Wi-Fi 6 Combo VDSL2 GPON IAD
DVA-6800Z
The DVA-6800Z Wi-Fi 6 Combo VDSL2 GPON IAD is a highly integrated router with everything
your home or small business needs for high-speed Internet access. It combines an ADSL2+/
VDSL2 modem, Gigabit Ethernet Internet Port, a GPON optical WAN interface, 4G mobile
Internet support by external USB dongle, Voice over IP (VoIP), and Gigabit wireless together in
a single, easy-to-use product that shares an Internet connection for all your devices.
Multiple Failover Redundancy and Future Connectivity
The D-Link DVA-6800Z Wi-Fi 6 Combo VDSL2 GPON IAD comes with a built-in high-speed
VDSL/ADSL modem, a 10/100/1000 Ethernet WAN/LAN port, and USB 3.0 and 2.0 ports which
support 3G/4G mobile broadband USB adapters. This means that if your primary connection
method should fail, the DVA-6800Z will automatically fall back to your pre-dened backup
connection. Additionally, the DVA-6800Z features a GPON port with a built-in WBF, provding
a reliable connection that allows you to take advantage of the high bandwidths oered by
GPON.
Smooth Streaming with Wireless AX
The DVA-6800Z uses the latest Wireless AX technology, which provides transfer rates of up to
3.6 Gbps. The router operates on both the 2.4 GHz and 5 GHz wireless bands at the same time
using concurrent dual-band technology. This allows you to browse the web, chat and e-mail
using the 2.4 GHz band, while simultaneously streaming digital media, playing online games,
or making Internet voice calls on the 5 GHz band.
Voice Over IP
The DVA-6800Z provides Voice over IP technology with advanced communication features, and
is compatible with industry-wide phone services so you can make and receive calls reliably. Use
the FXS phone port on the DVA-6800Z to connect an ordinary phone set for your VoIP phone
calls, and use the router functions to connect all of your family members or personnel to the
Internet for a fast online experience throughout your home or oce.
Features
Convenience
• User-friendly web conguration interface
• Compatible with all standard Internet
applications
• Industry standard and interoperable DSL
interface
Wireless
• WLAN with data transfer rates of up to 3600
Mbps, compatible with IEEE 802.11n/ac/ax
• Wireless LAN security features: WPA2/WPA3
Personal™
• Supports Zigbee 3.0
Broadband
• Asynchronous Transfer Mode (ATM) and digital
subscriber line (DSL) support
• Packet Transfer Mode (PTM) and digital
subscriber line (VDSL)
• Gigabit Ethernet Internet Port
• MSA host supporting 2.5 Gb/s ber module
Router Features
• IP routing and bridging
• Point-to-point protocol (PPP)
• Quality of Service (QoS)
• Universal Plug-and-Play (UPnP)
• Web Filtering
• USB mass-storage, SAMBA
Blazing Fast Internet Solution
Experience high-speed broadband Internet via the
built-in Ultra VDSL modem, Gigabit Ethernet, or USB
4G mobile dongle
Latest Wireless AX and Gigabit Ethernet
Enjoy Gigabit Ethernet and combined wireless speeds
of up to 3600 Mbps with increased range thanks to
the latest 802.11ax wireless technology
GPON Interface
Features a GPON optical WAN interface, oering
a 1.25 Gbps upstream data rate and a 2.5 Gbps
downstream data rate
Product Highlights
DVA-6800Z Wi-Fi 6 Combo VDSL2 GPON IAD
Smooth Transmissions
The DVA-6800Z Wi-Fi 6 Combo VDSL2 GPON IAD has built-in dual active
rewalls (SPI and NAT) to help protect your local network from intrusions. It is
also equipped with WPA3 wireless encryption technology and access control
to help protect your network from unauthorized access and outside threats so
you can use the Internet with condence. In addition, QoS priority queues and
packet prioritization can minimize trac congestion and deliver smooth VoIP and
streaming media, providing you with the best possible Internet experience.
Easy to Set Up
Setting up the DVA-6800Z is easy with the D-Link setup wizard. Simply open
the setup utility and follow a few easy steps to get your home network up and
running. You can also set up an encrypted wireless network with the touch of
a button using Wi-Fi Protected Setup (WPS). Simply press the respective WPS
buttons on each device to instantly establish an encrypted connection.
File Sharing Right at Your Fingertips
The DVA-6800Z lets you connect a USB storage device and instantly share
documents, movies, pictures, and music. You can put your music library on
a USB drive and share it with your entire home. You can show photos on the
living room TV while a family member watches a movie on their computer.
You can stream media les to multiple devices without interruption, or save
them to your device for oine playback. The intuitive interface lets anyone
immediately connect to a variety of entertainment options stored securely on
your own storage device.
Integrated with Zignee 3.0 for Smart Homes
The DVA-6800Z fully supports Zignee 3.0 and is compatible with all end devices
that use the standard. This enables you to implement a wide variety of smart
home applications, such as light control via your smartphone, or contact and
motion sensors for security and convenience.
Front Panel LEDs
Rear Panel Interfaces
WLAN
Button WPS
Button Power
DSL
Internet
WLAN
Voice USB
Fiber
DSL Line (1-2) LAN (1-3)
Power
Button
Power
Connector
Reset
Button
GPON
Connector
USB 2.0
USB 3.0
LAN/WAN
