (other than

batteries), which is identiﬁed as faulty or below

standard, or as a result of inferior workmanship or

materials. Products over 28 days old from the date

of purchase may be replaced with a refurbished or

repaired product.

The conditions of this guarantee are:

• The guarantee shall only apply to defects that

occur within the 12 month guarantee period.

• Proof of purchase is required.

• The equipment is returned to BT or its agent

as instructed.

This guarantee does not cover any faults or defects

caused by accidents, misuse, fair wear and tear,

neglect, tampering with the equipment, or any

attempt at adjustment or repair other than through

approved agents.

This guarantee does not affect your statutory rights.

For further information within and outside the 12

month guarantee, please refer to the full user guide

at www.bt.com/help/userguides

Product disposal instructions

The symbol shown here and on the product means

that the product is classed as Electrical or Electronic

Equipment and should not be disposed with other

household or commercial waste at the end of its

working life.

The Waste of Electrical and Electronic Equipment

(WEEE) Directive (2002/96/EC) has been put in

place to recycle products using best available

recovery and recycling techniques to minimise the

impact on the environment, treat any hazardous

substances and avoid the increasing landﬁll.

Product disposal instructions for residential users

When you have no further use for it, please remove

any batteries and dispose of them and the product

as per your local authority’s recycling processes. For

more information please contact your local authority

or the retailer where the product was purchased.

Product disposal instructions for business users

Business users should contact their suppliers and

check the terms and conditions of the purchase

contract and ensure that this product is not mixed

with other commercial waste for disposal.

R&TTE Directive & Declaration

of Conformity

This product is intended for use within the UK for

connection to the public telephone network and

compatible switchboards.

This equipment complies with the essential

requirements for the Radio Equipment and

Telecommunications Terminal Equipment Directive

(1999/5/EC).

General information

A full user guide can be downloaded in PDF format

from www.bt.com/help/userguides

Please consider the environment before printing.

BT Graphite 1100

Troubleshooting

Most problems are caused by something very simple and can be ﬁxed with a few simple checks:

• Make sure both the mains power adaptor cable and telephone line cord are plugged into

the correct sockets and plugged in at the wall.

• Make sure you use all the cables and batteries that came in the box, not those from a

previous product.

• If you experience poor speech quality or interference, make sure the product is not

located too close to other electrical appliances. This can also help improve the handset

range from the base.

• Make sure you charge the batteries for at least 24 hours before ﬁrst use to ensure

maximum battery performance. The charge capacity of the batteries will decrease

over time.

Using your BT Graphite 1100 on a broadband Internet enabled line?

Remember to plug the phone into the wall socket via an ADSL microﬁlter if you have

broadband Internet on your phone line, otherwise you may have problems with this

product and your broadband service. Additional BT ADSL microﬁlters can be purchased

from www.shop.bt.com

This guide can

be recycled.

Produkt Specifikationer

Mærke:	British Telecom
Kategori:	Telefon
Model:	Graphite 1100 Quad
Type:	DECT telefon
Produktfarve:	Sort
Skærm:	LCD
Hurtig start guide:	Ja
Højttalertelefon:	Ja
Genopkaldsliste kapacitet:	10
Nummervisning:	Ja
Batteritype:	AAA
Maksimal indendørs rækkevidde:	50 m
Maksimal udendørsinterval:	300 m
Trådløs forbindelse:	Ja
Mac kompabilitet:	Ja
Banke på:	Ja
Håndsæt tastaturlås:	Ja
