User Manual

Model: POE25

Multiple PoE Extenders can be connected every 100 meters to

obtain greater distances.The actual ﬁgures depend on operating

conditions.The range is over 24AWG or heavier Cat-5e or Cat-6

cable except where speciﬁed.

Examples for medium power PoE Devices (i.e. PoE Class 2, or

require under 6 watts)

Maximum Distances for Power Sources

For support and warranty, please visit: http://www.cudy.com/. Speciﬁcations

are subject to change without notice. Cudy is a registered trademark of

Shenzhen Cudy Technology Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders.

EU Address: Otto esser 2c, 65451 Kelsterbach, Germany

EU declaration of conformity

Support and Warranty

Cudy hereby declares that the device is in compliance with the

essential requirements and other relevant provisions of directives

2014/30/EU, 2014/35/EU, 2015/863/EU, 2009/125/EC and

2011/65/EU. The original EU declaration of conformity can be found at

http://www.cudy.com/ce

810600152

Examples for full power PoE Devices (i.e. PoE Class 0 or 3,

require under 12 watts).

Examples for PoE+ Devices (i.e. PoE Class 4 under 22 watts, or

802.3at compliant).

PoE Source Maximum Distances

PoE switch

(802.3af, Output voltages 50V)

200M

300M

15W mid-span

(802.3af, Output voltages 50V)

PoE+ switch

(802.3at, Output voltages 50V)

30W mid-span

(802.3at, Output voltages 50V)

400M

PoE+ switch

(802.3bt, Output voltages 50V)

60W mid-span

(802.3bt, Output voltages 50V)

PoE Source Maximum Distances

PoE switch

(802.3af, Output voltages 50V)

Not applicable

200M

15W mid-span

(802.3af, Output voltages 50V)

PoE+ switch

(802.3at, Output voltages 50V)

30W mid-span

(802.3at, Output voltages 50V)

300M

PoE+ switch

(802.3bt, Output voltages 50V)

60W mid-span

(802.3bt, Output voltages 50V)

Email:

support@cudy.com

Website:

www.cudy.com

Model

No. of channels

Pass Through

Data Rates

POE25

Power over

Ethernet input

Pin Assignment and Polarity:

Both 1/2, 3/6 and 4/5, 7/8

Power over

Ethernet Output

Pin Assignment and Polarity: 1/2 (+), 3/6 (-)

Output Power: Up to MAX 30W for 2 PSE

1 (PoE IN) into 2 (PoE OUT)

10/100/1000 Mbps half/full duplex

Mounting

Environment

Operating Humidity

Storage Temperature

Operating Ambient

Temperature

Wall or shelf

Regulatory Compliance

-25 to 55℃

-40 to 70℃

IEEE 802.3af (15.4W)

IEEE 802.3at (30W)

IEEE 802.3bt 4Pairs (60W)

Complies with IP67

Dimensions

230mm x 90mm x 40mm

Connectors

Network cables

Shielded RJ-45, EIA 568A and 568B

Shielded category 5E (or higher)

Speciﬁcations

Features

Description

Hardware Connection

Support up to 3 PoE+ Extenders for 400 Meters Distance

PoE+ Extender

Camera

PoE+ Switch

MAX 100Meters

PoE+ Extender PoE+ Extender PoE+ Extender CameraPoE+ Switch

100Meters 100Meters 100Meters 100Meters

Cudy Outdoor Gigabit PoE++ Extender helps install PDs (such as

IP Security Cameras, wireless access points) at greater distances

than 100 meters. By connecting PoE+ Extender for every extra

100 meters of cable, both Ethernet and PoE can be extended to

up to a total distance of 200 meters. It does not require any

additional power supply and the connected PDs is fed by a

single PoE switch or mid-span, which simpliﬁes installation.

Cudy Outdoor PoE++ Extender has an IP67 waterproof

enclosure and includes waterproof connectors on both the input

and output sides. With surge protection function and working

temperature from -25 ° C to 55 ° C, it can withstand severe

weather.

IEEE802.3af/802.3at/802.3bt compliant

One Gigabit PoE input port (60 watts max)

Two Gigabit PoE output ports (2 x 30 watts max)

Extends PoE signal for additional 100 meters

No additional power supply required

Auto-detect PoE and non-PoE equipments

Wall-mount design plug and play,

IP67 Waterproof compliant

PoE Extender

PoE Extender PoE Extender PoE Extender

Indoor or Outdoor Matching with (

waterproof Ethernet cable)
