Side 1/111

L3 Managed

Switches

CLI Manual

DN-651160, DN-651161

- 2 -

Table of Contents

L3 Managed Switches ........................................................................... 1

Chapter 1 System Status Commands .................................................... 7

1.1 Command Mode ....................................................................................... 7

1.2 System information ................................................................................... 8

1.2.1 Show system ........................................................................................... 8

1.3 Log information ........................................................................................ 8

1.3.1 Show logging ........................................................................................... 8

1.4 Port statistics ............................................................................................ 9

1.4.1 Show interface ........................................................................................ 9

1.5 View route ............................................................................................... 10

1.5.1 Show ip route ........................................................................................ 10

Chapter 2 System Setup Commands ................................................... 11

2.1 IP config ................................................................................................... 11

2.1.1 ip address .............................................................................................. 11

2.1.2 ip address dhcp ..................................................................................... 11

2.1.3 ip address old_ip ................................................................................... 12

2.1.4 Show interface ...................................................................................... 12

2.2 User config ............................................................................................... 13

2.2.1 Username name .................................................................................... 13

2.3 Time setting ............................................................................................ 14

2.3.1 sntp enable|disable .............................................................................. 14

2.3.2 sntp unicast-server ................................................................................ 14

2.3.3 sntp auto-sync timer ............................................................................. 15

2.3.4 sntp connect .......................................................................................... 15

2.3.5 timezone ............................................................................................... 15

Chapter 3 Port Configuration Commands ........................................... 16

3.1 Port config ............................................................................................... 16

3.1.1 Speed ..................................................................................................... 16

3.1.2 flow-control ........................................................................................... 17

3.1.3 Shutdown .............................................................................................. 17

3.1.4 Description ............................................................................................ 18

3.2 Rate limit ................................................................................................. 18

3.2.1 rate-limit................................................................................................ 18

3.3 Port mirroring .......................................................................................... 19

3.3.1 Monitor ............................................................................................ 19

3.4 Link aggregation ...................................................................................... 20

3.4.1 Trunk ..................................................................................................... 20

3.4.2 load-balance .......................................................................................... 21

3.4.3 lacp enable | disable ............................................................................. 21

3.4.4 lacp active | passive .............................................................................. 22

3.4.5 lacp port-key ......................................................................................... 22

3.4.6 lacp port-priority ................................................................................... 23

3.4.7 Example ................................................................................................. 23

Produkt Specifikationer

Mærke:	Digitus
Kategori:	bryter
Model:	DN-651161
Kode for international beskyttelse (IP):	IP40
Bredde:	175.6 mm
Dybde:	135 mm
Højde:	45.5 mm
Vægt:	800 g
Produktfarve:	Black, Blue
Pakkevægt:	575 g
Pakkedybde:	72.5 mm
Pakkebredde:	186 mm
Pakkehøjde:	208 mm
Opbevaringstemperatur (T-T):	-40 - 80 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 95 %
Strømforbrug (typisk):	18 W
Driftstemperatur (T-T):	-40 - 80 °C
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Husmateriale:	Metal
Hurtig start guide:	Ja
Strømkilde:	DC/PoE
Netværksstandarder:	IEEE 802.3af
Servicekvalitet support (QoS):	Ja
LED-indikatorer:	Ja
DC indgangsspænding:	12 - 48 V
Oprindelsesland:	Kina
Firmware kan opgraderes:	Ja
Fiber optisk strømstik:	SFP+
Fuld duplex:	Ja
Strøm over Ethernet (PoE):	Ja
Gennemsnitstid mellem fejl (MTBF):	300000 t
Switch-type:	Administreret
ARP inspektion:	Ja
Switch lag:	L2/L3
Total Power over Ethernet (PoE):	30 W
10G understøttelse:	Ja
VLAN understøttelse:	Ingen
Flowkontrol support:	Ja
Port-spejlning:	Ja
Link aggregering:	Ja
Broadcast stormkontrol:	Ja
Basis omskiftning RJ-45 Ethernet porte, antal:	8
Basis omskiftning RJ-45 Ethernet porttype:	Gigabit Ethernet (10/100/1000)
IGMP snooping:	Ja
Adgangskontrolliste (ACL):	Ja
Loop beskyttelse:	Ja
Opbevar-og-frem:	Ja
MAC adresselabel:	32000 entries
Switch kapacitet:	1 Gbit/sek.
Jumbo Frames support:	Ja
Jumbo rammer:	10240
Stativ-montering:	Ingen
Multicast-understøttelse:	Ja
Gigabit Ethernet (kobber) porte, antal:	8
Egnet til udendørs brug:	Ingen
Strømforsyning inkluderet:	Ja
Halv dupleks:	Ja
Stabelbar:	Ingen
Sikret mod hærværk:	Ingen
DIN-skinne montering:	Ja
Kode i den britiske toldtarif:	85176200
Pakkevolumen:	2804.88 cm³
DHCP funktioner:	DHCP relay, DHCP server, DHCP snooping
Antal installerede SFP+ moduler:	4
Redundant strømforsyning:	Ja
Overspændingsbeskyttelse:	4 kV
Beskyttelse ved overspænding:	Ja
Routing-protokoller:	OSPF, OSPFv3, RIPng, VRRP
GARP VLAN registreringsprotokol (GVRP):	Ja
Ethernet ringbeskyttelsesskift (ERPS):	Ja
Antal administrationsporte:	1 stk
