Side 1/19

Thank you for choosing a Caliber product. In doing so you’ve demonstrated a

desire to own the ﬁnest in Car Audio Technology. Caliber strives to provide you

with the ﬁnest products possible, and is always looking for ways to please our

customers even more.

Properly installed, your Caliber ampliﬁer will provide years of high quality sonic

reproduction. Before installing the ampliﬁer in your vehicle, please read this enti-

re manual carefully, in order to protect your vehicle, and get the maximum per-

formance of your mobile sound system.

Caliber Warranty

Due to the complexity of our products, we strongly recommend that this ampli-

ﬁer is installed by your authorized Caliber dealer. If properly installed by your

dealer we provide a warranty for 12 month from the date of purchase.

If you install this ampliﬁer yourself, we wish you lots of fun and succes in doing

so. If you follow our guidelines, you’ll get the best result. Our warranty, however,

will be limited to and not exceed 30 days from the date of purchase.

Caliber Accessories

To r ealize the exceptional performance of which this ampliﬁer is capable, it is

necessary that power sources, signal sources, speakers and interconnects are of

the highest quality. Remember that Caliber is not just an ampliﬁer manufacturer.

We also manufacture everything needed for the ‘optimal’ Car Audio System

(except the car). So be sure to ‘Get Connected’ with Caliber and ask your local

Caliber dealer for our accessories.

Contents

Before you start your installation . . . . . . . . . . . . . . . . . . . . . .This page

Features and Speciﬁcations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Mounting and Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Signal input/ -output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Speaker output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Equalizer adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Manuel de propriétaire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Bedienungsanleitung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

BEFORE YOU START

All Caliber Competition Pro Series Ampliﬁers have the following speciﬁcations.

Variable speciﬁcations are listed per model.

Frequency response (+0, -1dB) 20Hz - 30kHz

Total Harmonic Distortion <0,05% with 80kHz LPF

Signal to noise ratio (A-Weighted) >95dB

Input Sensitivity RCA input 15V - 500mV

Input Impedance 20 kOhm

Damping Factor > 180

Output Impedance 2 - 8 Ohm

2-channel Ampliﬁers

Competition CA 130 Pro Series

Maximum Power Output at 14,4V

4 Ohm 20Hz - 30kHz THD 0,5% 2x 130W

4 Ohm 1kHz Mono Bridged 1x 260W

Continuous Power Output at 14,4V

4 Ohm 20Hz - 30kHz THD 0,5% 2x 65W

4 Ohm 1kHz Mono Bridged 1x 130W

Fuse Rating 20A

Dimensions (WxHxD mm) 200 x 60 x 235

Competition CA 190 Pro Series

Maximum Power Output at 14,4V

4 Ohm 20Hz - 30kHz THD 0,5% 2x 190W

4 Ohm 1kHz Mono Bridged 1x 380W

Continuous Power Output at 14,4V

4 Ohm 20Hz - 30kHz THD 0,5% 2x 95W

4 Ohm 1kHz Mono Bridged 1x 190W

Fuse Rating 25A

Dimensions (WxHxD mm) 250 x 60 x 235

Competition CA 250 Pro Series

Maximum Power Output at 14,4V

4 Ohm 20Hz - 30kHz THD 0,5% 2x 250W

4 Ohm 1kHz Mono Bridged 1x 730W

Continuous Power Output at 14,4V

4 Ohm 20Hz - 30kHz THD 0,5% 2x 125W

4 Ohm 1kHz Mono Bridged 1x 250W

Fuse Rating 2x 20A

Dimensions (WxHxD mm) 320 x 60 x 235

Due to our effort to innovate and improve our ampliﬁers, this modern generation

of Caliber Competition Pro Series ampliﬁers offers you the following features:

•Bridgeable outputs.

•’Tri-mode’ output capability, simultaneous stereo & bridged

mono set up is possible.

•Pulse Width Modulated (PWM) MOSFET Power Supply.

•2 Ohm stable (4 Ohm mono-bridged)

•Double sided epoxy board.

•Variable input sensitivity: 15V to 0.5V.

•Thermal-, Overload- and Shortcircuit protection.

•Excellent muting circuitry assures no turn on/off ‘pops’.

•Built-in 7 band equalizer for each channel.

•Built-in phase control for each channel

•Built-in adjustable HighPass/LowPass/FullRange Filter(s).

•Built-in subsonic ﬁlter adjustable 10-50Hz

•Differential inputs to shunt any input noise

•Signal output RCA’s for additional ampliﬁer(s) (exept CA 670).

•Large power supply connectors for optimal power distribution.

•Chrome-plated speaker connectors for optimal signal output.

•European design and engineering.

•Superb Sonic Performance for your ‘Dream Machine’ on wheels.

•Years and years of acoustic pleasure.
