200 & 300 SERIES
Service and Installation Manual
Please read this manual completely before attempting to install or operate this equipment!
Notify carrier of damage! Inspect all components immediately. See page 2.
Drop In and Undercounter Products
March 2009
IMPORTANT INFORMATION
READ BEFORE USE
PLEASE SAVE THESE INSTRUCTIONS!
CA
UTION
Delfield
™
®
200 and 300 Series Service and Installation Manual
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com
2
Delfield
™
®
Models Serial Tag Location
N225, N227 On the compressor stand next to the temperature control
203, 204, 204P, 248, 250, 305 On the bottom of the ice chests
240 On the back
242 On the bottom of the sink
307 Underneath the top
Always have the serial number of your unit available when calling
for parts or service.
©2009 The Delfield Company. All rights reserved. Reproduction without
written permission is prohibited. “Delfield” is a registered trademarks of The
Delfield Company.
Contents
Serial Number Information
Specifications
Receiving And Inspecting The Equipment
Serial Number Information ........................................................2
Receiving And Inspecting Equipment ........................................2
Specifications .............................................................................2
Installation ...............................................................................3-4
Operation ....................................................................................5
Maintenance ...............................................................................5
Replacement Parts ..................................................................6-8
Wiring Diagram ..........................................................................8
Standard Labor Guidelines ........................................................9
Standard Warranty ..............................................................10-11
Even though most equipment is shipped packaged, care
should be taken during unloading so the equipment is not
damaged while being moved into the building.
1. Visually inspect the exterior of the package and skid or
container. Any damage should be noted and reported to
the delivering carrier immediately.
2. If damaged, open and inspect the contents with the
carrier.
3. In the event that the exterior is not damaged, yet upon
opening, there is concealed damage to the equipment
notify the carrier. Notification should be made verbally as
well as in written form.
4. Request an inspection by the shipping company of the
damaged equipment. This should be done within 10 days
from receipt of the equipment.
5. Visually inspect the refrigeration package. Be sure lines
are secure and base is still intact.
6. Freight carriers can supply the necessary damage forms
upon request.
7. Retain all crating material until an inspection has been
made or waived.
MODEL L D H SHIP
WEIGHT
CUTOUT SIZE CABINET
CAPACITY
H.P. AMP VOLT NEMA
PLUG
DESIGN
LOAD BTU
SYSTEM
CAP. BTU
EVAP BTU/
TD/TEMP
DROP-IN FREEZERS
N225
16.56”
(42.1cm)
27.87”
(70.8cm)
26.75”
(67.9cm)
115lbs
(52kg)
25.75” x 14.62”
(65.4cm x 37.1cm)
6 gal. 1/5 5.3 115 5-15P 292 411 20/20°/-23°
N227
30”
(76.2cm)
27.87”
(70.8cm)
26.75”
(67.9cm)
191lbs
(87kg)
25.75” x 28.00”
(65.4cm x 71.1cm)
12 gal. 1/5 5.3 115 5-15P 473 532 28/19°/-22
DROP-IN REEZERS WITH LEXAN
®
LID
N225L
16.56”
(42.1cm)
27.87”
(70.8cm)
26.75”
(67.9cm)
115lbs
(52kg)
25.75” x 14.62”
(65.4cm x 37.1cm)
6 gal. 1/5 5.3 115 5-15P 292 411 20/20°/-23°
N227L
30”
(76.2cm)
27.87”
(70.8cm)
26.75”
(67.9cm)
191lbs
(87kg)
25.75” x 28.00”
(65.4cm x 71.1cm)
12 gal. 1/5 5.3 115 5-15P 473 532 28/19°/-22
DROP-IN WATER STATIONS AND ICE STORAGE
203
ice chest 20.25”
(51.4cm)
20.25”
(51.4cm)
23.25”
(59.1cm)
52lbs
(24kg)
19.25” x 19.25”
(48.9cm x 48.9cm)
90lbs
(41kg)
N/A N/A N/A N/A N/A N/A N/A
204
water and ice
station
24”
(61.0cm)
21”
(53.3cm)
23.5”
(59.1cm)
47.5lbs
(22kg)
21” x 17.75”
(53.3cm x 45.1cm)
45lbs
(20kg)
N/A N/A N/A N/A N/A N/A N/A
204P
water and ice
station
24”
(61.0cm)
21”
(53.3cm)
27”
(68.6cm)
47.5lbs
(22kg)
21” x 17.75”
(53.3cm x 45.1cm)
45lbs
(20kg)
N/A N/A N/A N/A N/A N/A N/A
240
ice chest with
cover
21”
(53.3cm)
17.5”
(44.5cm)
17”
(43.2cm)
36lbs
(16kg)
— 75lbs
(34kg)
N/A N/A N/A N/A N/A N/A N/A
248
water and ice
station
31”
(78.7cm)
15”
(38.1cm)
22.5”
(57.2cm)
28lbs
(13kg)
28” x 12.5”
(71.1cm x 31.8cm)
45lbs
(20kg)
N/A N/A N/A N/A N/A N/A N/A
305
ice chest with
cover
21.25”
(54.0cm)
15.25”
(38.7cm)
13”
(33.0cm)
18lbs
(8kg)
12.5” x 17.75”
(31.8cm x 45.1cm)
45lbs
(20kg)
N/A N/A N/A N/A N/A N/A N/A
307
glass filler 12”
(30.5cm)
12”
(30.5cm)
9.5”
(24.1cm)
7lbs
(3kg)
9.00” x 9.00”
(23cm x 23cm)
— N/A N/A N/A N/A N/A N/A N/A
UNDERCOUNTER SINKS, WATER STATIONS AND ICE STORAGE
242
UC sink & faucet 18”
(45.7cm)
13.5”
(34.3cm)
12.75”
(32.4cm)
20lbs
(9kg)
17” x 12.5”
(43.2cm x 31.8cm)
— N/A N/A N/A N/A N/A N/A N/A
250
UC sink, ice chest
and water station
46”
(116.8cm)
14.12”
(35.9cm)
22.75”
(57.8cm)
81lbs
(37kg)
45” x 13”
(114.3cm x 33.0cm)
45lbs
(20kg)
N/A N/A N/A N/A N/A N/A N/A
