Side 1/24

CA 4050

Maxim u m Power Ou tp ut at 1 4, 4V

4Ω 20Hz - 30kHz THD 1% 4x 225W

2Ω 20Hz - 30kHz THD 1% 4x 180W

4Ω 1kHz Mono Bridged 2x 450W

Co ntinu ou s Pow e r O utp ut at 14,4 V

4Ω 20Hz - 30kHz THD 1% 4x 60W

2Ω 20Hz - 30kHz THD 1% 4x 75W

4Ω 1kHz Mono Bridged 2x 180W

Fuse R a ti ng 2x 20A

Di m en sion s 275x360x50mm

E n g l i s h

F E a t u R E s

• Bridgeable outputs.

• ’Tri-mode’ output capability, simultaneous stereo & bridged mono set up is possible.

• Pulse Width Modulated (PWM) MOSFET Power Supply.

• Variable input sensitivity: RCA input 0.5V to 2V.

• Thermal-, Overload- and Shortcircuit protection.

• Excellent muting circuitry assures no turn on/off ‘pops’.

• Built-in High Pass / Full Range / Low Pass Filter Switch. 50Hz - 250Hz

• Chrome plated power connectors for optimal power distribution.

• European design and engineering.

• Chrome plated speaker connectors for optimal signal output.

M O u n t i n g

The amplifier has to have at least 5 cm (2”) ventilation space at all sides, to allow the heat to rise

away from the amplifier. Be sure that the power and signal cables can enter and leave the ampli-

fier in a straight line, to avoid the risk of malfunction. Always place the power- and signalcables at

opposite sides of the vehicle to reduce any noises.

The amplifier should be protected from exposure to moisture and direct sunlight.

Mark the mounting surface using the amplifier as a template, then drill 2.5 mm (1/8”) diameter

holes at the marked locations and mount the amplifier using the supplied self-tapping screws.

i n s t a l l a t i O n

Remember to always disconnect battery ground before working on a vehicle’s electrical system!

Always place a fuse or circuit breaker no more than 30 cm (12”) from the battery, no greater

than the fuse(s) of your amplifier for optimal protection.

g E t t i n g y O u R P O w E R s t a R t E D

• First, the +12V terminal is connected directly to the battery of your car. Use a cable of at

least 10 mm2, and make sure that the connectors are of the same value.

- Don’t forget the extra “Vehicle protection” fuse.

- The 12V + terminal should NOT be connected to the car fuse box.

• Second, the ground terminal (GND) must be fastened securely to the chassis of the vehicle with

the same mm2 cable as the positive cable (the same amount of power has to run through it).

Ensure that all paint, undercoating or any other insulation is removed from the area where you

want to make your ground connection to.

• Third, the last cable to connect is your remote turn-on (REM). Many radio-cassette and

CD-players have an output terminal for connection of the REM of an amplifier. If you don’t have

such an output, a separate switch must be installed to control your amplifiers on/off function.
