Side 1/2

C3COM-3/C3IO-16/C3IR-8/C3RY-16/C3RY-8

3-Series® Control Cards

Installation Guide

Additional Resources

Visit the product page on the Crestron website

(www.crestron.com) for additional information and the

latest rmware updates. Use a QR reader application on

your mobile device to scan the appropriate QR image.

C3IO-16C3COM-3

C3IR-8 C3RY-8

C3RY-16

1 A ground terminal connection is recommended but not

required. Ground potential difference must be under +/-4 v.

Description

Crestron® 3-Series® control cards are designed to install

into a control card expansion slot of a 3-Series Control

System® device (PRO3 or AV3). The cards can also be

installed into a 3-Series Card Interface device

(CEN-CI3-1 or CEN-CI3-3).

NOTE: The AV3 requires the CAGE3 Control Card

Expansion Cage accessory to enable use of 3-Series

control cards.

NOTE: 3-Series control cards are not compatible

with the 2-Series PRO2, AV2, or PAC2 models. Even

when installed in the CAGE3 Control Card Expansion

Cage, the cards are not compatible with any 2-Series

control system.

Installation

Items required to install the 3-Series control cards are

already attached to the unit. The only tools required

are a Phillips screwdriver and a grounding strap. To

install the control card, follow the procedure below.

CAUTION: 3-Series control cards contain

electrostatic-sensitive devices (ESD); observe

precautions for handling ESDs to avoid damaging the

card.

NOTE: If the card is being installed into an AV3,

ensure that the CAGE3 Control Card Expansion Cage

accessory is installed before completing this

procedure.

1. Disconnect power from the control system.

2. Use the Phillips screwdriver to remove two

screws and the blank faceplate from the control

system.

3. Align the 3-Series control card guides in the open

slot and slide the control card into position.

4. Firmly press on both ends of the 3-Series control

card faceplate to seat the control card into the

control system connector.

5. Tighten the thumb screws to secure the 3-Series

control card to the control system.

6. Reapply power to the control system.

C3COM-3 Wiring Connections

The C3COM-3 provides three bidirectional

RS-232/422/485 ports (COM 1−3). Refer to the

following table when making connections to the

C3COM-3.

C3COM-3 Pin Out

PIN RS-232 RS-422 RS-485

G GND GND GND

TX TX TX- TX-/RX-

RX RX RX+ (Not Used)

RTS RTS TX+ TX+/RX+

CTS CTS RX- (Not Used)

Troubleshooting

The following table provides corrective actions for

possible issues that may arise. If further assistance is

required, please contact a Crestron customer service

representative.

3-Series Control Card Troubleshooting

TROUBLE POSSIBLE

CAUSE(S)

CORRECTIVE

ACTION

The control

card does

not function.

The control

system is not

receiving

power.

Verify the

power to the

control

system.

The control

card is not

properly

seated in the

slot.

Verify that the

control card is

properly

inserted into

the control

system slot

per the

procedure in

this guide.

There is a

loss of

functionality

due to

electrostatic

discharge.

The control

system is

improperly

grounded.

Check that all

connections to

the control

system have

been properly

made.

C3RY-8/C3RY-16 Wiring Schematics

The C3RY-8 and C3RY-16 provide two terminal blocks

that contain eight normally open, isolated relays

(rated 1 amp, 30 volts ac/dc). Refer to the following

diagrams when making connections to the C3RY-8 or

C3RY-16.

C3RY-8 Wiring Schematic

1 2 3 4 5 6 7 8

C3RY-16 Wiring Schematic

12 3 4 5 6 7 8 C

A B

12 3 4 5 6 7 8 C

As of the date of manufacture, the device has been tested

and found to comply with specications for CE marking.

These products are Listed to applicable UL

® Standards and

requirements by Underwriters Laboratories Inc.

Ces produits sont énumérés aux normes applicables et les

exigences UL par Underwriters Laboratories Inc.

Federal Communications Commission (FCC) Compliance

Statement

CAUTION: Changes or modications not expressly approved

by the manufacturer responsible for compliance could void

the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV

technician for help.

Industry Canada (IC) Compliance Statement

CAN ICES-3(B)/NMB-3(B)

Product warranty can be found at

www.crestron.com/warranty.

The specic patents that cover Crestron products are listed at

patents.crestron.com.

Certain Crestron products contain open source software. For

specic information, please visit

www.crestron.com/opensource.

Crestron, the Crestron logo, 3-Series, and 3-Series Control

System are either trademarks or registered trademarks of

Crestron Electronics, Inc. in the United States and/or other

countries. UL and the UL logo are either trademarks or

registered trademarks of Underwriters Laboratories, Inc. in

the United States and/or other countries. Other trademarks,

registered trademarks, and trade names may be used in this

document to refer to either the entities claiming the marks

and names or their products. Crestron disclaims any

proprietary interest in the marks and names of others.

Crestron is not responsible for errors in typography or

photography.

This document was written by the Technical Publications

department at Crestron.

Crestron Electronics, Inc. Installation Guide

15 Volvo Drive DOC. 7944B

Rockleigh, NJ 07647 (2047636)

Tel: 888.CRESTRON 02.17

Fax: 201.767.7576 Specications subject to

www.crestron.com change without notice.
