Digital Wireless Guitar System
The CAD Audio WXGTS Digital Wireless Guitar System makes it
easy to cut the cord, providing high-quality audio in an easy to use,
compact design. The WXGTS operates in the 2.4GHz ISM
frequency band allowing unlicensed operation throughout the
world. The WXGTS can support up to 6 units operating
simultaneously in the same area. Alternatively, one transmitter can
sync to multiple receivers at the same time. You will enjoy up to
100 feet (30.5m) of operating range and up to 5 hours of battery
life for maximum freedom of movement for the entire gig. The
compact design eliminates the need for bodypacks or wires,
making mid-show instrument swaps easier than ever before. The
WXGTS may be used with other electronic instruments such as
The WXGTS Digital Wireless Guitar System contains the following
• 2.4GHz operating frequency allows for
license-free use worldwide.
• 24-bit/48KHz uncompressed digital conversion.
• Up to 100' (30.5m) operating range.
• Built for guitars, but compatible with a wide range
of electronic instruments.
• 280° rotating body fits most instrument body styles.
• Built-in rechargeable batteries last up to 5 hours per charge.
Thank you for choosing our Wireless Guitar System. The product is
designed for guitar for wireless connection. We have tried our best
to provide you a low noise and latency, high sound quality (48KHz)
and long transmission distance wireless device. Enjoy yourself with
The USB cable is mainly for charging. Please use this to connect to
USB interface of your devices and make sure you use a qualified
While charging, please make sure that the device is shut down to
avoid the loss of electricity during charging, which will lead to longer
charging time and shorter battery life. When the device is not in
use, please shut down in time to avoid continuous battery
Please always turn off the power of the equipment when connecting
or disconnecting with the guitar. It will help to prevent the damage
cause to this product and other relevant equipment.
Operation is subject to the two following conditions: (1) this device
may not cause harmful interference, and (2) this device must
accept any interference received, including the interference that
may cause undesired operation.
To reduce the risk of fire of electric shock, please do not expose
appliance to rain or moisture.
Two-Year Limited Warranty
CAD Audio hereby warrants that this product will be free of defects in
material and workmanship for a period of two years from the date of
purchase. In the unlikely event that a defect occurs, CAD will, at its option,
either repair or replace with a new unit of equal or greater value. In the event
that a suitable replacement is unavailable, CAD Audio may elect to reimburse
owner for the cost of local repairs or issue a refund in the amount of the
original purchase price. Items must be purchased from an authorized CAD
Audio dealer, and the warranty is not transferable from the original owner.
Please retain proof of purchase to validate the purchase date and include it
This warranty excludes exterior finish or appearance, damage from abuse,
misuse of the product, use contrary to CAD’s instructions or unauthorized
repair. All implied warranties, merchantability, or fitness for a particular
purpose is hereby disclaimed and CAD hereby disclaims liability for
incidental, special or consequential damages resulting from the use or
unavailability of this product.
This warranty gives you specific legal rights and you may have other rights
that vary from state to state. Some states do not allow the exclusion or
limitation of incidental or consequential damages or limitations on how long
an implied warranty lasts, so the above exclusions and limitations may not
Note: No other warranty, written or oral is authorized by CAD Audio.
To initiate a warranty claim, please contact American Music and Sound
at 1-800-431-2609 to obtain a return authorization number and shipping
• A return authorization is required for all returns. RETURNS WITHOUT A
PRE-APPROVED RETURN AUTHORIZATION NUMBER WILL
• Please use at least 3 inches of padding surrounding the product for
protection during shipment
• Retain your tracking number until your warranty claim has been resolved
• We recommend using an insured shipping method in case of loss
or damage during shipment
If outside the United States, contact your local dealer or distributor for
Individuals with cardiac pacemakers and other similar medical devices
should consult with their physician before using any RF devices. Though
the output level of this wireless system is below 50 milliwatts, the proximity
of the transmitter to the implant device could pose a threat.
As with any wireless product, environmental conditions can reduce or in
some cases prohibit a successful connection between the transmitter and
This device complies with Part 15 of the FCC Rules. Most users of CAD
Audio wireless products in the United States do not need a license for
operation. However, the rules for unlicensed operation state that this
device must not operate in excess of 50 milliwatts and it must not cause
harmful interference to other wireless devices, and must accept
interference received from other devices. Wireless products meeting CAD
factory standards adhere to these rules. The FCC reserves the right to
change these rules at any time. For more information contact the FCC at
1-888 -CALL-FCC (TTY: 1-888 -TELL-FCC) or visit the FCC’s wireless
microphone website at: www.fcc.gov/cgb/wirelessmicrophones
6573 Cochran Rd., Bldg. Solon, OH 44139 U.S.A.I
Tel: (440) 349-4900 Fax: (440) 248- 4904
Sales: 800-762-9266 cadaudio.com
Distributed Worldwide by American Music and Sound
925 Broadbeck Drive, Suite 220
Newbury Park, CA 91320 U.S.A.
Tel: (800) 431-2609 Fax: (800) 431-3129
©2021 CAD Audio Rev00 1221
Plug the transmitter into your instrument output jack. Plug the receiver
into your instrument amplifier, effect pedal input, or mixer input.
The devices should be charged prior to use via the USB Charging Ports,
with the device power off.
Power up the transmitter and the receiver. The Status Indicators will
slowly flash letting you know the devices are not yet paired.
Press and hold the Pairing Key of the receiver. The Status Indicator will
flash indicating pairing mode. Press and hold the Pairing Key of the
transmitter. Momentarily the Status Indicators of both devices will reach
steady state, pairing complete.
Up to 6 separate systems may be used simultaneously in the same area
Alternatively, multiple receivers may be used with one transmitter
To operate this way, initiate pairing mode with all receivers. Then initiate
pairing mode on the transmitter. When pairing mode is finished, one
transmitter may be received by all receivers.
1. Transmitter Signal Input. Plug into the output jack of
Rotating Plug, convenient for most musical instruments.
5. Pairing Key. Press and hold for 3 seconds to initiate pairing,
• Steady state indicates transmitting mode.
• Slow flash indicates low battery.
• Quick flash indicates pairing.
1. Receiver Output. Plug into amplifier, mixer, or effects pedal
Rotating Plug. Convenient for most applications.
5. Pairing Key. Press and hold for 3 seconds to initiate pairing.
The Tri-Status Indicator will flash after receiving signal from
transmitter. The flash number indicates the number of transmitters
• Steady state indicates pairing successful, receiving.
• Slow flash indicates low battery.
Device cannot be powered on:
• Be sure to charge the battery prior to use.
• The battery can enter protection mode if left uncharged for a
long time. Charging for more than 10 minutes will bring the
battery out of protection mode and into charge mode. It is
best to charge device when powered off.
Device is powered on however no audio transmission:
• System has likely not been paired. Initiate pairing procedure.
Unpleasant noise while in use:
• This could be due to strong electromagnetic interference or
receiver out of usable range. Reduce distance between
transmitter and receiver.
Troubleshooting Applications
Frequency Response ..................................................... 20Hz-20kHz
Frequency Band Range ............................................. 2.4 - 2.483GHz
Latency ......................................................................................≤12ms
THD .......................................................................................... <0.13%
Noise...........................................................................................-87dB
Dynamic Range ..................................................... 105dB A-weighted
Transmitter Power ................................................................... 140MA
Battery Life...................................................Up to 5 hours per charge
Weight............................................................................. 0.4lbs (.18kg)
Dims ...................................................................... 4.75" x 3.35" x 2.6"
