Features Specifications & Packing Information
The MasterLiquid ML360P Silver Edition is
Cooler Master’s newly optimized liquid cooler to
ensure maximum performance and elegant
aesthetics. Cooler Master has re-designed the
Dual-Chamber pump outlook into a sleek
aluminum finish. The ML360P Silver Edition is
employed with Cooler Master’s custom 360mm
low resistance radiator which allows for a
higher flow rate and enhances heat exchange
efficiency /performance. In addition, the new
integrated Addressable RGB 360mm fan design
allows for easy installation and enhances cable
management. The aluminum Addressable pump
design will definitely differentiate your PC from
the rest.
Aluminum Pump Design – Addressable RGB
aluminum pump designed for a sleek
aesthetic and exceptional performance
360mm Radiator - Our aluminum 360mm
large surface radiator will remove excess heat
from the CPU and cool with maximum efficiency.
Integrated Fan design - By combining three
120mm fans into one integrated unit for a quick
and painless install
Fewer wires to worry about - Easy cable
management with just 2 connectors for the
integrated 360mm fan design
Addressable RGB LED Lighting - This all-in-
one liquid cooler comes with Addressable RGB
LED lighting design on the pump and fans that is
certified to sync with Motherboard RGB software
or controlled by our controller
Exclusive Wired ARGB Controller- Allows you
customize colors even without RGB Motherboard.
MasterLiquid ML360P Silver Edition
EAN code 4719512088227
UPC code 884102060670
Net weight (Kg) 1.742
Gross weight (Kg) 2.440
Carton dimension (L x W
x H)
57.5*45.7*26.5cm
Cont. W/ Pallet
Carton/
Pallet
W/O Pallet
20’ 960 24 N/A
40’ 1920 24 N/A
40 HQ 2240 28
N/A
Product
Name ML360P Silver Edition
Product Model MLY-D36M-A18PA-R1
CPU Socket
Intel® LGA 2066 / 2011-
v3 / 2011 / 1151 / 1150 /
1155 / 1156 / 1366 /
775
AMD TR4 /AM4/ AM3+ /
AM3 / AM2+ /AM2 /
FM2+ / FM2 / FM1
Waterblock Dimensions
82.9×72×52.9mm(3.3×2
.8×2.1 inch)
Radiator Dimensions
394×119×27.2mm(15.5
×4.7×1.1 inch)
Radiator Material Aluminum
Fan Dimensions
360×120×25mm(14.2×4
.7×1 inch)
Fan Speed 650~1800 RPM
Fan Air Flow 45 CFM±10%
Fan Air Pressure 1.58mm-H2O ±10%
Fan MTTF 160,000 hours
Fan Noise Level(1m) 8-30 dBA
Fan Connector 4-Pin(PWM)+ARGB 3Pin
Fan Rated Voltage 12VDC
Fan Rated Currrent
0.32A
（
LED 1.2A
）
Fan Power Consumption
3.84W
（
LED7.2W
）
Fan led color ARGB
Pump MTTF 70,000 hours
Pump Noise Level(1m) <15dBA
Pump Rated Voltage 12VDC
Pump Power Consumption pump 1.3W ( LED 2.0W)
Connector 3PIN
