Thank you for purchasing our CSV-1566 Product.

After unpacking the product, please make sure you have all the

items provided and checked for any damages. In case of any missing/

damaged parts please inform your supplier immediately.

You should have:

• CSV-1566 Docking Station

• PowerSupply 120W

• 1x USB TypeC cable, 1x connection to Host(1m / 3.28ft) M/M

• Quick Install Guide

Please make sure your Host System has the latest drivers updates

installed from our website www.Club-3d.com you can ﬁnd whether

you need drivers under the product code : CSV-1566 Downloads on

our website.

1. Please connect the black USB type C cable and connect it to the

connector on the Dock marked “To Host” , connect the other side

of that cable to the USB Gen1 Type-C port of your NoteBook/Host

system.

2. Connect your preferred Display(s) to the designated connector(s)

and power on your Display unit(s) , peripherals, ethernet and/or

sound devices

3. Connect the Power cable from the Power Charger into the

designated, , connector on the Dock.DC in

4. Now Plug the Power Supply in a wall socket and switch the Dock

ON, the should be lit !Purple indicator

Note: BLUE The indicator on the Dock is when in Stand-By mode !

No need to connect your Host system to the Power Charger, our Dock

will Dynamically Charge your Host system up to 80Watts.

You’re ready to start working and enjoy the full beneﬁts of our Dock.

CSV-1566 QUICK INSTALLATION GUIDE

USB type C cable

Bottom design:

which allows to put this

dock underneath the host.

PowerSupply 120W

CSV-1566

CSV-1566 QIG Rev. September-2021

For any Questions please check our forum section on our website www.club-3d.com

USB-A

Smart

Charging

Connect DC in

to adapter

USB-C To Host

Connect the USB

Type C cable to

your laptop
