Replacement button assembly for Horizon® 2 dimmers,
switches, and keypads
l
Six button assembly styles are available to accommodate
common button configurations
l
Available blank or with custom engraving
l
Engraved buttons can be backlit by a Horizon 2 dimmer,
switch, or keypad
l
Button assembly is field-replaceable without removing the
device from the wall
l
Available in white, black, and almond
The HZ2-BTNS is replacement button assembly for Horizon®2
dimmers, switches, and keypads. Button assemblies are
available in six styles to provide a variety of button
configurations and each style is available in White(-W), Black
(-B), and Almond(-A).
Custom Engraving Options
Identify the function of each button on the button assembly
with custom, laser-etched engraving. Engraved buttons can
be illuminated using the device's LED backlights. Engraving is
included when ordering ENGRAVED models. Button
assemblies without engraving (BLANK models) are also
available and can be used as is or can be custom engraved by
a third-party engraver.
Create engraving files using Impress, the Crestron Home
Setup app, the Crestron Home Online Configurator, or D3Pro.
If necessary, custom engraving can be changed up until the
order is processed by emailing orders@crestron.com with the
updated engraving file and order information.
Field-Replaceable Button Assemblies
Button assemblies can be installed on Horizon devices without
removing the device from the wall. Button assembly
engravings are backlit when installed in devices that provide
LED backlighting.
The field-replaceable button assemblies allow for changes in
device function or to allow the customer to use the system
before finalizing the engravings. The button assembly can be
replaced with any custom engraved or blank HZ2-BTNS
button assembly.
The HZ2-BTNS series button assemblies are available in the
following styles:
l
Style 1: 5 single buttons
HZ2-BTNS-1 ENGRAVED
HZ2-BTNS-1 BLANK
l
Style 2: 4 single buttons and 1 split rocker button;
Split rocker button is located in the lowest button position
NOTE: The split rocker button does not allow for a
center push and shares one backlight for the entire
split rocker.
HZ2-BTNS-2 ENGRAVED
HZ2-BTNS-2 BLANK
HZ2-BTNS
Horizon® 2 Button Assembly
