Side 1/4
EOC-KVMUSA1
Installation Guide
TM
Professional Video + Serial + Audio KVM extender over CATx cable up to 1000 ft.
Transmitter Receiver
EOC-KVMUSA1-T EOC-KVMUSA1-R
Standard
Packing List
Wall Mounting Kit x 2
IR Remote Controller
RC-02
WMK-01
Video IR Remote Contro ller
/
-
RC 02
1
3
2
ALL
ON / OFF
4
Skew
R
G
B
Port
+
Ordering Information
Connect power adaptor
1 2 3
Connections at the transmitter ( EOC-KVMUSA1-T )
Connections at the receiver ( EOC-KVMUSA1-R )
4 5 6
Connect the link Cat.5
cable
Connect video input from
the source PC system
Connect audio input from
the source PC system
Connect with a local monitor Connect
speaker amplifier
with a local
1 2 3
Connect power adaptor
Connect video output
with device / monitor
Connect audio output with
device / speaker amplifier
4 5 6
Link Cat.5 cable
Skew brightness and focus
7
Installation
Application Connection Diagram
Legend
CATx Cable
Product View
EOC-KVMUSA1-T
EOC-KVMUSA1-R
165 mm ( 6.5 inch )
27 mm
( 1.06 inch )
85 mm
( 3.35 inch )
EOC-KVMUSA1-T
EOC-KVMUSA1-R
165 mm ( 6.5 inch )
27 mm
( 1.06 inch )
85 mm
( 3.35 inch )
DC
5V in
EO
C-
KVMU
SA-R
IR
Br
ight
ne
ss
Fo
cu
s
Sk w Tun
in
g
e
G
R
B
Ca
t
.
5
S
L
Receiver
EOC-KVMUSA1-R
300 M / 1000 ft.
Transmitter
EOC-KVMUSA1-T
Computer
or
other devices
3-ft Male-to-Male
Video Cable x 1
3-ft Stereo
Audio Cable x 1
CMV-202-03
CAS-202-03
4-ft USB A-to-B
cable x 1
CRJ45-DB9F-5
5-ft RJ45-to-Serial
cable x 1
UC-AB-04
Optional part / accessory
Power Supply DC 5V 1A x 2
3A-041WU05 ( US )
7 8
Switch to select mode :
V+U mode : orange LED on
V+A mode : orange LED flash
EOC-KVMUSA1-T & EOC-KVMUSA1A-R
EOC-KVMUSA1
Model
Description
Cables
3-ft Male-to-Male video cable
IR Remote Controller
RC-02
Power Adaptor
IR remote controller for Video / Audio Solution products
Power supply DC 5V ( 1000 mA ) - AC 100-120 / 220-240V for USA
CAS-202-03 3-ft Stereo audio cable
Wall Mounting Kit
WMK-01
Wall mounting kit
CMV-202-03
PAUS-DC5V1A
PAEU-DC5V1A
* Any other interface is available up on request
4-ft USB A-to-B cable
CRJ45-DB9F-5 5-ft RJ45-to-serial cable
UC-AB-04
Power supply DC 5V ( 1000 mA ) - AC 100-120 / 220-240V for Europe
VG
DC
A + D
aLoc
l IN
5V DC i
n
O
- MU
-
E
C
KV
SA
1
T
Se alri
USB
U
dp
ate
M
do e
V+U T
( )
V+A T
(
)
V+U+A R
( )
9
Console selection :
T only : only console in transmitter
can be operated
T+R : consoles in both transmitter
and receiver can be operated
If necessary ; use I.R
remote controller to fine
tune R.G.B skew
Skew R.G.B tuning
8 9
Connect USB output with
device / touch monitor
Set DDC in transmitter :
Red LED on : DDC in receiver is stored
Red LED off : DDC in transmitter is stored
Connect USB input from
the source PC system
IG-EOCKVMUSA1_V2-1
13F., No.120, Sec. 1, Sanmin Rd., Banciao Dist.,
New Taipei City 220, Taiwan, R.O.C.
