Description of the functions

Panel Release Push this button to release the frontpanel.

Eject Push this button to eject the CD out of the unit.

Power Power function to activate or deactivate the unit.

Band Band selection allows you to select different reception bands, f.i. FM1, FM2, FM3, AM1 and AM2

AF AF stands for Alternative frequencies; the tuner will return to alternative frequencies whenever the reception signal is getting worse.

TA TA stands for Trafc announcement which means that it will give you information about the trafc (if broadcasted) no matter what mode you are in (CD,USB, etc.) it will automatically interrupt the cd

and give the information, after that it automatically switches back to the selected mode

Manual up/down Long press to move the radio frequency number up/down step by step.

Menu (system) Press the VOL/SEL button for several seconds to activate the cyclical mode to choose from the following user instructions:

TA SEEK/ALARM > MASK ALL/DPI > TA VOL > RETURN S/L (Press to enter fuctions)

Audio Menu The Audio menu button gives you the possibility to adjust your sound system with the following options Bass, Treble, Balance and Fader. These options can be used to ne tune your sound.

In EQ mode you can choose from preset EQ settings: FLAT, CLASSIC, POP, ROCK

Mode The mode button allows you to go from one source (f.i. CD) to another source (f.i. Tuner, DAB) by pushing the button as many times as needed.

Rotary volume This knob allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears.

M1-M6 These are the preset stations where you can store your favorite radio stations if in tuner mode.

Pause/Play This button allows you in CD, USB or SD mode to play or to pause the music.

Scan Scan will play 10 seconds of each song on the CD, USB or SD. If the preferred song is playing, push again and it will play that song.

Repeat Repeat will play a selected song or album continuously. Available in CD, USB and SD mode.

Shufe Shufe will play all the songs random. Available in CD, USB and SD mode.

File down/up In MP3 mode press this button to go up or down one folder.

Track down/up In MP3 mode press this button to go up or down one track

fast forward/backward Long press to fast forward to the CD, USB or SD.

3,5mm AUX jack in To connect an external audio system.

USB poort When inserting a USB stick the unit will switch to USB mode. (Max 32GB)

SD card input (behind panel) Remove the frontpanel to insert SD card. When inserting a SD card the unit will switch to SD mode. (Max 32GB card)

Reset (behind panel) Use a non-metallic pointed object to press and hold the reset button for 5 seconds. The unit will be set to factory default.

Key System Tuner DAB CD/MP3/WMA BT Audio Bluetooth

Short press Short press Short press Short press Short press Short pressLong press Long press Long press Long press

1Power Power off

2Rotary Volume

3Menu (audio / system) OK

4Panel release

5Disc slot

6Eject

7LCD display

8USB port

9Mode Mode Mode Answer

incomming call

Transfer

conversation to

mobile phone

10 Display PTYClock set

11 Mute

12 Track scan /

folder navigation

Reject incoming

call/end call

13 Band ID3

14 Seek down Stadion down Track down fast backward Track downManual down

15 Seek up Stadion up Track up Track upManual up fast forward

16 Scan Scan

17 3,5mm AUX In Jack

18 M1 Play/Pause Play/PauseStore M1 Store M1

19 M2 Store M2 Store M2 Intro

20 M3 RepeatStore M3 Store M3

21 M4 Store M4 Store M4 Shufe

22 M5 Folder down Store M5 Store M5

23 M6 Folder upStore M6 Store M6

24 TA

25 AF

Bluetooth

Pairing Activate Bluetooth on your mobile phone, and search for available devices. Select “RCD234DBT Caliber”, password “0000”. If succesfull “Connected” is displayed, if not “Pairing Fail!” will be displayed

for 3 seconds. The unit will go back to the previous mode.

Reconnect The unit will normally auto-reconnect.

Reject incomming call Press (F/PS) button if you not wish to answer the call, and return to normal playing mode.
