Side 1/12

MCD 264BT

English

Short press Long press Short press Long press Short press Long press Short press Long press

1 Power Power off

3 Menu (system)

4 Panel release

6 Eject

9 Mode Mode Mode Answer incoming call

Transfer phone

conversation back

10 Display #9

11 Audio menu

12 AMS (PS) AMS (AS) Pause/play #0

13 Band ENTER

Reject incoming call

/End call

14 Seek down Tune down

Track down Fast backward

15 Seek up Tune up Track up Fast forward #

16 PTY #8

17 AF REG #7

18 TA #1

19 M1 Memory 1 Play/Pause #2

20 M2 Memory 2 Scan File/track up Fast forward #3

21 M3 Memory 3 Repeat File/track down Fast backward #4

22 M4 Memory 4 Shuffle #5

23 M5 Memory 5 down -10 #6

24 M6 Memory 6 up +10

Seek up/down

REG

M1-M6

AMS (PS)

Rotary volume

PTY

AMS (AS)

Menu (system)

Equalizer

Audio menu

Tune up/down

NER

WMA

TEM

Loud

KEY

ota

Power

Eject

Panel release

Band

Mode

Reset

(

behind

anel

)

Repeat

SD card input

USB input

Fast forward/backward

Pause/Play

Track down/up

Shuffle

Scan

Short press to move to the next station automatically

BT A

3,5

mm A

X in

Jac

D Di

Descri

tion of the functions

Push this button to release the frontpanel

Push this button to eject the CD out of the unit

Power function to activate or deactivate the unit.

Band selection allows you to select different reception bands, f.i. FM1, FM2 and FM3

Long press to reinforce the bass output

AF stands for Alternative frequencies; the tuner will return to alternative frequencies whenever the reception signal is getting worse

TA stands for Traffic announcement which means that it will give you information about the traffic (if broadcasted) no matter what mode you are in (CD,USB, etc.) it will

automatically interrupt the cd and give the information, after that it automatically switches back to the selected mode

REG stands for Regional program operation. Long press REG will allow traffic announcement from strong stations to come through. Long press REG again will allow all

received traffic announcement to interupt CD pla

or radio listenin

The PTY function allows you to search for stations with a particular program type like NEWS group and POP group both of these groups are divided in different

subjects.Rotate the volume control to select different PTY as follows:

NEWS -> AFFAIRS -> INFO -> SPORT-> EDUCATE -> DRAMA -> CULTURE -> SCIENCE -> VARIED -> POP M -> ROCK M -> EASY M -> LIGHT M -> CLASSICS ->

OTHER M -> WEATHER -> FINANCE-> CHILDREN -> SOCIAL -> RELIGION -> PHONE IN -> TRAVEL -> LEISURE -> JAZZ -> COUNTRY -> NATION M -> OLDIES ->

FOLK M -> DOCUMENT -> TEST -> ALARM -> NEWS

Long press to move the radio frequency number up/down step by step.

Hold button for 2 seconds to open the menu. Press repeatedly to view menu items TA - PI - Retune - MASK - Beep

The Audio menu button gives you the possibility to adjust your sound system with the following options Bass, Treble, Balance and Fader. These options can be used to

fine tune your sound

The Equalizer button allows you to select your desired audio mode. Press repeatedly to view modes FLAT - CLASSICS - POP M - ROCK M - DSP OFF

The mode button allows you to go from one source (f.i. CD) to another source (f.i. Tuner) by pushing the button as many times as needed

AS stands for Autostore; in tuner mode it will automatically store the 6 strongest stations (M1-M6). Note: all previous stored stations are lost

PS stands for Preset stations this means that when you push this button in tuner mode it will automatically switches to the first preset (M1) if you push again it will go to

the next and so on

This knob allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears

These are the preset stations where you can store your favorite radio stations if in tuner mode

This button allows you in CD, USB or SD mode to play or to pause the music

Scan will play 10 seconds of each song on the CD, USB or SD. If the preferred song is playing, push again and it will play that song

Repeat will play a selected song or album continuously. Available in CD, USB and SD mode

Shuffle will play all the songs random. Available in CD, USB and SD mode

In MP3 mode press this button to go up or down one track

Long press to fast forward to the CD, USB or SD

BLUETOOTH O

en Bluetooth menu b

ressin

and holdin

"Menu" button

To connect an external audio system

When inserting a USB stick the unit will switch to USB mode. (Max 1000 tracks)

Remove the frontpanel to insert SD card. When inserting a SD card the unit will switch to SD mode. (Max 2GB card, max 1000 trac

ks)

Use a non-metallic

ointed ob

ect to

ress and hold the reset button for 5 seconds. The unit will be set to factor

default

3,5mm AUX in Jack

Pairing

Activate BlueTooth on your mobile phone, and search for available devices. Select "Caliber-BT", password "0000". If succesfull "Connected" is displayed, if not "Pairing

Fail!" will be displayed for 3 seconds. The unit will go back to the previous mode.

Reconnect

The unit will normally auto-reconnect.

Transfer

To audio transfer from headunit back to the mobile

hone. Lon

ress the Transfer

(

MODE

)

button to transfer the audio back to

our mobile
