Electronic Door Lock

1 Slide the cylinder from outside to inside through prole cylinder opening.

2 Fix cylinder with the xing screw.

3 Stick inner knob onto cylinder resp. onto appropriate adapter and screw in tight.

Chart 1 provides the corresponding gradations.

4 Slide case over the inner knob and let it snap in.

Assembly for doors whose thickness incl. ttings are bigger than 29 mm on

each side.

1 Compress with the help of the removal plier the snap-in nose of the knob and

slide off the case.

2 Carefully remove the connector.

Introduction

Congratulations on the purchase of Your BURG-WÄCHTER quality product! Thank You

for choosing the electronic locking system secuENTRY 7000 pro from the house of

BURG-WÄCHTER. This system was designed and produced using the latest technical

possibilities and to fulll high security requirements. The electronic cylinder can easily and

without any drilling be applied to every door with prole cylinder perforation and up to

a door thickness of 130 mm (67,5/62,5, measured centre xing screw) and is excellently

suitable for new installation as well as for retrot.

Content of Instructions

General remarks

Technical data

Installation

Battery replacement

Programming/functions/handing

Guarantee /environment

A. General remarks

Please read the instructions carefully before You begin with installing and programming.

Keep the instructions safe. We wish You much pleasure with Your new locking system.

The secuENTRY 7000 pro cylinder can be used with the following opening devices:

• Keypad PINCODE

• Keypad FINGERPRINT

• Transponder

• Smartdevice/App

The opening devices are separately available.

Administrator code / QR code

Every secuENTRY 7000 pro cylinder comes with a QR code, which is necessary both

for programming the keypad as well as for integration into the locking system via the

optional secuENTRY software. Without an appropriate keypad, opening devices

(user, transponder) can only be programmed to the cylinder via BURGsmart App

or the optional software. The administrator code can as well be found on the

note showing the QR code.

SN:

10 : 2D : 00 : 3E

30 : 42 : 25 : 00 : 00 : 60

123456

E1 : 25 : F3 : E2 : DB : 86 : C0 : 70 :

F7 : EA : 04 : 93 : 17 : 2E : BF : 9E

MAC:

AES:

ADM:

1 Cylinder

(SN; MAC; AES; ADM)

Look out! In case of loss of the administrator and/or the QR code,

reprogramming or usage of all administrator features will not be possible

anymore. Please store away safely!

Tip: The QR code can as well be scanned in digital form or saved as a picture on a

protected disk.

For possibly occurring injuries or damages incurred during assembly or by improper

handling, the manufacturer accepts no liability.

B. Installation

In the following the installation process for the secuENTRY 7000 pro cylinder will be

explained. Please read the instructions carefully before the installation.

Please note

Basic measurements of each side of the cylinder is 30 mm. Delivered, the cylinder inner

surface measures 30 mm, bought externally it already is preassembled. Enclosed to the

cylinder is an adapter set, that allows You to adjust the cylinder to doors with a thickness

up to 130 mm (67,5/62,5/measured centre xing screw). Fitting to the adapter length,

appropriate screws are enclosed to Your set.

Abb.1: Illustration shows

adapter and the

appropriate screws

(1:1 Illustration on separate

suppl. sheet)

M 4 x 6

M 4 x 12

M 4 x 16

M 4 x 20

M 4 x 30

M 4 x 25

M 4 x 35

M 4 x 40

M 4 x 45

Adapter No

Adapter

1 2 3 4

Measure A; B <=

29mm

29,5 –

34mm

34,5 –

38,5mm

39 –

42,5mm

43 –

47,5mm

Screw M4 x 6 M4 x 12 M4 x 16 M4 x 20 M4 x 25

Adapter 5 6 7 8

Measure A; B 48 –

52,5mm

53 –

57,5mm

58 –

62,5mm

63 –

67,5mm

Screw M4 x 30 M4 x 35 M4 x 40 M4 x 45

Chart 1: Required adapter

Look out! It is important to ensure that the inner knob does not bump against

anything as the knob can break. The lock must not be greased or oiled.

Proceed with installation as follows:

Place cylinder on the door to check whether an adapter is needed. Alternatively, the

door incl. metal ttings can be measured (measure A; B). If You want to use the rubber

covering for the prole cylinder perforation, You need to add 2 mm each onto the

measures.

Assembly for doors whose thickness incl. ttings are smaller than 29 mm on

each side and where the cylinder can be pushed from the inside to the outside

through the prole cylinder opening.

Look out! Do not damage the

plate or the cable!

4 Remove the knob from the cylinder and thread the cable out of the duct.

5 Choose the appropriate adapter for the outside and push open. Chart 1 provides

the corresponding gradations.

6 Slide installation aid over connector and slide it together with the cylinder and the

adapter from the inside into the mortice lock.

Look out! Do not crease or damage

cable!

7 Fixate cylinder with xing screw.

8 If required, assemble the cylinder extension (inside/outside) and succinctly mark with

tting.The cylinder extension prevents a contortion of the cylinder.

9 Disassemble cylinder extension, reduce with a saw to desired length and assemble

denitively.

10 Slide cable with installation aid through the outside knob and lead cable

inside the groove. Look out: Do not crease or damage cable!

11 Click adapter onto the cylinder.

12 Keep cable sturdy and lead through the groove.

Look out! Cable must not overlap and

has to be stored completely inside the

pocket!

13 Screw in appropriate screw with the enclosed inner-hex driver.

Look out! Do not crease or damage

cable!

14 Connect cable over the plug connection with the plate and store the spare cable

inside the designated side pocket.

o

7000

BURG-WÄCHTER KG

Altenhofer Weg 15

•

58300 Wetter

•

Germany

info@burg.biz · www.burg.biz

BW_pro 7000 Zylinder_BA_sE_009100 hsb/eba/swi 190723

Installation and operating instructions

Further languages at:

www.burg.biz
