Side 1/2

1. On the home screen, press Contacts (Right Soft Key) > then press [Ok]

2. Scroll down and select [New] > then press [Ok]

3. Select where you would like to save the contact (SIM or phone) > press [OK]

4. Type the contact’s name and phone number into the  elds provided

5. Press [OK] > and select [Save] to save your new contact.

HOW DO I ADD A CONTACT TO MY CONTACT LIST?

PACK AGE CONTENT

INSERTING & REMOVING SIM CARD

INSERTING MICRO SD CARD

DWR-720 /PW

BASIC USER SETUP GUIDE

DWR-720 /PW Phone

Antenna

AC Power Adapter

Handset Cord

Handset Receiver

Battery

SIM

CARD

Turn the SIM card so the

gold contacts are facing

down and the top right

corner is the one that is

cut. Insert the SIM card

by carefully sliding it

into the silver SIM card

holder from the right.

Lightly press

down and

carefully slide

the MicroSD card

cover to the

right. You will

hear a small click

and the clip will

now be loose.

Flip open the

MicroSD card cover

by softly lifting it to

the right. Turn the

MicroSD card so the

gold contacts are

on the right facing

down. Place the

MicroSD card  at

into the groove.

Close the MicroSD

card cover by

 ipping the cover

left, softly press

down and slide

the cover to the

left to lock. You

will hear a small

click and the clip

is now locked.

Remove the SIM

card by pushing

down the clip on

the right. Then

carefully sliding

the SIM card out

from the left.

INSERT REMOVE

SIM

CARD

PRESS

DOWN

Only some of the key features are listed here. For more details on other features and con guration settings,

please refer to the User Manual on our website at: Telkom.d-link.co.za

PLEASE NOTE

HOW DO I CONFIGURE THE APN IF I’M NOT USING A TELKOM SIM?

1. On the home screen, press Menu (Left Soft Key) > select [Settings] > click on [Wireless & Networks]

2. Select [Mobile networks] > scroll down and select [Access Point Names]

3. Click on the [Ok] button and select [Edit] > select [APN] > click on [Ok] and select [Edit]

4. Click [back] to delete the default APN > now type the APN settings provided by your Internet Service Provider

To change between upper & lowercase press the [#] key > click on [Ok] > select [Ok] to save.

HOW TO DEACTIVATE THE SIM CARD’S PIN CODE

1. On the home screen, press Menu (Left Soft Key) > navigate to [Settings], then press [Ok]

2. Scroll down and select [Security], then press [Ok] > select [Set up SIM card lock], then press [Ok]

3. Select [Lock SIM card], and press [Ok] > enter your current SIM card PIN and click on [Ok] to deactivate it.

USB TETHERING

1. One-on-one internet connection between the device and a laptop/computer.

2. Connect a device to the phone using a USB cable (use the phone’s power socket as a connection point).

3. In the idle mode, press Menu (Left Soft Key) > select [Settings] > click on [Wireless & Networks]

4. Select [Tethering & portable hotspot] > click on [USB tethering] to enable it.

5. Your computer will now be able to connect the internet through your device.

WI-FI TETHERING

1. You can connect up to 8 Users using your device as a Wi-Fi Hotspot.

2. In the idle mode, press Menu (Left Soft Key) > select [Settings] > and click on [Wireless & Networks]

3. Select [Tethering & portable hotspot] > click on [Wi-Fi hotspot].

4. Option 1 [WLAN switch] select to [Enable] the Wi-Fi hotspot.

5. Option 2 [Keep Wi-Fi hotspot on] select how long you want the Wi-Fi hotspot to be active.

6. Option 3 [Set up Wi-Fi hotspot] lets you edit the details for your Wi-Fi hotspot:

• Rename your [Network SSID] in order to recognise it easier.

• Set your [Security] to WPA2 - PSK to setup a password for you hotspot.

• Create a unique [Password] to prevent unauthorised access to your device.

7. Option 4 [Connected Users] shows the number of active connections.

MicroSD

CARD

1. On the home screen, press Menu (Left Soft Key) > navigate to [Settings], then press [Ok]

2. Scroll down to [Quick number], then press [Ok] > select the slot where you would like to set the number > then press [Ok]

3. If you know the number, enter it here > then press [Save] > and select [Save] from the menu.

Or if you already have the contact saved, press [Save] > then select [From contact] > press [OK]

Select the contact from your contact list > and press [Ok] > press [Save] > and select [Save] from the menu.

HOW DO I SET QUICK DIAL KEYS (M1 - M4)?

SENDING A SMS

1. On the home screen, press Menu (Left Soft key) > select [SMS] > select [Write Message].

2. You can manually enter recipient number in the “Type number”  eld or select from contacts.

3. Type your message content in the “Type text message”  eld > press [Ok] > select [Send] to send.

HOW DO I CHECK MY AIRTIME BALANCE?

1. In idle state of the device, enter *188# and then dial by pressing the green Dial / Answer key.

2. An on-screen message will con rm that an SMS with your airtime balance will be sent to you shortly.

Screw the antenna

into the TNC

Antenna Port

INSTALLATION

Ensure the DWR-720 /PW is powered o before performing the steps below.

