MODELS QP230BC QP230BL QP230SS QP230WW • • •

QP236BC QP236BL QP236SS QP236WW • • •

QP242BC QP242BL QP242SS QP242WW • • •

Page 1

WARNING

CAUTION

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR IN-

JURY TO PERSONS, OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended the manufac-by

turer. If questions, contact the manufacturer at the you have

address or telephone number listed in the warranty.

2. Before servicing or cleaning unit, switch power at service off

panel and lock the service disconnecting means prevent to

power from being switched on accidentally. When the ser-

vice disconnecting means cannot be locked, securely fasten

a prominent warning device, such as a the service tag, to

panel.

3. Installation and electrical wiring must be done a work by

qualified person(s) in accordance with all applicable codes

and standards, including fire-rated construction.

4. Sufficient air is needed proper combustion and exhaust-for

ing of gases through the flue (chimney) of fuel burning equip-

ment prevent backdrafting. Follow the heating equipment to

manufacturer’s guideline and safety standards such as those

published by the National Fire Protection Association (NFPA),

and the American Society of Heating, Refrigeration and Air

Conditioning Engineers (ASHRAE), and the local code au-

thorities.

5. This product may sharp edges. Be careful avoid cuts have to

and abrasions during installation and cleaning.

6. When cutting or drilling into wall or ceiling, do not damage

electrical wiring and other hidden utilities.

7. Ducted fans must be vented the outdoors.always to

8. Use only metal ductwork.

9. Do not use this with solid-state speed control fan any device.

10. As an alternative, this product be installed with the may UL-

approved cord kit designated the product, following in-for

structions packed with the cord kit.

11. This unit must be grounded.

TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:

1. Never leave surface units unattended at high settings.

Boilovers cause smoking and spillovers that ig-greasy may

nite. Heat oils slowly on or medium settings.low

2. Always turn hood ON when cooking at high heat or when

cooking flaming foods (i.e. Crepes Suzette, Cherries Jubilee,

Peppercorn Beef Flambé).

3. Clean ventilating fans frequently. Grease should not be al-

lowed accumulate on or filter.to fan

4. Use proper pan size. use cookware appropriate Always for

the size of the surface element.

TO TO REDUCE THE RISK OF INJURY PERSONS IN THE

EVENT OF A RANGE GREASE FIRE, OBSERVE THE TOP

FOLLOWING:*

1. SMOTHER FLAMES with a close-fitting lid, cookie sheet,

or metal then turn the burner. BE CAREFUL tray, off TO

PREVENT BURNS. If the flames do not go out immediately,

EVACUATE AND CALL THE FIRE DEPARTMENT.

EVOLUTIONTM 2

QP2 Series Range Hoods

READ AND SAVE THESE INSTRUCTIONS

FOR DOMESTIC COOKING ONLY

WARNING

2. NEVER PICK UP A FLAMING PAN — You be burned or may

spread the fire.

3. DO USE WATER, including dishcloths or towels - NOT wet

violent steam explosion will result.

4. Use an extinguisher ONLY if:

A. You know a Class ABC extinguisher and you have you

already know operate it.how to

B. The is small fire and contained in the area where it started.

C. The department is being called.fire

D. You can fight the with your back an exit.fire to

* Based on “Kitchen Safety Tips” published NFPA.Fire by

1. For indoor use only.

2. For general ventilating use only. Do not use exhaust haz-to

ardous or explosive materials and vapors.

3. To avoid motor bearing damage and noisy and/or unbal-

anced impeller, keep drywall spray, construction dust, etc.,

off power unit.

4. Do not use cooking equipment greater than 60,000 over

BTU/hr. as the blower motor will shut down intermittantly.

5. Your hood motor has a thermal overload which will automati-

cally shut the motor if it becomes overheated. The motor off

will restart when it cools down. If the motor continues shut to

off and restart, the hood serviced.have

6. The of the hood MUST BE LESS than 24” and at a top NOT

maximum of 30” above cooktop best capture of cooking for

impurities.

7. This hood is not intended be used as a shelf.to

8. Please read specification label on product further infor-for

mation and requirements.

Installer: Leave this manual

with the homeowner.

Homeowner: Cleaning, Maintenance and

Operating instructions on page 2.

NOTE If hood is be installed non-ducted:to

Purchase set a of (2) non-ducted filters 30” for wide

hoods (Model BPPF30) & 36” wide hoods (Model

BPPF36) or a set of (3) non-ducted filters 42” for wide

hoods (Model BPPF42) from your local distributor or

retailer and attach them the aluminum to mesh filters.

