SAFETY WARNING
It is strongly recommended to read all the instructions, contra-
indications and safety measures carefully before using the device.
The complete user manual can be found at www.compex.com
1. DEVICE DESCRIPTION
A On/o button or Pause button
during stimulation
B Power and battery LED indicator
C Program button (only available
on COREBELT 1.0), to select the
program P1 or P2
P1 rst LED solid green
P2 rst and second LED solid
green
D +/- intensity buttons, to increase
or decrease the stimulation
intensity
E Stimulation LED indicator
F Charger socket, plug in the USB
cable to charge the device
A
B
C
E
D D
E
A Holster
B Notches to facilitate the positioning of the belt on the back
C Elastic strap to avoid having any loose ends of the belt hanging down
D Metallic pins, electrodes must be positioned over these metal pins
E Self-fastening area to adjust the size of the belt
A
D
E
F
B
C
Make sure the device is
charged before using it (green
LED).
If the device is not going to
be used for over 3 months,
ensure that the battery is
fully charged.
3. SET TING UP THE BELT
Setup the size of your belt by measuring your
waist circumference and seeing which belt
number it matches to.
S/M belt Attachment
area L/XL belt
65 - 67 cm 0 85 - 87 cm
67 - 72 cm 1 87 - 94 cm
72 - 78 cm 2 94 - 100 cm
78 - 84 cm 3 100 - 107 cm
84 - 85 cm 4 107 - 113 cm
- 5 113 - 114 cm
Tips: How to measure the waist circumference?
Stand up straight, place the tape measure at the level of your
belly button and wrap it around your waist. Hold the tape
measure against your body, not too tight, and take a reading.
Adjust the belt by positioning the internal attachment on belt
number found on the previous step.
Then adjust the other side external attachment and bend the
belt to get a S-like shape.
Check if the adjustment is okay by placing
the center of the back belt on your spinal
cord. The notches on the belt facilitate the
positioning.
