Side 1/7
FUCILI
GUNS
FUSILS
FUSILES
4
Congratulations! The product you purchased, which is the result
of continuous research and development, is made in compli-
ance with CRESSI-SUB quality standard, thus ensuring long reli-
ability and duration.
The "SL" series guns are manufactured
in the following versions:
SL STAR 40 - SL STAR 55 - SL STAR 70;
SL 55 (with reducer) - SL 70 (with reducer)
SL 100 (with reducer).
1. Description.
WARNING
Read carefully this user's manual before using the
gun, and store it for future reference.
This type of guns can be called of "air spring" type since the
arrow (N.° 13 - table 8) propulsion is obtained through compres-
sion of the air contained in the gun tank (N.° 6 - table 8), which
takes place each time the gun is charged. In fact, when the rod
(N.° 13 - table 8) is fitted into the gun barrel (N.° 7 - table 8), the
piston (N.° 4k - table 8) is pushed across the barrel (N.° 7 - table
8) and the pressure inside the tank (N.° 6 - table 8) increases
until the piston remains coupled to the release mechanism
(N.° 12k - table 8). Now, if the trigger is pulled (N.° 19k - table 8),
the piston is free, and it receives the violent air expansion running
across the barrel (N.° 7 - table 8) until it stops against the damp-
ing bushing (N.° 16k - table 8), thus releasing the rod
(N.° 13 - table 8) which is held inside the piston simply through
friction. Then, the compressed air, by expanding upon firing, pro-
vides the power required for firing, thanks to the energy stored
when charging the arrow.
The SL series guns, designed for underwater fishing, are water-
tight and compressed-air operated. Lightweight and balanced,
they can be easily handled thanks to their anatomical handle to
the whose base the buoy line can be fastened.
In the water, when the arrow is charged, they are lightly negative
whereas they float after firing, except for the SL 40 model.
A small quantity of oil is introduced in the gun to lubricate its inter-
nal parts.
The lightweight and self-concentrating piston ensures improved
arrow accuracy and speed.
The gun, which is supplied ready for use with the required quan-
tity of lubricant and with compressed air at the recommended
medium pressure of 18-20 bars, is provided with an 8-mm rod.
In models fitted with power reducer, the gun can be used at its
maximum pressure (FIG. 2 - "MAX" position or at its reduced
pressure (FIG. 2 - "reduction" position), depending on the firing
type chosen, at either maximum or reduced power. You can also
make arrow charging easier by turning the reducer lever to the
"reduction" position.
The SL guns are also provided with an automatic trigger-operat-
ed line release mechanism (n° 11K - table 8).
2. How to charge the gun.
WARNING
Do not charge or discharge the gun in the air! Carry
out these operations only in the water in order to
guarantee your safety, and not to damage the gun!
Never fire from air to water!
To charge the gun, first turn the safety on (N.° 17 table 8), then
lay the handle on your thigh or foot, and fit the arrow into the bar-
rel using the handle magazine supplied, keeping firmly the muz-
zle with your free hand (FIG. 1), and pushing the rod until the pis-
ton couples to the release mechanism.
The guns provided with pressure reducer allow to charge the
arrow more easily, by turning the reducer lever to the "reduction"
position, as shown on FIG. 2.
