DM-XIO-DIR-80
DigitalMedia™ XiO Director – Virtual Switching Appliance for 80 Endpoints
crestron.com | 800.237.2041
>Comprehensive network AV system configuration,
management, and signal routing
>Emulates a traditional hardware-based matrix switcher
>Works with Crestron® DM® NVX encoders
and decoders
>Supports 80 endpoints in a
single domain
>Fully scalable for any sized network
>Intuitive web-based graphical user interface
>Ethernet control system interface
>Fully-programmable control of the virtual matrix and
physical endpoints
>Automatic endpoint device discovery
>Custom naming and search tools
>Easy diagnostics and signal status display
>XML device map file import/export
>Built-in logging
>Four Gigabit Ethernet LAN ports
>Single-space 19” rack-mountable
>Universal 100-240V internal power supply
The DM® XiO Director, model DM-XIO-DIR-80, is an enterprise-grade
network appliance that facilitates configuration, control, and management
of a large-scale AV network. Using encoder/decoders, CrestronDM NVX ®
offers the industry’s most versatile and scalable solution for distributing
4K60 4:4:4 HDR video over an IP network. The XiO Director provides a
means for managing large networks of DM NVX devices, routing AV signals,
and simplifying integration with one or more Crestron control systems.
Virtual DM® Switcher
The XiO Director virtually emulates the functionality of a traditional
hardware-based DigitalMedia™ matrix switcher, routing high-quality
4K streaming AV signals throughout a room, building, or campus. The
DM-XIO-DIR-80 model supports a total of 80 endpoint devices consisting
of DM NVX encoders and decoders. Multiple XiO Director units can be
deployed, with the ability to route signals between units just like hardware
switchers [1], easily handling even the largest corporate enterprise,
university, governmental, military, medical, transportation, sports,
entertainment, hospitality, gaming, or retail application.
Simple, Flexible Configuration
System configuration could not be simpler. The XiO Director automatically
discovers each DM NVX endpoint on the network, and allows each endpoint
to be assigned as a logical input or output to the software-based matrix
switcher. The XiO Director effectively eliminates the need for a physical
switcher, providing the virtual equivalent running on the AV network.
Note: The DM-XIO-DIR-80 assigns all associated endpoints to a single
“domain.” A domain is a logical grouping of endpoints that operate
together as a single switching entity. Each DM-XIO-DIR-80 in a system
functions as a separate domain. Other XiO Director models, including the
DM-XIO-DIR-160 DM-XIO-DIR-ENT and , can support multiple domains.
Refer to each model’s spec sheet for more information and additional
available features.
Easy Web-based Setup and Control
The XiO Director provides an intuitive web-based user interface to facilitate
system configuration, signal routing, and comprehensive diagnostics of the
complete AV network. Each domain and endpoint, as well as the inputs and
outputs on each endpoint, can be designated with a user-friendly name.
Navigating the entire system is easy using the search box
[1] to quickly find
domains, endpoints, inputs, and outputs by name or address. A system
overview screen is also provided, showing the video and audio signal
status for every input and output in a graphical layout that’s easy to view
and navigate.
SPECIFICATIONS
Device Support
Endpoints: Supports 80 DM NVX devices, each configured as an encoder
or decoder
Domains: Supports a single domain (all endpoints are grouped together as
a single system)
Communications
Ethernet: 10/100/1000 Mbps, auto-switching, auto-negotiating, auto-
discovery, full/half duplex, TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, IPv4
or IPv6, HTTPS web browser setup and control, Crestron control system
integration
DM NVX (via Ethernet): HDCP 2.2, AES audio/video content encryption,
RTP, RTSP, SDP, ONVIF, IGMPv2, IGMPv3, SMPTE 2022, FEC (Forward
Error Correction)
Connectors
MGMT (front): (1) 8-pin RJ45 connector, shielded, female;
10Base-T/100Base-TX/1000Base-T Ethernet port for hardware
management
DM-XIO-DIR-80 DigitalMedia
™
XiO Director
crestron.com | 800.237.2041
USB 2.0 (front): (2) USB Type A connectors, female, black;
USB 2.0 host ports for factory use only
USB 3.0 (front): (2) USB Type A connectors, female, blue;
USB 3.0 host ports for factory use only
LAN 1 – 4 (front): (4) 8-pin RJ45 connectors, shielded, female;
10Base-T/100Base-TX/1000Base-T Ethernet ports for web browser,
endpoint, and control traffic
100-240V~ 2-4A 50/60Hz (rear): (1) IEC 60320 C14 main power inlet;
Mates with removable power cord, included
Controls & Indicators
MSG: (1) Blue LED, identifies the device when “unit identification” is
initiated
LAN 1 – 2: (2) Green LEDs, each indicates Ethernet activity on the
corresponding LAN port
DISK: (1) Yellow LED, indicates SSD activity
PWR: (1) Green LED, indicates the unit is powered on
RESET: (1) Recessed pushbutton, initiates a hard reset
Power Button: (1) Pushbutton, initiates boot up or shutdown
MGMT: (1) Amber LED & (1) bi-color green/orange LED; indicates Ethernet
activity, speed, and link status for the management LAN port
LAN 1 – 4: (1) Amber LED & (1) bi-color green/orange LED per each of (4)
ports; each pair indicates Ethernet activity, speed, and link status for the
corresponding LAN port
Power
Main Power: 4 Amps @ 100-120 Volts AC, 50/60 Hz;
2 Amps @ 220-240 Volts AC, 50/60 Hz
Power Consumption: 35 Watts at 100% CPU usage and fan speed
Environmental
Operating Temperature: 50° to 95° F (10° to 35° C)
Operating Humidity: 8% to 90% RH (non-condensing)
Non-Operating Temperature: -40° to 158° F (-40° to 70° C)
Non-Operating Humidity: 5% to 95% RH (non-condensing)
Heat Dissipation: 119.4 BTU/hr
Construction
Chassis: Metal, black finish; vented front, rear, and sides; variable speed
fan cooled
Mounting: Freestanding or 1 RU 19-inch rack-mountable (rack ears
included)
Dimensions
Height: 1.72 in (44 mm)
Width: 17.21 in (437 mm) without rack ears;
19.00 in (483 mm) with rack ears
Depth: 10.49 in (267 mm) without rack ears
Compliance
IC, CE, FCC Part 15 Class B digital device
MODELS & ACCESSORIES
Available Models
DM-XIO-DIR-80: DigitalMedia™ XiO Director – Virtual Switching Appliance
for 80 Endpoints
Available Accessories
DM-NVX Series: DigitalMedia™ 4K60 4:4:4 HDR Network AV
Encoder/Decoders
DM-RPP-K24: DigitalMedia™ 24-Port Keystone Patch Panel
DM-CONN-ULTRA-RECP: DigitalMedia™ Ultra Keystone RJ45 Jack
DM-CBL-ULTRA-PC: DigitalMedia™ Ultra Patch Cables
Front and Rear Panels
