December update 29 , 2016

Additional Information for

Range Hoods meeting ADA Compliance

Broan and NuTone branded residential range hoods can be installed to comply

with Sections 308 and 309 of ADA Guidelines, when used with appropriately

mounted controls installed at 15” to 48” above the floor and control access

should not require reaching over a cooking appliance.

The following range hoods can work in an ADA Compliant situation when the

range hood is wired to operate from a dedicated, standard electrical wall

switch. facilitate this application, share the information on the following To

pages with your electrician when preparing for the installation.

2-SPEED RANGE HOODS:

Broan 40000, F40000, 41000, 42000, 43000, 52000,

PM250, QL1, QS1, QSE1, QDE, QML and CBD1 Series,

BKSA1, CLSC1, CRSF1

NuTone NS6500, NSPM250, RL6200, WS1 Series, AHSA1, AVSF1

INTERMEDIATE RANGE HOODS: (with variable speed)

Broan 46000 & QT20000 Series

NuTone ACS Series

INSTALLATION

1. WARNING

To avoid fire or electrical shock, turn off power at circuit

breaker or fuse. Test that the power is off before wiring.

2. MOUNT THE SWITCH BOX

For 2-Rocker Switch: Install a 3½" deep single-gang

switch box or a 2" deep double-gang switch box.

For 3-Rocker Switch: Install a 2½" deep double-gang

switch box with a single device adapter plate.

3. ATTACH POWER CABLE

Clamp wiring to switch box and unit using appropriate

clamp. Provide 6" leads inside box and fan for easier

wiring.

4. CONNECT WIRING

General instructions for all configurations:

Make sure both the switch box and the appliance are

properly grounded.

Make sure ground wire is securely fastened to control's

ground screw. Tighten ground screw 14 to 16-in. lbs.

torque.

Remove insulation per strip gauge on control (approx.

5/8"). Use proper wire nut sizes for number and size of

wires.

For push-in terminals: Use #14-AWG solid copper wire

only.

For screw terminals: Use #12 or #14-AWG solid copper

wire only. Tighten screw terminals 14 to 16-in. lbs. torque.

Choose 4A., 4B. or 4C

4A. When using 2-Rocker or 3-Rocker Switch to turn an

appliance ON & OFF:

Make electrical connections following appropriate

diagram.

(over)

WARNING

To prevent serious injury from electrical shock or damage

to electrical components - DO NOT WIRE HOT!

Each individual rocker switch on this control is rated at 15

AMPS, @ 120 VAC. The total load on this control must not

exceed 20 AMPS, @ 120 VAC.

Warranty is void if miswired.

WARNING

ALL ELECTRICAL WORK MUST BE DONE IN

ACCORDANCE WITH LOCAL CODES, ORDINANCES,

OR NATIONAL ELECTRICAL CODE AS APPLICABLE.

FOR SAFETY, THIS PRODUCT MUST BE INSTALLED IN

A GROUNDED SWITCH BOX. IF YOU ARE UNFAMILIAR

WITH METHODS OF INSTALLING ELECTRICAL

WIRING, SECURE THE SERVICES OF A QUALIFIED

ELECTRICIAN.

Turn off power and lock out service panel before installing

or wiring this product.

Use this control only with copper or copper-clad wire. Do

not use aluminum wire with this device.

2-ROCKER & 3-ROCKER SWITCHES

3 - ROCKER SWITCH

2 - ROCKER SWITCH

STEP 4A

NOTE: If the switch has not been wired properly and wires need

to be moved, proceed as follows:

WARNING: To avoid fire or electrical shock, turn off power at

circuit breaker or fuse. Test that the power is off

before wiring.

1. Each wire opening has a

release slot.

2. Push a small nail or screw-

driver into release slot

while gently removing wire.

3. DO NOT pull any wire out

of the switch without using

the release slot. The switch

may become damaged.

RELEASE SLOT

WIRE OPENING

C O M

B L A C K

W H I T E

G R O U N D

G R D

B L A C K

W H I T E

G R O U N D

1 2 0 V A C

L I N E I N

L O A D

S I N G L E - G A N G

S W I T C H B O X A P P L I A N C E

R E D

COM

GRD

BLACK

WHITE

DOUBLE-GANG SWITCH BOX

(with single device adapter plate) APPLIANCE

GROUND

120 VAC

LINE IN

BLACK

WHITE

BLACK

WHITE

GROUND

LOAD

RED
