D-Link DWR-M955X Manual

D-Link Router DWR-M955X

Læs gratis den danske manual til D-Link DWR-M955X (4 sider) i kategorien Router. Denne vejledning er vurderet som hjælpsom af 4 personer og har en gennemsnitlig bedømmelse på 5.0 stjerner ud af 2.5 anmeldelser. Har du et spørgsmål om D-Link DWR-M955X, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/4

Wi-Fi 6 AX1500

4G Cat4 LTE Router

Package Contents:

Wireless Router (DWR-M955X)

Power Adapter

Ethernet Cable

Quick Installation Guide

Warranty Card

If any of these items are missing from your packaging,

contact your reseller.

DWR-M955X

Connect via Wi-Fi

Connect your device to the

Router’s Wi-Fi. The default

Wi-Fi name and password

are printed on the label at

the back of the Router.

Connect to ISP

Connection Box

Using the included

Ethernet cable,

connect the Router’s

WAN port to the

Ethernet port on

your NBN or UFB

Connection Box.

Connect via a Network Cable

Connect your PC to the

Router’s LAN1, LAN2 or

LAN3 port using a

network cable.

Connect Your Device

Power

Cable

WAN

TECHNICAL SUPPORT

For conguration guides and the latest software updates, please visit

support.dlink.com.au

You can contact our Technical Support Team:

• Via website: https://www.dlink.com.au/contactus

• Via Live Chat: https://support.dlink.com.au/

• Via phone (24x7):

Australia: 1300 700 100

New Zealand: 0800 900 900

Schematic Diagram of Router Connection

Optional:

Insert SIM Card for 4G LTE

connectivity.

OPTIONAL: MESH SETUP

To create a Wi-Fi mesh with multiple D-Link Routers, rst select the required mode under

“Easymesh” settings of each Router. The Router that connects to the Internet should be

set as Controller. The Satellite Routers should be set as Agents.

RESET TO FACTORY DEFAULTS

To revert the Router to factory settings including Admin password, Wi-Fi name and Wi-Fi

password, press the Reset (WPS) button for 10 seconds.

Press the WPS button at the back of both Routers for 3 seconds. The 2.4GHz LED will ash

and the Routers will wirelessly sync with each other automatically.

OPTION 1 - D-LINK WI-FI APP SETUP OPTION 2 - WEB BROWSER SETUP

Step 1. Install the D-Link Wi-Fi Assist App. You can also use a Web browser on your computer or on your phone to set up the Router.

Step 1. Connect your computer or phone to your Router’s Wi-Fi. The Wi-Fi Name and

password are printed on the label at the back of the Router. Alternatively, you can connect

your computer to one of the Router’s LAN ports using a network cable.

Step 2. Open your Web browser and enter http://192.168.0.1 in the address bar. You will

be prompted to enter the Router’s admin password – the factory password is printed on

the label at the back of the router.

Step 2. Connect your phone to your Router’s Wi-Fi. The Wi-Fi Name and password are

printed on the label at the back of the Router.

Step 3. Open the D-Link Wi-Fi Assist app. You will be prompted to enter the Router’s

admin password – the factory password is printed on the label at the back of the Router.

Step 4. Tap on the Settings icon in the top right corner and then select Quick Setup.

Select your Internet Connection type and enter the required details.

Enter your desired Wi-Fi Name and assign a secure password to your Wi-Fi.

After completing the Quick Setup, the Router will restart.

Reconnect to your Router’s Wi-Fi using the new name and password.

Step 3. The Setup Wizard will take you through the initial Router set up.

Select your Internet Connection type and enter the required details.

If required, you can change the Router’s IP address.

Assign a strong system password to protect your Router from unauthorised access.

Enter your desired Wi-Fi Name and assign a secure password to your Wi-Fi.

After completing the Setup Wizard, the Router will restart.

Reconnect to your Router’s Wi-Fi using the new name and password.

Select your Router’s Operation Mode. “Gateway” is the most common mode.

Produkt Specifikationer

Mærke:	D-Link
Kategori:	Router
Model:	DWR-M955X
