Side 1/12

16 8109 37

212017161514131211 2219518

MCD 065

English

Short press Long press Short press Long press Short press Long press

1 Mute

2 Power on Power off

4 Audio menu Menu Ok

5 Mode Loud

6 Rotary volume

8 AF

9 TA

10 PTY

11 PS AS

12 M1 Memory 1 Pause/play

13 M2 Memory 2

14 M3 Memory 3 INT

15 M4 Memory 4

Random

16 M5 Memory 5 File/track down -10

17 M6 Memory 6 File/track up +10

18 Display Info

19 Band Enter

20 Seek down Tune down File/track down Fast backward

21 Seek up Tune up File/track up Fast forward

22 Scan

Scan (tuner)

Each found station will be played for 5 seconds

Note! Do not operate the unit while driving.

Power

Repeat

Seek up/down

Short press to move to the next station automatically

USB input

To connect an external audio system

These are the preset stations where you can store your favorite radio stations if in tuner mode

Panel release

Power function to activate or deactivate the unit. To deactive press and hold the power button for 3 seconds

Tune up/down

Band

Push this button to confirm the option you have selected.

Long press to move the radio frequency number up/down step by step.

The PTY function allows you to search for stations with a particular program type like NEWS group and POP group both of these groups

are divided in different subjects. PTY "POP", pop/rock, easy/light, classics/others, jazz/country, nation/oldies. PTY "NEWS", news/info,

sport/educatie, culture/science, weather/finance, social/religion

TA stands for Traffic announcement which means that it will give you information about the traffic (if broadcasted) no matter what mode

you are in (USB, SD) it will automatically interrupt the music and give the information, after that it automatically switches back to the

selected mode.

TUNER MP3/WMASYSTEM

Mute

Repeat track

Repeat all

Panel release button

3.5mm AUX in Jack

Band selection allows you to select different reception bands, f.i. FM1, FM2, FM3

Push this button to turn off the sound, push again to return to the last volume level.

KEY

M1-M6

Rotary volume

PTY

Menu (system)

Info

Audio menu

This button allows you in USB or SD mode to play or to pause the music.

3,5mm AUX in Jack

Pause/Play

When inserting a USB stick the unit will switch to USB mode. (Max 1000 tracks)

INT will play 10 seconds of each song on the USB or SD. If the preferred song is playing, push again and it will play that song

Mode

Random

In MP3 mode press this button to go up or down one folder.

Fast forward/backward

Long press to fast forward to the USB or SD

PS stands for Preset stations this means that when you push this button in tuner mode it will automatically switches to the first preset (M1)

then it will go to the next and so on.

Repeat will play a selected song or album continuously. Available in USB and SD mode

Shuffle will play all the songs random. Available in USB and SD mode

File/track down/up

INT

AS stands for Autostore; in tuner mode it will automatically store the 6 strongest stations (M1-M6). Note: all previous stored stations are lost

This knob allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears

Description of the functions

Push this button to release the frontpanel

AF stands for Alternative frequencies; the tuner will return to alternative frequencies whenever the reception signal is getting worse

View played track information

The Audio menu button gives you the possibility to adjust your sound system with the following options Bass, Treble, Balance and Fader.

These options can be used to fine tune your sound.

Hold button for 3 seconds to open the menu. Press repeatedly to view menu items.

The mode button allows you to go from one source to another source (f.i. Tuner) by pushing the button as many times as needed.

SD card input

Remove the frontpanel to insert SD card. When inserting a SD card the unit will switch to SD mode. (Max 2GB card, max 1000 tracks)

reset (behind panel)

Use a non-metallic pointed object to press and hold the reset button for 5 seconds. The unit will be set to factory default.

Produkt Specifikationer

Mærke:	Caliber
Kategori:	Bilradio
Model:	MCD 065
Produktfarve:	Sort
Kompatible hukommelseskort:	SD
Equalizer:	Ja
Lyd-output kanaler:	4.0 kanaler
Udgangseffekt:	300 W
Indbygget kortlæser:	Ja
LED-baggrundsbelysning:	Ja
Maksimal effekt pr. kanal:	75 W
Klar til iPod:	Ingen
Equalizerbånd, antal:	4
Understøttede radiobånd:	FM
MP3-afspilning:	Ja
Skærmlys:	Ja
Vigtig belysningsfarve:	Blå
Automatisk digital indstilling:	Ja
Filtype:	MP3, WMA