Flip the phone

around and

open the Battery

Cover at the

bottom of the

device.

Plug the one

end of the hand-

set cord into the

handset receiver.

On the front of the

device, hold the

Red End call / Power

key for ±5 seconds.

A loading screen will

display to indicate

that the phone is

starting up.

Connect the USB

point of the Power

Adapter to the USB

power jack on the left

side of the phone.

Plug the power

adapter into a

wall outlet.

Insert and slide

the SIM Card

into place as

shown above.

SIM

CARD

KEY LOCATION

Right Soft key

M1-M4 Quick

Dial keys

End /

Power key

Wi-Fi key

Redial key

Hands Free

Loud Speaker key

Keypad

Dial/Answer key

Direction key

Left Soft key OTHER IMPORTANT KEYS

* KEY: Press and hold the [0] key to input a +

when dialling a number.

CHANGING CALL VOLUME

Press the Right / Left direction key to adjust

the volume while on a call.

POWER ON/OFF

ON: On the front of the device, hold the Red

End call / Power key for 5 seconds.

OFF: Hold the Red End / Power Key for 5 seconds.

Note: In this state, all reminders and alarms will

still sound.

NETWORK DEPENDANT

FEATURES

Call forwarding, call barring, call waiting and

voice mail.

SETTINGS

1. You can change your language, time

& date, Call settings, Phone Settings,

Display settings, Etc.

2. Edit Volume, Security.

3. Check your phone information.

Open the MicroSD

card holder and insert

the MicroSD card

into the

Insert the Battery

with the metal end

on the bottom left.

Close Battery Cover.

Note: The battery comes partially charged.

You can use the device while charging.

If prompted for a PIN

number enter the 4 digit PIN

indicated on the larger card

supplied with the SIM card.

Push the left Soft Key and

select “OK” to unlock.

Plug the other end

of the handset cord

into the headset

port on the back of

the phone and clip

the cord into the

cord clip.

Note: If the phone has no signal and shows “Mobile Network

Not Available” when dialling please phone Telkom on 081 180

to verify that your SIM is active and your area has coverage.

Rubber Feet Grip

Handset Port

Handset Cord Clip

Battery Cover

TNC Antenna Port

Sticker with Wi-Fi &

Bluetooth details

MicroSD

CARD

*188# Check Mobile Balance and get all your balances SMS’d to you

*180# Mobile Account Menu (buy bundles, transfer airtime/data, manage spend limit,

get device settings, change tari , BIS)

*1# Check what your mobile number is (Indicated by MSISDN)

*140*mobile number# Send a Please Call Me

USEFUL TELKOM MOBILE USSD CODES

FAQ

MY PHONE SAYS MOBILE NETWORK NOT AVAILABLE WHEN DIALLING

1. If this is a new installation, your SIM card may not be active. This could take between 24 - 48 Hrs.

2. Or there is no mobile service (signal) / coverage in your area.

Check that your SIM Card has been inserted correctly (as indicated on page 1 of this user guide).

If problem persists please phone Telkom on 081 180 to verify that your SIM card is active and that your area has coverage.

MAKING AND ENDING A CALL

1. On the home screen, enter the number you want to dial and press the green Dial / Answer key.

2. With the handset on hook the hands free call (Loud speaker) will be initiated.

3. Pick up the handset receiver to switch over to handset calling.

4. During an active call, press the large speaker icon to enable hands free call.

5. To end an active call, press the red End / Power key or hang up.

PIN: xxxx

PUK: xxxx

USB Power Jack

Produkt Specifikationer

Mærke:	D-Link
Kategori:	Telefon
Model:	DWR-720
Bredde:	100.3 mm
Dybde:	49.35 mm
Højde:	14.13 mm
Vægt:	43.67 g
Produktfarve:	Sort
Batterispænding:	5 V
Batterikapacitet:	2000 mAh
Skærm diagonal:	- "
Kompatible hukommelseskort:	MicroSD (TransFlash)
Wi-Fi:	Ja
Datanetværk:	3G, EDGE, GPRS, GSM, HSDPA, HSUPA, UMTS
Generering af mobilnetværk:	3G
Batteriteknologi:	Lithium-Ion (Li-Ion)
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Driftstemperatur (T-T):	-10 - 55 °C
Ethernet LAN-datahastigheder:	- Mbit/s
Sikkerhedsalgoritmer:	64-bit WEP, 128-bit WEP, WPA, WPA2-PSK, WPS
Markedspositionering:	Bærbar
Dimensioner (BxDxH):	100.3 x 49.35 x 14.13 mm
Antenner, antal:	3
Firewall:	Ingen
LED-indikatorer:	Network, Power
Indbygget kortlæser:	Ja
Understøttede WLAN-dataoverførselshastigheder:	21 Mbit/s
Enhedstype:	Udstyr til trådløst netværk
Antenne type:	Intern
Understøttede UMTS-bånd:	900,2100 Mhz
Understøttede GSM-bånd:	850,900,1800,1900 Mhz
xDSL-forbindelsestype:	Ingen
