Christie Xenolite

lamps

and Christie Solaria

™

Series projectors

Usage best practices

How to calculate the amount of light required

The basic formula to calculate this theoretical light requirement is:

 Lumens (L) = Average Screen Brightness desired (average fL)

X Screen Area (sq ft)

• Givenagoodlightdistribution,the“AverageScreenBrightness”

canbeestimatedbymultiplyingthecenterbrightnessdesiredby

0.95.Generallyacceptedpracticeforthetargetcenterbrightness

is:14fLfor2Dand4.5fLfor3D(lightmeasurementtakenthrough

3Dglasses).

 Afteryouhavethe“Lumens”numberyouwoulddivideitbyall

signicantsystemefciencies.Someexampleswouldbe:

•

Screengain:1.0to2.4.Silverscreensare2.4.Thisisaveryimportant

partofthisequationandcareshouldbetakentomakesurethis

numberisaccurate.Ifthescreeninquestionisnotnewthenthe

overallgainshouldbemeasuredproperly.Anydegradation

ordebrisonthescreenwillreducethescreengain.

• Portwindowefciency:96%efciencyistypicalforgoodportglass.

• LossduetocolorcorrectionrequiredformeetingDCIcolor

specications:97%efciencyistypical.

• 3Dsystemlightefciency:thisnumbercanbeanywhere

from10%to30%efciencydependingonthe3Dsystemused.

• Othereffectslikedownangleandscreencurvedomakea

differenceforlightdistributionbuttheyonlyeffectthese

calculationsiftheyareexcessive.

 Calculation:Lumens Required (L) = Lumens (L) / (Screen Gain X Port

Window Efﬁciency X Color Correction Efﬁciency X 3D Efﬁciency)

 Theresulting“LumensRequired”numberyougetwouldbethe

“MINIMUMlumenrequirement”tomeetthedesiredlightlevels.

How to select the right projector/lamp combination

that will provide enough light to satisfy screen

brightness requirements

Thereshouldbeenoughbrightnessavailableevenattheendof

thelamp’slifetomeetyourspeciedcenterbrightnessrequirement.

Yourcompany’slampchangingpolicymayneedtobereviewedto

makethisdecision.

 Thereisanaturalbrightnessdrop-offthatoccurswithanyXenonlamp

duringitslife.Thisbrightnesscurveistypicallysharpatthebeginning

ofthelamp’slifeanddropsslowerafterthisinitialperiod.Leaving

thelampat100%powerthroughoutitslifewouldgivethistypical

brightnesscurve:

Lamp life

Starting lamp at 100% power

Maintaining lamp at 100% power

Point at which

brightness is

unacceptable

Approximately

50% brightness

100% Rated

brightness

(lamp/projector

combination)

Brightness

 Thisinitialdrop-offinbrightnessismainlyduetothere-shapingofthe

electrodesinsidethelamp.Thearcbetweentheelectrodesinsidethe

lampwillmoveslightlyduringthisperiod.Re-aligningthelampoften

canminimizethisdrop-off.Thisre-alignmentshouldbedoneatleast

everytimetheequipmentisserviced.Themorefrequentthisisdone,

themorelightefciencycanbepreserved.

 100%Ratedbrightnesswouldindicatetheuseofanewlamprunning

at100%power.

USAGE BEST PRACTICES

Optimize your Christie

digital cinema system

ChristieXenolite

lampscanproduceremarkablebrightness

andcolorconsistencywithexcellentresistancetoicker,

ignitiondifcultyandexplosion.Withthissuperiorperformance

comesgreateconomy.Herearesomeusageguidelines

thatcanbeappliedtogetoptimumperformancefromthe

ChristieXenolitelampandChristieSolaria

™

Seriesprojector

combination.Ifyouneedtechnicalsupporttohelpyou

withthis,pleasedonothesitatetocontactChristie

technicalsupport.

Produkt Specifikationer

Mærke:	Christie
Kategori:	Projektor tilbehør
Model:	CDXL-45
Antal pr. pakke:	1 stk
Pæreeffekt:	4500 W
Lampens levetid:	1200 t
Indgangsspænding:	31.5 V
Kapabilitet:	CP2000-ZX, CP2000-SB and the CP2000-XB
Mærke kompatibilitet:	Christie
