Assembly Instructions: (Monroe)7041-M1L
IMPORTANT:
• ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
• SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
• USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See the important notes above. Shut off the
poweratthecircuitbreakerandcompletelyremovetheoldxturefromtheceiling,including
theoldmountingstrap.
1.Fromthepartsbagremovethemountingstrapassembly.Oneendofnipple(F)shouldbe
shouldhavecanopyloop(H)attached.Attachmountingstrap(A)tothejunctionboxusing
mountingscrews(B)andascrewdriver.Tightensecurely.
2. Unscrew canopy loop collar (I) from canopy loop (H). Pass canopy (G) over the mounted
canopylooptotesttheheight.Approximatelyhalfofthecanopyloop’sexteriorthreadsshould
be exposed, and the canopy loop collar should t snugly onto the canopy loop. Remove
reached.
ASSEMBLING THE FIXTURE
3.Decorativerod(N)isonthexture’swires,butnotattachedtothexture.Hookthebottom
of decorative rod (N) into top loop (L) and pull the wires until taut.
4. By measuring, determine the correct number of chain links needed for proper hanging
height.Ifnecessary,useapairofplierstoopenandremoveanyexcesschain.
5.Attachchainconnectors(K)toeachendofchain(J)beforeattachingoneendofthechain
connector/chain to the top of decorative rod (N). Close the chain connector. Connect the
other chain connector (K) to canopy loop (H).
collar (I) and canopy (G) onto the chain/wire.
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
For Customer Service, please
contact the place of purchase.
CONNECTING THE WIRES
7.Haveanassistantsupporttheweightofthexturewhilecompletingthewiring.Cutaway
excess wire. Threadthe xture’s wiresthrough canopyloop (H) andnipple (F). Attach the
xture’swirestothepowersupplywiresfromthejunctionbox.Connectblacktoblack(or
smooth);whitetowhite(orribbed);groundtoground(greenorcopper).Twisttheendsofthe
wirepairstogether,andthentwistonawireconnector.Makesurealltwistsareinthesame
direction.Ifthereisnogroundwire(greenorcopper)comingfromthejunctionbox,locate
groundscrew(E)onmountingstrap(A)andwrapthexture’sgroundwirearoundthegreen
groundscrew(E).Useascrewdrivertosecuregroundscrew(E)ontothemountingbracket.
Tuckallwiresneatlyintothejunctionbox.
A
B
F
K
G
I
H
D
K
J
C
E
P
L
M
N
O
FINISHING THE INSTALLATION
8.Pushcanopy(G)uptotheceilingand
slide canopy loop collar (I) up beneath
thecanopy.Tightlythreadcanopyloop
collar (I) onto canopy loop (H) to secure
canopy (G) in place.
House Wires
Fixture Wires
Hot
How to Identify the Fixture’s Wires
Hot Neutral Ground
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
9.Slideglassshade(P)oversocket(M)andsecureinplacewithsocketcover(O).
10.
Install a light bulb (not provided) in accordance with the xture’s specications. Do not exceed the maximum recommended
wattage.
Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
