Side 1/40

Downdraft Ventilators

Page 1

WARNING

READ AND SAVE THESE INSTRUCTIONS

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR

INJURY TO PERSONS, OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended by the manufacturer.

If you have questions, contact the manufacturer at the address

or telephone number in the warranty.

2. Before servicing or cleaning unit, switch power oﬀ at service

panel and lock the service disconnecting means to prevent

power from being switched on accidentally. When the service

disconnecting means cannot be locked, securely fasten a

prominent warning device, such as a tag, to the service panel.

3. Installation work and electrical wiring must be done by a

qualiﬁed person(s) in accordance with all applicable codes

and standards, including ﬁre-rated construction codes and

standards.

4. Suﬃcient air is needed for proper combustion and exhausting

of gases through the ﬂue (chimney) of fuel burning equipment

to prevent backdrafting. Follow the heating equipment

manufacturer’s guideline and safety standards such as those

published by the National Fire Protection Association (NFPA),

and the American Society for Heating, Refrigeration and Air

Conditioning Engineers (ASHRAE), and the local code au-

thorities.

5. When cutting or drilling into wall or ceiling, do not damage

electrical wiring and other hidden utilities.

6. Ducted fans must always be vented to the outdoors.

7. To reduce the risk of ﬁre, use only metal ductwork.

8. Do not install this product with the activating switch directly

behind a burner or element. Minimum distance between the

switch and the edge of the burner should be 4 inches.

9. Loose-ﬁtting or hanging clothing should never be worn when

operating this appliance. They may be ignited by burners/

elements on cooktop.

10.Children should not be left alone or unattended in the area

where this appliance is in use.

11. This unit must be grounded.

TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:

a) Never leave surface units unattended at high settings.

Boilovers cause smoking and greasy spillovers that may

ignite. Heat oils slowly on low or medium settings.

b) Always turn hood ON when cooking at high heat or when

cooking ﬂaming foods.

c) Clean ventilating fans frequently. Grease should not be

allowed to accumulate on fan or ﬁlter.

d) Use proper pan size. Always use cookware appropriate

for the size of the surface element.

TO REDUCE THE RISK OF INJURY TO PERSONS IN THE

EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE

FOLLOWINGa:

1. SMOTHER FLAMES with a close-ﬁtting lid, cookie sheet,

or metal tray, then turn oﬀ the burner. BE CAREFUL TO

PREVENT BURNS. If the ﬂames do not go out immedi

ately, EVACUATE AND CALL THE FIRE DEPARTMENT.

2. NEVER PICK UP A FLAMING PAN - You may be burned.

3. DO NOT USE WATER, including wet dishcloths or towels

- a violent steam explosion will result.

4. Use an extinguisher ONLY if:

A. You know you have a Class ABC extinguisher, and you

already know how to operate it.

B. The ﬁre is small and contained in the area where it

started.

C. The ﬁre department is being called.

D. You can ﬁght the ﬁre with your back to an exit.

a Based on “Kitchen Firesafety Tips” published by NFPA.

CAUTION

1. For general ventilating use only. Do not use to exhaust

hazardous or explosive materials and vapors.

2. To avoid motor bearing damage and noisy and/or unbalanced

impellers, keep drywall spray, construction dust, etc. oﬀ power

unit.

3. Clean ﬁlters and grease-laden surfaces frequently.

4. Do not repair or replace any part of this appliance unless

speciﬁcally recommended in this manual. All other servicing

should be done by a qualiﬁed technician.

5. Please read speciﬁcation label on product for further informa-

tion and requirements.

MODEL WIDTH BLOWER

RMDD3004 30" 500 cfm Interior

RMDD3604 36" 500 cfm Interior

RMDD4804 48" 500 cfm Interior

RMDD3004EX 30" Models 331H, 332H, 335, or 336 Exterior (purchase separately)

RMDD3604EX 36" Models 331H, 332H, 335, or 336 Exterior (purchase separately)

RMDD4804EX 48" Models 331H, 332H, 335, or 336 Exterior (purchase separately)

WARNING - To reduce the risk of burns or ignition of clothing by reaching across burners, the downdraft remote control MUST

be mounted in the countertop - at least 4" from the burners. See "INSTALL COOKTOP" section on page 8.

INSTALLER:

Save this manual for Electrical

Inspector and Homeowner to use.

NOTE:

Model RMDDRBK Remote Up/Down

Control sold separately.

Page 2

Downdraft Ventilators

AIR

VENT

COUNTER

TOP

BLOWER

BOX

CHIMNEY TOP

COOK TOP

GEAR

MOTOR

COVER

TYPICAL INSTALLATION

120 VAC

GROUNDED

OUTLET

This downdraft blower system

is designed to be used to ex-

haust airborne contaminants

when cooking with a variety of

gas or electric cooktops. It can

be mounted in island, penin-

sula, or conventional wall loca-

tions.

This unit can be easily installed

following these basic steps:

•Cut out the countertop

opening.

•Mount the unit in the

cabinet.

•Connect the ductwork and

electrical.

•Install the cooktop.

Note: the high level of air ﬂow of

this appliance may eﬀect the

gas ﬂame on some types of gas

cooktops. This is NORMAL and

will cause no harm, but can be

corrected by lowering the speed

of the blower.

PLANNING

Interior Blower Installation Exterior Blower Installation

Note: the high level of air ﬂow of this appliance may eﬀect the gas

ﬂame on some types of gas cooktops. This is NORMAL and will

cause no harm, but can be corrected by lowering the speed of the

blower.

ELECTRICAL

SPECIFICATIONS

120 VAC • 60 Hz • 4.0 A

TAKE MEASUREMENTS

All Units

1. Refer to the cooktop installation instructions for dimensions of

cooktop, countertop cut-out, and cabinet requirements. Mod-

els RMDD3004 & RMDD3004EX will ﬁt in most 30" wide

cabinets. Models RMDD3604 & RMDD3604EX will ﬁt in most

36" wide cabinets. Models RMDD4804 & RMDD4804EX will

ﬁt in most 48" wide cabinets. However, it is recommended that

oversized cabinets be used for easier installation.

2. Cooktop depth can vary greatly from one to another. This may

cause the ﬁt of these two appliances to be rather tight.

Pay special attention to the areas of potential interference high-

lighted above. A countertop with (A) a raised lip and/or (B) a

backsplash may not allow enough ﬂat countertop for a proper

installation. Note that 2" of ﬂat countertop is required behind

cooktop and that 1-3/4" is necessary between the back edge of

the cooktop and the inside of cabinet back.

ELECTRICAL

SPECIFICATIONS

120 VAC • 60 Hz • 6.0 A (max.)

3-1/4" X 10"

DUCT CONNECTOR

AIR

VENT

BLOWER

BOX

CHIMNEY TOP

COOK TOP

GEAR

MOTOR

COVER

TYPICAL INSTALLATION

3-1/4" X 14"

DUCT CONNECTOR

120 VAC

GROUNDED

OUTLET

COUNTER

TOP

This downdraft blower system

is designed to be used to ex-

haust airborne contaminants

when cooking with a variety of

gas or electric cooktops. It can

be mounted in island, penin-

sula, or conventional wall lo-

cations.

This unit can be easily installed

following these basic steps:

•Cut out the countertop

opening.

•Mount the unit in the

cabinet.

•Install Model 331H, 332H,

335, or 336 External

Blower

•Connect the ductwork

and electrical.

•Install the cooktop.
