Enables installastionofone cable retractorin the middle
module position withinanFT2-202 Series FlipTop™
l
Attaches belowthe table to the frontorrear ofthe FlipTop
chassis
l
Provides mountingslots for one retractorandone power
supply
l
Compatible withFT2-202-MECHandFT2-202-ELECSeries
FlipTops™
l
Compatible withGravity RetractorsandOne-Touch
Retractors (FT2A-CBLR-GRandFT2A-CBLR-1TSeries
respectively)
The FT2A-CBLR-BRKT-202 is an adapterbracketfora
Crestron® FT2-202 SeriesFlipTop™ thatenables the
installationofasingle cable retractor inthe middle position
withinthe FlipTop.Itattaches tothe frontor rearofthe FlipTop
chassis, andprovides mountingslots for one retractor andone
power supply.
FT2-202 SeriesFlipTops normallysupportthe installationof
Addingthe FT2A-CBLR-BRKT-202 bracketallowsaretractorto
be installedin the middle ofthe row,allowingforatotalofupto
three retractors across theentire row.The mid-rowretractor
occupies the thirdandfourthmodule slots ofthe row.
When installingamid-rowretractor,the bracketandretractor
canattachtoeither the frontorrear ofthe FlipTopchassis
belowthe table.When installed,the mid-rowretractor
enclosure projects fromthe frontorrear ofthe chassis
perpendicular tothe end-mountedretractors. The cable
connectornestswithinthe retractormodule abovethetable at
a90° rotationrelative to other connectors withinthe FlipTop.
Note: Usingthe bracket, an FT2A-CBLR-GRSeries Gravity
Retractor requires 2-3/4 inches (70 mm) horizontal clearance,
andan FT2A-CBLR-1TSeries One-TouchRetractor requires 9
inches (228 mm) horizontal clearance, measuredfromthe front
orrear ofthe FlipTopchassis beneaththe table.Refer to each
product'sspec sheetfor additional dimensions andclearances.
When usedwithanFT2-202-ELECSeries "Electrical"FlipTop,
the FT2A-CBLR-BRKT-202 bracketretainstheabilitytomount
asingle FT2A-UTK-PWSpower supplyonthe same side as the
cableretractor.
