32 OZ. SAUCE BOTTLE WARMER
Introduction
This warmer is designed for commercial use only and is not intended for residential use. It would be operated by
trained individuals. Be sure to read the operation and safety manual before using to ensure unit functionality and
safety of users.
Sauce bottle warmers are perfect for buffets, salad bars, dessert bars, ice cream and frozen yogurt shops to keep
sauces, toppings and dressings at the perfect temperature for serving. The individual adjustable wells allow precise
co
ntrol for a large array of contents. The warmers feature an angled control panel for use in normal countertop or
drop-in installations to ensure functionality in any environment.
Note: Use bottles that have a minimum heat resistance of 200°F or higher. Check with the manufacturer of your
bottles to Ensure they can be used in a bottle warmer.
Operating Instructions
Caution: Do not operate unit without water – check water level frequently when in operation and apply more water as needed.
Using to
o much water will overflow the well when bottles are used, and not enough water will not allow even heating of the sauce
bottle and its contents.
Caution: Do not submerge heating element or any electrical components in water. To avoid overfilling, place your sauce bottles in
the warmer and fill the well with water up to ½” below the rim of the warmer.
Sauce bottle warmers are intended to be used with sauce bottles of 32oz. or smaller to heat the contents for easy disp
ensing and
dressing.
1. Place preferred sauce bottles in each well.
2. Fill warmer with hot water, leaving a ½” gap between the top of the water line and the warmer rim.
3. Fill sauce bottles with food product and place in warmer.
4. Turn the temperature knob to the desired temperature.
5. Allow content to pre-heat to desired temperature, and adjust thermostat to desired holding temperature.
Cleaning and Storage
Clean and dry the heating unit after each use. Use soft cloth and mild soap on exterior. Do not use metal scouring pads,
strong abrasives or detergents on exterior. These however can be used on the interior of the wells when necessary.
Sauce Bottle Warmer Specs
Item # # of Bottles Temperature Range Wattage Voltage Dimensions
382SBW1 1 x 32 oz.
105-195°F
200W
120V
6.5”W x 9”D x 8”H
382SBW2 2 x 32 oz. 400W 10.5”W x 9”D x 8”H
382SBW3 3 x 32 oz. 600W 16”W x 9”D x 8”H
382SBW4 4 x 32 oz. 800W 21”W x 9”D x 8”H
