Hose Reel
Art.no 31-5288 Model Automatic 40 m
Please read theentire instruction manual before use and save
it for future reference. Wereserve theright for any errors in text
or images and for making any necessary technical changes to
this document. Ifyou should have any questions concerning
technical problems please contact our Customer Services.
Safety
Warning:
• Please read theentire instruction manual before using
theproduct and save it for future reference.
• This hose reel is not atoy; do not let children play withit.
• If thehose is to be replaced, both thesafety locks and
thehose brake must be engaged.
• The hose reel must be stored protected from freezing
conditions. Theguarantee does not cover damage caused
by freezing.
Disposal
This product should be disposed of in accordance with local
regulations. Ifyou are unsure how to proceed, contact your
local authority.
Specifications
Hose 40 m (PVC), Ø ½″ (12 mm)
Max pressure 1.0 MPa (150 psi)
Coupling thread ¾″ NPT
Size (L×W×H) 53×26×46 cm
Product description
Safe hose replacement
1. Wallbracket
2. Hosecoupling holder
3. Hoselock mechanism
4. Metalhandle
5. Hosebrake
6. Safetylocks, for use during hose replacement
7. Hosecoiling guide
8. Nozzleholder
3. Foldout thesafety
locks (6) (one
on either side
of opening) and
push them into
thecorresponding
retainer holes on
thereel drum.
Thereel drum is
now locked and
thehose can be
safely replaced.
4. Unscrew thestrain
relief and remove
thequickcoupling.
Remove
theoldhose.
1. Openthelid on top
of thehosereel.
2. Uncoiltheentire
length of thehose
and then let it
rewind slightly,
thus locking it and
preventing it from
rewinding fully.
5. Fitthequick coupling onto thenew hose and connect
it to thecorresponding quick coupling on thehose reel.
Screwthestrain relief backon.
6. Pullout thesafety locks and push them into theretaining
holes located in thereel drum. Shutthehose reellid.
Useful tips
• The hose is equipped with abrake to help adjust thehose
to thedesired length: Pullthehose out of thereel and
carefully release some tension to activate thehosebrake.
• The hose must not be under pressure when it is rewound
onto thereel: Closetheair inlet and leave thenozzle open
before rewinding thehose.
• Pull thehose out about 20 cm and then release it and let it
rewind automatically.
