F2000 and F17 Series Equipment Stands
Service, Installation and Care Manual
Please read this manual completely before attempting to install or operate this equipment! Notify carrier of
damage! Inspect all components immediately. See page 2.
July 2011
IMPORTANT INFORMATION
READ BEFORE USE
PLEASE SAVE THESE INSTRUCTIONS!
Delfield
™
®
Warning
To assure proper operation a 2" airspace must be maintained between the bottom of any cooking equipment
and the top of this unit. Cooking equipment must have a barrier (i.e. bottom, drip pan) between its heat
source and the top of the equipment stand. Failure to comply with this could severely damage the equipment
stand and void all warranties.
F2000/F17 Series Equipment Stand Service and Installation Manual
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com
2
Delfield
™
®
Receiving And Inspecting ..........................................................2
F2000 Specifications ..................................................................3
F17 Specifications ......................................................................4
Installation ............................................................................. 5-6
Operation ...................................................................................6
Temperature Control Settings ....................................................7
Maximum Cooking Equipment Weight Capacity ........................7
Maintenance ........................................................................... 8-9
Refrigerator Wiring Diagrams ..................................................10
Freezer Wiring Diagrams .........................................................11
Replacement Parts by Model ............................................. 12-15
Condensing Unit Assemblies ...................................................16
Evaporator Coil Assemblies .....................................................17
Control Assemblies ..................................................................17
Drawer Assemblies ..................................................................18
Replacement Part Prints ..........................................................19
Standard Labor Guidelines .......................................................20
Warranties.......................................................................... 21-23
©2011 The Delfield Company. All rights reserved. Reproduction without written permis-
sion is prohibited. “Delfield” is a registered trademark of The Delfield Company.
The serial number on remote models is located behind the 6"
(15cm) stainless steel panel.
The serial number on self-contained models is located in the
compressor housing.
The serial number tag shows the refrigerant used and the amount
of charge and amperage.
Always have the serial number of your unit available when calling
for parts and service.
Contents Serial Number Location
Even though most equipment is shipped crated, care should be
taken during unloading so the equipment is not damaged while
being moved into the building.
1. Visually inspect the exterior of the package and skid or
container. Any damage should be noted and reported to the
delivering carrier immediately.
2. If damaged, open and inspect the contents with the carrier.
3. In the event that the exterior is not damaged, yet upon
opening, there is concealed damage to the equipment notify
the carrier. Notification should be made verbally as well as
in written form.
4. Request an inspection by the shipping company of the
damaged equipment. This should be done within 10 days
from receipt of the equipment.
5. Check the lower portion of the unit to be sure legs or casters
are not bent.
6. Also open the compressor compartment housing and
visually inspect the refrigeration package. Be sure lines are
secure and base is still intact.
7. Freight carriers can supply the necessary damage forms
upon request.
8. Retain all crating material until an inspection has been made
or waived.
Uncrating the Equipment
First cut and remove the banding from around the crate. Remove
the front of the crate material, use of some tools will be required.
If the unit is on legs remove the top of the crate as well and lift
the unit off the skid. If the unit is on casters it can be "rolled" off
the skid.
Receiving and Inspecting the Equipment