MODELS QP230BC QP230BL QP230SS QP230WW • • •

QP236BC QP236BL QP236SS QP236WW • • •

QP242BC QP242BL QP242SS QP242WW • • •

Page 2

CLEANING & MAINTENANCE

For performance, appearance, and health reasons, clean filter,

fan and grease-laden surfaces. Use only a clean cloth and mild

detergent solution on stainless and painted surfaces.

Clean all-metal filters in the dishwasher using a non-phosphate

detergent. Discoloration of the filter may occur if using phosphate

detergents, or as a result of local water conditions - this will but

not affect filter performance. This discoloration is not covered by

the warranty.

Clean the non-duct recirculating filter surfaces frequently with

a damp cloth and a mild detergent. DO immerse filters in NOT

water or put in dishwasher. The special “Clean Sense” feature

indicates when the filter is be replaced. The blue and yellow to

strips will blend green when it is time change the filter. The to to

“Clean Sense” feature works best when facing the cook-toward

ing surface. Change the non-duct recirculating filters 6 every

months. For replacement non-duct recirculating filters - purchase

S99010353 or Model BPPF30 30 wide hoods”, S99010354 for

or Model BPPF36 36” wide hoods, or S99010360 or Model for

BPPF42 42” wide hoods.for

The motor is permanently lubricated and never needs oiling. If

the motor bearings make excessive or unusual noise, replace

the motor with the exact service motor. The impeller should also

be replaced.

Use 120 V, 50 W, shielded halogen bulbs - MR16 with GU10 base.

OPERATION

Always turn the hood ON before cooking in order establish an to

air flow in the kitchen. After turning the range, let the hood run off

for few a minutes clear the air.to

Operate the hood as follows:

LIGHT (3 pushbutton switches)

Turns light on setting.to LOW

Turns light on MEDIUM setting.to

Turns light on HIGH setting.to

Pressing the same light again will turn lights OFF.button

A light above each indicates light setting.button

FAN (3 pushbutton switches)

Turns on speed.fan to LOW

Turns on MEDIUM speed.fan to

Turns on HIGH speed.fan to

Pressing the same again will turn OFF.fan button fan

A light above each indicates speed.button fan

NOTE

This hood utilizes an offset blower design achieve greater to

performance and lower sound levels. As a result, you notice may

that cooking impurities more attracted one side or appear are to

to be pulled-in faster than they appear on the opposite side. This

is completely normal. The hood has been designed and tested

to provide good capture of cooking impurities and odors under

all normal cooking conditions regardless of the cooking location

on the cooktop. Please note that cooking on the rear burners will

always result in the best capture of cooking impurities, regardless

of the hood design.

HEAT SENTRY SYSTEM

This range hood is equipped with an advanced Heat Sentry sys-

tem that monitors excessive temperature and automatically for

adjusts the the appropriate setting.fan to

1) If the fan is on, the Heat Sentry will increase the system fan

setting when the temperature is elevated. If the temperature con-

tinues rise, the Heat Sentry will continue increase to system to

the fan setting until the temperature is stabilized or reduced. The

flashing light above the fan button shows the Heat Sentry system

fan setting. Once the temperature has reduced, the Heat Sentry

system to will change the fan the original setting.

2) If the fan is off, the Heat Sentry system will automatically turn

the on its highest speed when the temperature is above fan to

normal. When the Heat Sentry is on, the light above the system

high speed fan will flash on and button off. After the temperature

has lowered normal, the speed will be reduced until the to fan

temperature has stabilized, then the will turn fan off.

CONTENTS

GREASE

FILTERS

(2 - FOR 30” & 36” HOODS)

3 - FOR 42” HOODS)

(1) 3¼” X 10”

DAMPER / DUCT

CONNECTOR

(1) 7” ROUND

DUCT

CONNECTOR

(4)

HALOGEN

BULBS

(1)

BULB

SUCTION

CUP TOOL

(1) PARTS BAG CONTAINING:

(3)

WIRE

NUTS

(1)

NON-DUCT

DIVERTER

INCLUDED WITH THE HOOD:

(9)

#8 X 1/4”

DUCT

CONNECTOR

SCREWS

(5)

#10 X 5/8”

RD. HD.

MOUNTING

SCREWS

(2)

#8 X 5/16”

MACHINE

SCREWS

(2)

#8 WASHERS

FOR NON-DUCT

DIVERTER

Note: Canadian version does not this function.have
