Side 1/3

quickstart guide

C2N(I)-AMP-4X100

www.crestron.com

Specifications subject to

change without notice.

C2N(I)-AMP-4X100

For Regulatory Compliance information, refer to the latest version

of Doc. 7289.

QUICKSTART DOC. 7288B (2032394, Sheet 1 of 2) 04.13

4 Room Audio System

Make the necessary connections as called out in the diagram below. Connect power last.

Hardware Hookup

NOTE: SPEAKER OUTPUTS For triple the power (into 8 speakers only), Ω 1

and 2 or 3 and 4 can be bridged. For example, the left SPEAKER OUTPUTS

speaker’s + and - terminals are connected to the two + terminals of output #1

and the right speaker’s + and - terminals are connected to the two + terminals

of output #2. Refer to the diagram to the right.

To adjust volume when bridged, select 1 for 1 ROOM SPEAKER OUTPUTS

and 2 or select 2 for 3 and 4.ROOM SPEAKER OUTPUTS

RM 1

RM 3

RM 2

RM 4

BRIDGE

8 OHMS ONLY +-

L+-+-R

To Cresnet Devices

NET

From AC Power Line

PWR

Tie to Ground

From Unbalanced Stereo Line Level Audio

Outputs from Source Devices

ANALOG SOURCES (IN)

To Additional Amplifiers

ANALOG SOURCES (OUT)

NOTE: NET The 24 volt lines on the ports of the amplifier are

limited to 300 mA.

To Loudspeakers

SPEAKER OUTPUTS

NON-BRIDGE

L+-+-R

+ - + -

LEFT RIGHT

NOTE: The C2NI-AMP-4X100 (International

version) requires a power cord that is

harmonized to the country’s national and local

electrical codes. Each inner wire in the cord

should be at least 18 AWG (0.75 mm

2) and rated

for at least 300 V. The temperature rating of the

cord should be at least 60º C. The cord length

should be 1.5 - 2 meters.

To Cresnet® Devices

LOOP THRU

2Attach the Labels

Use the included labels and inserts to prepare the C2N(I)-AMP-4X100:

1. Locate the and label inserts included with the unit ( insert has space for six labels, insert has room for four labels).SOURCE ROOM SOURCE ROOM

2. Apply the peel-and-stick labels in the appropriate positions on the inserts, being careful to match label positions to what is configured in the programming software. For neatest appearance, when applying a label,

cover the white guidelines on the insert. First and last labels cover one line each; labels in between cover lines on their left and right sides.

quickstart guide

C2N(I)-AMP-4X100

www.crestron.com

Specifications subject to

change without notice.

C2N(I)-AMP-4X100

For Regulatory Compliance information, refer to the latest version

of Doc. 7289.

QUICKSTART DOC. 7288B (2032394, Sheet 1 of 2) 04.13

4 Room Audio System

3Establish Communication

The port on the C2N(I)-AMP-4X100 connects to the control system via Cresnet:NET

1. In Crestron Toolbox, click Tools System Info| .

2. Click the icon.

3. For Connection Type Cresnet ID Through , select . In the drop-down menu, select

the control system that is connected to the device.

4. Click OK. Communications are confirmed when the device information is

displayed.

The Net ID of the C2N(I)-AMP-4X100 has been factory set to . The Net IDs of 33

multiple C2N(I)-AMP-4X100 devices in the same system must be unique. Net IDs are

changed from a personal computer (PC) via Crestron Toolbox (refer to “Establish

Communication” in section π).

Net ID

Turn the Amplifier On or Off

To turn the amplifier on, move the front panel switch to the position.ON

To turn the amplifier off, move the front panel switch to the position.OFF

Select a Source

To select a source for distribution, press the desired button. If a room is connected to the selected source, SOURCE

its LED lights.

NOTE: If a room is in Volume Control mode, press a button to exit the mode.SOURCE

Select a Room

Once a source is selected, press any button that is to receive the selected source. The room is connected to ROOM

the selected source and its LED lights.

To remove a room from the selected source, press the button of a connected room. The LED turns off.ROOM

NOTE: If a room is in Volume Control mode, press a button to exit the mode.ROOM

NOTE: ROOM 1 ROOM 2 If the outputs of the C2N(I)-AMP-4X100 are bridged, the button acts in unison with the

button and the button acts in unison with the button. Similarly, the LED acts in unison ROOM 3 ROOM 4 ROOM 1

with the LED and the LED acts in unison with the LED.ROOM 2 ROOM 3 ROOM 4

Volume Control Mode

The volume level of a connected room can be controlled when the room is in Volume Control mode. To switch to

Volume Control mode:

1. Press and hold the button of the room to be controlled for 2 seconds.ROOM

• Press j k or to change the volume in 1 dB increments.

• Hold j k or for more than 1 second, to ramp the volume up or down in 1 dB/0.1 second

increments.

If the maximum volume or minimum volume is reached, all of the front panel LEDs blink three times.

2. Press the button again to exit ROOM Volume Control mode.

If j k or is not pressed for 10 seconds, the amplifier automatically exits Volume Control mode.

Operation

LAN

COMPUTER

PWR NET HW-R SW -R ACQUIRE ACTIVITY

MC3

123456

ANALOG SOURCES

CAUTION

RISK OF E L ECT R IC SHOC KDO NOT OPEN

AVIS: RISQUE DE CHOC EL E C T R IQUE NE PA S OUV R IR

CAUTIONDISCONNECT AC POWER

BEFORE CONNECTINGSPEAKERS AND PERIPHERALS

SPEAKER OUTP UTS

ELECT RONICS I NC. ROCKL EI GH N.J . 0 78 4 7 US A

LOOP THRU

NET

L R L R L R L R L R L R

OUT

L + - + - R

L + - + - R L + - + - R

24 Y Z G

24 Y Z G 24 Y Z G 24 Y Z G 24 Y Z G

POWER 24VDC 5W/PORT CLASS 2

8Ω 50W 4Ω 75W CLASS 2 WIRING

120V

50Hz400W

Use Crestron Toolbox™ to communicate with the C2N(I)-AMP-4X100. Refer to the

Crestron Toolbox help file for details.

There is a single method of communication: Indirect communication.

NOTE: Required for setting the Net ID and loading firmware.
