Side 1/3

MICROBOX AMPLIFIED

LOADED ENCLOSURE

MICROBOX AMPLIFIED

LOADED ENCLOSURE

( A division of CV & DA Holdings, Inc.)

DESMB8A/DESMB8DA

DESMB10A/DESMB10DA

DESMB12A

DESMB8A/DESMB8DA

DESMB10A/DESMB10DA

DESMB12A

DES

SERIES

DES Microbox Manual 2023 | Spread 1 of 2 - Pages (6,1)

Diamond Audio (a division of CV & DA Holdings, Inc.) warrants this product to be free from defects in

material for a period of one (1) year from the original date of purchase provided it was purchased from

an authorized DAT retailer within the United States. However, if this product was installed by authorized

DA retailer, the warranty period will be extended to two (2) years.

THIS WARRANTY IS NOT TRANSFERABLE AND APPLIES ONLY TO THE ORIGINAL PURCHASE OF THIS

PRODUCT IN ITS ORIGINAL INSTALLATION. Original purchaser must reside in the United States and be

able to provide proof of purchase and installation with the sales from the authorized DAT retailer and

completion of online registration that sold and installed the product.

Should a manufacturing defect occur during above said warranty period, DA will replace or repair the

defective product with a product of the same or equivalent value and performance.

Damage or failure caused by any of the following is not covered under this warranty policy: negligence,

improper use, abuse, product modification, unauthorized repair attempts, accident, acts of God,

misrepresentations by DA retailers, and improper/inadequate packaging during return shipping.

Warranty is void if serial numbers have been removed, altered or defaced.

In the event a DA product should require service, you should visit the authorized DA retailer you

purchased the product from and they can expedite your claim. All claims must fall into the guidelines

listed above and be accompanied by a copy of the original sales and installation receipt from that

authorized DA retailer.

Product returned for warranty service must be freight-prepaid, properly packaged and clearly marked

with the Return Authorization (RA) number issued by DA. Any product returned to DAT that is improperly

packaged, does not have a RA number clearly marked on the package, or never received a RA number

may be refused upon delivery. DA does not assume responsibility for lost or misdirected product.

Repair or replacement under this warranty is the exclusive remedy of the consumer. DA shall not be

liable for any incidental or consequential damages for breach of any expressed or implied warranty on

this product. Some states do not allow the exclusion or limitation of incidental or consequential damages,

or allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not

apply to you. This warranty gives you specific legal rights and you may also have other rights that may

vary from state to state.

Customer outside the United States should contact their local sales office to obtain information on

pricing, exchange unit availability, instructions, service and warranty/non-warranty replacement

or repair.

3761 South Hill St.

Los Angeles, CA 90717

Tel: 213-261-4161

Fax: 213-947-4767

Web: diamondaudio.com

Facebook.com/DiamondAudio

213-261-4161

helpdesk@dat-cvm.com

( A division of CV & DA Holdings, Inc.)

SINGLE

DUAL

DES Microbox Manual 2024 | Spread 2 of 2 - Pages (2,3)

Dimension

Length (A)

Height (C)

Depth (B)

in. (mm)

Unit

DESMB8A DESMB10A

18” (457.2)

6.4” (156.2)

12” (305)

20.9” (533)

7.8” (200)

12.9” (330)

DESMB12A

24” (609)

11” (277)

14.4” (368)

Dimension

Length (A)

Height (C)

Depth (B)

in. (mm)

Unit

DESMB8DA DESMB10DA

34.4” (875.5)

6.4” (156.2)

12” (305)

40.3” (1024)

7.8” (200)

12.9” (330)

Model

DESMB8A

DESMB10A

DESMB8DA

2Ω

Nominal Impedance

RMS Power MAX Power

250W

500W

Grille

OD187.2, H29

DESMB10DA

DESMB12A

2Ω

250W

500W

OD187.2, H29

350W

700W

OD238.6, H29.5

500W

1000W

OD238.6, H29.5

500W

1000W

OD287.2, H29.5

About the Diamond Audio Experience:

Congratulations, you have just purchased the finest mobile audio products on the market to date.

At Diamond Audio, our products represent the latest advances in acoustic technology in sound

reproduction for your vehicle. Diamond Audio products are designed, developed, and engineered using the

latest innovative materials and components to provide the finest sound reproduction possible. Every

Diamond Audio product has been verified and tested by Klippel equipment to ensure the best sound and

most reliable product on the market today. If installed correctly, Diamond Audio products will provide

many years of the ultimate listening experience.

Please note that prolonged exposure to sound pressure levels in excess of 100dB can cause permanent

hearing loss. Using Diamond audio products can exceed that level, so please exercise restraint in its

operation to preserve your ability to enjoy its high-fidelity sound for

years to come.

Diamond Audio recommends an authorized Diamond Audio dealer professionally install our products to

achieve the best possible system performance and longevity. Installation by a professional will ensure an

authentic Diamond Audio listening experience and the sound you would expect from Diamond Audio

products. Also, doing this will extend your warranty from one year to two years.

Diamond Audio’s Microbox Enclosure system delivers impressive bass output in a small package! These

Microbox Enclosures come preloaded with a single or dual pair option of true DES Series subwoofers and

powerful internal amplifiers for the perfect match up. After many hours of fine-tuning this subwoofer and

developing the perfect slot-port application, these Microbox subs outperform even larger systems.

Constructed with high-strength MDF, extensive bracing, and lock-tight fastening, it means no leaks and

distortion-free bass response. - Go ahead, Hear the Music!

These MICROBox subwoofer systems pack a punch. We highly recommend bolting the enclosures down

with L brackets or some restraint to keep them from moving around when the vehicle is in motion. The

amplifiers are equipped with quick disconnects if the enclosure needs to be removed or replaced for

space considerations.

We recommend a minimum of 8GA copper power wire for all models for the best amplifier

performance.

NO CCA wire. CCA wire will void your warranty, reduce the performance of your system, and could

cause harm to your system or vehicle.
