Side 1/3

Paralleled distribution block for Cresnet® network cables

Provides connections for lighting control modules and

outboard devices

The is a Cresnet terminalblockdesignedCAEN-BLOCK

specifically forCrestron lighting and automation systems to

linkextension andsatellite enclosures to the central control

system. TheCAEN-BLOCK mounts at the bottom ofa ,CAEN

CAEN-MLO CAENIB, or enclosure that does not containa

control systemto provide Cresnet and Override signal

connectivity forCLX-Series lighting control modules. The

CAEN-BLOCK servesas a parallel distribution blockfor

multipleCresnetcables,and provides connections for Cresnet

andoverridesignalcables from the central control system.

The

TheTheCre

Cre

CreCresnet

snet

snetsnetB

BBus

usus

Cresnet isthe communications backbone for many Crestron

keypads,lightingcontrols, shademotors, thermostats,

sensors, andother devices that don’t require thehigher speed

ofEthernet. Itprovides a dependable and flexible wiring

solution, allowingmultiple devices to be wiredtogether in

parallelusingboth home-run and daisy-chain topologies. The

Cresnet busdistributes bidirectional data communication and

24VDCpower to each device over asingle 4-conductor cable.

CAEN

CAENCAENMo

MoMounting

unting

untingunting

TheCAEN-BLOCKis designed to mount inside aCAEN,

CAEN-MLO, orCAENIB enclosure, positioned at the bottom

belowthelightingcontrolmodules. Frontfacing connectors

andcontrolsaffordoptimal visibility and serviceability to

facilitateinstallation andtroubleshooting.

Specifications

SpecificationsSpecifications

Connectors

ConnectorsConnectors

LEFT/RIGHT

LEFT/RIGHTLEFT/RIGHT (2)5-pin0.156in.headers;

Cresnet/Override interconnect portsfor

Crestron CLX-serieslighting control modules

(interconnect cablesincluded)

NET

NETNET (4)4-pin 3.5mm detachableterminalblocks,

paralleled;

Connect upto 20 Cresnet devices;

Amaximumaggregatecable length of

1500feet(457 meters) is recommended

OVERRIDE

OVERRIDEOVERRIDE (2)3-pin3.5mmdetachable terminal blocks,

paralleled;

Comprised of(2) inputs(and pass-thru)for

external contactclosures;

Triggers thepreset Override state in each

connected CLX-seriesmodule;

TheL input passes through to the LEFT

interconnect port;

TheR input passes through to the RIGHT

interconnect port

Environmental

EnvironmentalEnvironmental

Temperature

TemperatureTemperature 32°to 104°F (0° to 40°C)

Humidity

HumidityHumidity 10%to 95% RH (noncondensing)

Construction

ConstructionConstruction

Chassis

ChassisChassis Metal,gray, surface mount module with (2)

integral mountingflanges

Mounting

MountingMounting Installs ina Crestron CAEN, CAEN-MLO, or

CAENIBenclosure

Dimensions

DimensionsDimensions

Height

HeightHeight 2.0in.(51mm)

Width

WidthWidth 6.00in.(153mm)

Depth

DepthDepth 1.74in.(44mm)

Weight

WeightWeight

5.65oz(161g)

Model

ModelModel

CAEN-BLOCK

Cresnet® NetworkTermination Block for CAEN and CAENIB

Automation Enclosures

CAEN-BLOCK

CAEN-BLOCKCAEN-BLOCK

Cresnet® Network Termination Block for CAEN and CAENIB Automation

Enclosures

Available

AvailableAvailable Accessories

Accessories

AccessoriesAccessories

For a list of available accessories, visit the CAEN-BLOCK

product page.

This product may be purchased from select authorized Crestron dealers and

distributors. To find a dealer or distributor, please contact the Crestron sales

representative for your area. A list of sales representatives is available online at

www.crestron.com/How-To-Buy/Find-a-Representative or contact us for

additional information by visiting forwww.crestron.com/contact/our-locations

your local contact.

The original language version of this document is U.S. English.

All other languages are a translation of the original document.

The product warranty can be found at .www.crestron.com/warranty

The specific patents that cover Crestron products are listed online at

patents.crestron.com.

Certain Crestron products contain open source software. For specific

information, please visit .www.crestron.com/opensource

Crestron, the Crestron logo, and Cresnet are either trademarks or registered

trademarks of Crestron Electronics, Inc. in the United States and/or other

countries. Other trademarks, registered trademarks, and trade names may be

used in this document to refer to either the entities claiming the marks and

names or their products. Crestron disclaims any proprietary interest in the

marks and names of others. Crestron is not responsible for errors in typography

or photography.

Specifications are subject to change without notice.

Rev 01/08/24

CAEN-BLOCK

CAEN-BLOCKCAEN-BLOCK

Cresnet® Network Termination Block for CAEN and CAENIB Automation

Enclosures
