Side 1/6

Installation guide

Actuator

Type ICAD 600B / 600B-TS / 1200B

027R9001

Info for UK customers only : Danfoss Ltd., 22 Wycombe End, HP9 1NB, GB

Імпортер:ТОВ з іі “Данфосс ТОВ” 04080, Київ 80, п/с 168, Україна

Nm LB-feet

ICAD 600B

ICAD 600B-TS

ICAD 1200B

ICM + ICAD 600B/ICAD 600B-TS

1 2

3 4

5a 5b ICM + ICAD 1200B

Before installing ICAD on ICM please read

t she eparate guide

“Mechanical in Itallation ICAD onof CM”

ICAD 600B

ICAD 600B-TS

ICAD 1200B

mm in.

H45 1.77

L325 1

ring

Groove where

clamps hold onto

ICM top

New O-ring

“Quick start guide”

DANFOSS

Buttons and display description in page 4

Max. 3 Max. 2.2

ICAD 600B / ICAD 600B / ICAD 1200B

ICAD 600B/1200B - Analog I/O for modulating control

ICAD 600B/600B-TS/1200B - Digital I/O for ON/OFF valve operation

External

voltage

24 V DC (+)

(–)

II III

Supply

D F G E

DI1 DI2

Control

ICAD

Danfoss

M27H0163_1

Neutral zone/3 points control

Control

Power supply cable

cable

Terminal box

Data cabl e

Power

Control

Data

(White/blue)

(White/orange)

(Orange)

(Blue)

A (Black)

(Black)

(White)

(Brown)

(Blue)

B (Brown)

C (Red)

D (Orange)

E (Yellow)

F (Green)

G (Blue)

ICAD back Ref Color

A (Black)

B (Brown)

C (Red)

D )(Orange

E (Yellow)

F )(Green

G (Blue)

EKC 347

EKC 315A

EKC 361

Only possible with EKC 347

A (Black)

B (Brown)

C (Red)

D (Orange)

E (Yellow)

F (Green)

G (Blue) EKE 347

Only possible with EKE 347

A (Black)

B (Brown)

C (Red)

D )(Orange

E (Yellow)

F )(Green

G (Blue)

Auxiliary relays

24 V DC

A Black - Common alarm

B Brown - ICM fully open

C Red - ICM fully closed

D Orange - GND ground

E Yellow + 0/4 – 20 mA Input

F Green + 0/2 – 10 V input or digital input for on/o control

G Blue + 0/4 – 20 mA Output

I Black + Fail safe supply. Batter 19y / UPS* V DC

II White + Supply voltage

24 V DC 2A, or more, per ICAD recommended

ICAD PSU must be SELV**, >15 W

III Brown -

IIII Blue +UPS Signal of Health - optional depending on ID31:

‘UPS supply’ set to ‘Yes’

Digital

output

1 White/Blue

2 White/Orange

3 Blue

4 Orange

(-) / TX+ Data – (B) / Transmit Pair(+)

GND / RX+ Ground / Receiving Pair(+)

(+) / TX- Data + (A) / Transmit Pair(-)

GND / RX- Ground / Receiving Pair(-)

*Uninterruptable Power Supply

The ICAD is a Class III appliance

RS 485 / Ethernet