Tel +886-2-8964-2700 Fax +886-2-8964-2977
20525 Paseo Del Prado Walnut, CA 91789, USA
Tel +1-909-444-9288 Fax +1-909-444-9289
Corporate Office
Design Center and Operational Hubs
ConnectPRO - USA, Taiwan
www.connectpro.com
TM
ConnectPRO offers a 1 year limited warranty for all of its Video / Audio Solution
products. ConnectPRO stands behind its products assuring that you've purchased a
proven technology with quality and reliability.
Limited Warranty For ConnectPRO Video / Audio Extender
Unit Input & Output View Specification
5V DC in
IR
Bright ness Focus
Skew Tuning
GR B
Cat.5
S
L
EO C- KV MUSA1 -R
5V DC in
VGA + DDC
USB
Seria l
EO C- KV MUSA1 -T
Mode
( )
V+U T
( )
V+A T
( )
V+U/A R
Updat e
EO C- KV MUSA1 -T
Conso le
T only
T + R
VGA + DDC
Cat.5
( )
T / R
DDC
( )
R
VGA + DDC
Seria l
EO C- KV MUSA1 -R
Updat e
USB
Transmitter Unit - Output
Receiver Unit - Output
Receiver Unit - Input
Transmitter Unit - Input
EOC-KVMUSA1-T
DC jack
RJ-45 Cat.x connector
RJ-45 Cat.x indicator
(L) Green flash = Cat.x not connected
Green not flash = Cat.x connected
(R) Orange flash = V+A mode
Orange not flash = V+U mode
Cat.x cable length
L = Long
S = Short
Brightness
Focus
IR indicator
IR receiver
Video red color skew
Video green color skew
Video blue color skew
EOC-KVMUSA1-R
DC jack
USB update
VGA input
Audio input
( Stereo audio 3.5 mm )
Input signal mode
V+U= VGA+USB
V+A = VGA+Audio
V+U/A = VGA+USB/Audio
Serial port control
USB
USB 2.0 connections for
mouse and keyboard
Console indicator
Console switch
Audio output
( Stereo audio 3.5 mm )
VGA output
RJ-45 Cat.x connector
RJ-45 Cat.x indicator
(L) Green flash = Cat.x not connected
Green not flash = Cat.x connected
(R) Orange flash = V+A mode
Orange not flash = V+U mode
DDC button
DDC button indicator
USB update
USB complies 2.0 HID devices DDM
connections for mouse and keyboard
Serial port control
Audio output
( Stereo audio 3.5 mm )
VGA output
EOC-KVMUSA1-T EOC-KVMUSA1-R
0 to 60 °C ( 32 to 140 °F )
-30 to 70 °C ( -22 to 158 °F )
0~80% RH, NC
( )
DC 5V 1000 mA
50-60 Hz
AC 100-120 / 220-240V
27 x 165 x 85 mm ( 1.06 x 6.5 x 3.35 inch )
430 g ( 0.95 lb )
Mechanical
Environmental
Certification
Supported
Ports
Connector
Dimensions H x W x D
Weight
Operating temp
Storage temp
Humidity
Operating voltage
Power frequency
Input power
Stereo audio
Resolution
DDC
VGA
Input
Output
HDB-15 Female x 1
Stereo Audio Jack x 1
1920 x 1440
Stereo audio 3.5 mm
DDC , DDC2 , DDC2B
VGA , SVGA , XGA , SXGA , UXGA , QXGA
FCC, CE
HDB-15 Female x 1
DB-9 Female x 1
USB B x 1
RJ-45 / 8P8C x 1
USB A x 2
HDB-15 Female x 1
j
Stereo audio ack x 1
USB A ( DDM Technology ) x 2
RJ-45 / 8P8C x 1
j
Stereo audio ack x 1
DB-9 Female x 1
Focus adjustment tune x 1
Brightness adjustment tune x 1
RGB adjustment tune x 1
440 g ( 0.97 lb )
