Ctek MXT 4.0 Manual

Ctek Batterioplader MXT 4.0

Læs gratis den danske manual til Ctek MXT 4.0 (6 sider) i kategorien Batterioplader. Denne vejledning er vurderet som hjælpsom af 44 personer og har en gennemsnitlig bedømmelse på 4.7 stjerner ud af 22.5 anmeldelser. Har du et spørgsmål om Ctek MXT 4.0, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/6

EN • 3

ABSORPTION, READY TO USE

ANALYSE

RECOND

MODE

NORMAL

AGM

CONGRATULATIONS

to the purchase of your new professional switch mode battery charger.

This charger is included in a series of professional chargers from CTEK AB and SWEDEN

represents the latest technology in battery charging.

CTEK COMFORT CONNECT – eyelet M8

CTEK COMFORT CONNECT

MAINS CABLE

CTEK COMFORT CONNECT – clamp

CHARGE CABLE

SUPPLY PLUG*

*Supply plugs may dif fer to suit your wall socket.

NORMAL

BATTERY

PROGRAM

ERROR LAMP

AGM

BATTERY

PROGRAM

POWER

LAMP

CHARGING

1. Connect the charger to the battery.

2. Connect the charger to the wall socket. The power lamp will indicate that the mains

cable is connected to the wall socket. The error lamp will indicate if the battery clamps

are incorrectly connected. The reverse polarity protection will ensure that the battery

or charger will not be damaged.

3. Press the MODE-button to select charging program.

4. Follow the indication lamps through the charging process.

The battery is ready to start the engine when is lit.

The battery is fully charged when is lit.

5. Stop charging at any time by disconnecting the mains cable from the wall socket.

MODE-

BUT TON

MANUAL

DESULPHATION

SOFT START BULK FLOAT, FULLY CHARGED

PULSE, MAINTENANCE CHARGING

RECOND

PROGRAM

20015561D MXT 4.0, Manual EU, Print le 003.indd 3 2011-10-11 12:42:46

4 • EN

BATTERY SIZE (Ah) TIME TO 80% CHARGED

10Ah 2h

20Ah 4h

50Ah 10h

100Ah 20h

READY TO USE

The table shows the estimated time for empty battery to 80% charge

CHARGING PROGRAMS

Settings are made by pressing the MODE-button. After about two seconds the charger

activates the selected program. The selected program will be restarted next time the

charger is connected.

The table explains the diﬀerent Charging Programs:

Program Battery

Size (Ah) Explanation Temp range

NORMAL 8–250Ah

Normal battery program

28,8V/4A. Use for WET batteries,

Ca/Ca, MF and for most GEL batteries

+5°C–+50°C

(41ºF–122ºF)

AGM

8–250Ah

AGM battery program 29,4V/4A

Use for AGM batteries.

-20°C–+5°C

(-4ºF–41ºF)

RECOND 8–250Ah

Recond program 31.4V/1.0A

Use to return energy to the empty

WET and Ca/Ca batteries. Recond

your battery once per year and after

deep dischare to maximise lifetime and

capacity. The Recond program adds the

Recond step to the normal battery

program. Frequent use of the Recond

program may cause water loss in the

batteries and reduce service life of

electronics. Contact your vehicle and

battery supplier for advice.

-20°C–+50°C

(-4ºF–122ºF)

ERROR LAMP

If the error lamp is lit, check the following:

1. Is the chargers positive lead connected to the

batterys positive pole?

2. Is the charger connected to a 24V battery?

3. The clamps are short circuited?

4. Has charging been interrupted in or ?

Restart the charger by pressing the MODE-button. If charging

is still being interrupted, the battery...

...is seriosly sulphated and may need to be replaced.

...can not accept charge and may need to be replaced.

...can not keep charge and may need to be replaced.

20015561D MXT 4.0, Manual EU, Print le 003.indd 4 2011-10-11 12:42:46

Produkt Specifikationer

Mærke:	Ctek
Kategori:	Batterioplader
Model:	MXT 4.0
Bredde:	89 mm
Dybde:	191 mm
Højde:	48 mm
Vægt:	800 g
Antal pr. pakke:	1 stk
Produktfarve:	Blue, Silver
Batterispænding:	2 V
Driftstemperatur (T-T):	-20 - 50 °C
Strømkilde type:	DC
Indgangsspænding:	220-240 V
Indgangsfrekvens:	50/60 Hz
Aktuel opladning:	4
