APX480M manual.qxd 3/12/2004 1:07 PM Page 1

APX480M Power System Amplifier

INTRODUCTION

The Clarion APX480M is a full-featured four-channel amplifier incorporating

the following features:

•Specially coated circuit boards, that resist mold, mildew and moisture

damage.

•Pulse-Width Modulated (PWM) MOSFET power supply for maximum

performance with minimal distortion.

•Remote turn-on with "soft start" muting to prevent turn-on "thump".

•Advanced circuitry design featuring bridgeable and mixed mode operation

for use in various system configurations including 4, 3, or 2 channel

systems.

•Variable high-pass/low-pass electronic crossover with a 12dB per octave

slope (adjustable range: 55Hz to 5.5kHz).

•Variable bass boost circuit to reinforce low frequency signals that may be

lost due to subwoofer enclosure design.

•Adjustable input level controls with ground loop isolation to minimize noise

and distortion.

•2-ohm stereo stable, 4-ohm mono stable.

•Gold-plated power, speaker, and RCA connectors.

•Speaker level input.

•Low profile construction with aluminum heat sink for efficient heat

dissipation.

ABOUT THE MANUAL AND WARRANTY

This manual describes the basic requirements to install the Clarion

APX480M amplifier. The installation of this amplifier can be quite complex to

install, if you do not posses the necessary knowledge and tools to perform

this installation, please contact your local Clarion dealer.

Keep all instructions and sales receipt for future reference and warranty

information. Warranty information can be found on page 11 of this manual.

TABLE OF CONTENTS

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Input Connections and Audio Controls . . . . . . . . . . . . . . 1

Connections for Power and Speakers . . . . . . . . . . . . . . . 3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Mounting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Wiring Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Wiring and Applications . . . . . . . . . . . . . . . . . . . . . . . . . 5

Setting the Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Setting the Crossover . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Setting the Bass Boost . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Final System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Product Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Clarion Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . 13

APX480M manual.qxd 3/12/2004 1:07 PM Page 2
