1M wide DIN rail mounting

Ethernet to KNX interface

Integrates KNX with a Crestron® control system

Supports KNXnet/IPSecurity (AES-128)

Controls up to 1,000 KNX datapoints

Up to 8 simultaneous KNXnet/IP Tunneling connections

Configure using ETS Software

On-board controls for setup and diagnostics

Powered via the KNX bus

The is an IP-based KNX interface that allows aDIN-KXI

4-Series® to communicate with a KNX system.Control System

It is capable of addressing and controlling up to 1,000

datapoints and receives power over the KNX bus. The DIN-KXI

can also be used as a programming interface for KNX devices

using ETS5 and ETS6 software.

KNX

KNXKNX Security

Security

SecuritySecurity

The device supports KNX Security (AES-128) which can be

enabled using ETS software.

Ethernet

EthernetEthernet Communications

Communications

CommunicationsCommunications

The Ethernet connection allows access to the KNX bus from

any point on the LAN. This provides programming and

diagnostics without direct access to the DIN-KXI.

Local

LocalLocal Diagn

Diagn

DiagnDiagnostics

ostics

osticsostics

The buttons and LEDs on the device provide diagnostic data

including the operating status and communication errors.

DIN

DINDIN Rail

Rail

RailRail Installation

Installation

InstallationInstallation

The 1M (18mm) wide DIN-KXI snaps onto a standard DIN rail

for installation in a wall mount enclosure. Wiring connections

are made along the top and bottom, clearly accessible from

the front for easy installation and servicing. All setup controls

and indicators are positioned on the center front panel.

DIN-KXI

DIN-KXIDIN-KXI

KNX Secure IPGateway, DINRailMount

Specifications

SpecificationsSpecifications

Power

PowerPower

KNX

KNXKNX Bus

Bus

BusBus 20mA

Communications

CommunicationsCommunications

KNX

KNXKNX KNX over TP (Twisted Pair);

Interface protocol: cEMI;

Max. APDU length: 55;

Device model: System B;

KNXnet/IP Security (AES-128);

Compatible with ETS5 and ETS6

Ethernet

EthernetEthernet Supports ARP, ICMP, IGMP, UDP/IP, TCP/IP,

DHCP, and Auto IP;

DHCP is enabled by default, can be changed

using the ETS Software

Connectors

ConnectorsConnectors

KNX

KNXKNX (2) 4-conductor KNX bus connectors, push-in

style;

Consisting of (1) Red (+) and (1) Black (-)

connector, for power and communications;

Accepts up to 4 solid-core twisted pairs;

0.6 - 0.8mm (22 - 20AWG), strip wires 5 -

6mm (0.2 - 0.24in.)

LAN

LANLAN (1) 8-pin RJ-45, female;

100BASE-TXEthernet port;

Green and yellow LEDs indicate Ethernet

port status

Controls

ControlsControls and

and

andand I

IIndicators

ndicators

ndicatorsndicators

KNXPROG.

KNXPROG.KNXPROG. (1) Red LED and (1) recessed, miniature push

button for entering Programming mode and

factory reset;

Programming Mode: Press to enter

Programming mode, the LED lights to

indicate that Programming mode is

activated;

Factory reset: Press and hold while

connecting the KNX bus, hold for 6 seconds

until all LEDs flash

KNX

KNXKNX (1) Multicolor LED, indicates power and KNX

status;

Green: Indicates power is received from the

KNXbus;

Flashing Green Indicates communications on

the KNXbus;

Flashing Red: Indicates communications

failure on the KNX bus

MODE

MODEMODE (1) Multicolor LED, indicates BAOS and IP

tunnel status;

Green: Normal operating mode;

Red:Programming mode is active;

Flashes green (1 to 10 times): Manual mode

is active, the selected BAOS connection (1 to

10) is not used and is available, the number

of flashes indicates the connection number;

Flashes Orange (1 - 10 times): Manual mode

is active, the selected BAOS connection (1 -

10) is used;

Flashes Green (1 - 5 times): Manual mode is

active, the selected Tunnel (1 - 5) is not used

and is available;

Flashes Orange (1 - 5 times): Manual mode is

active, the selected Tunnel (1 - 5) is used;

Flashes Red: The configuration is not

properly loaded

IPIP (1) Multicolor LED, indicates Ethernet

status;

Green: Active Ethernet link and valid IP

settings;

Flashes green: Ethernet activity;

Red:Invalid IP settings or has not received IP

settings from the DHCP server

CONNBAOS

CONNBAOSCONNBAOS (1) push button, to enter Manual mode and

select a BAOS connection;

Press to enter Manual mode and select a

BAOS connection (1 - 10), the MODE LED

indicates the selected BAOS connection

number;

To exit Manual mode, press CONN BAOS

and CONN TUNN simultaneously

CONNTUNN

CONNTUNNCONNTUNN (1) push button, to enter Manual mode and

select a tunnel connection;

Press to enter Manual mode and select a

TUNN connection (1 - 5), the MODE LED

indicates the selected tunnel connection

number;

To exit Manual mode, press CONN BAOS

and CONN TUNN simultaneously

Environmental

EnvironmentalEnvironmental

Temperature

TemperatureTemperature -5° to 45°C (23° to 113°F)

Humidity

HumidityHumidity 5% to 93% RH (noncondensing)

Construction

ConstructionConstruction

Enclosure

EnclosureEnclosure Light gray polycarbonate housing with

polycarbonate label overlay

Mounting

MountingMounting 35mm DIN EN 60715 rail mount, DIN 43880

form factor for enclosures with 45mm front

panel cutout, occupies 1 DINmodule space

(18 mm)

DIN-KXI

DIN-KXIDIN-KXI

KNX Secure IPGateway, DINRailMount
