Side 1/8

2.1

1.1

2.1

Contents

Introduction 1

Installation 1

Use, safety 3

Cleaning and hygiene 5

Fault nding 6

Maintenance 7

Conformity with regulation 8

Introduction

1.1 DESCRIPTION

• These 11.5 and 17.5 litre capacity cutters are machines de-

signed for cookery professionals for mincing, mixing, emulsifying,

liquidising, kneading, etc. and can be used to process all types of

foodstu󰀨s (meat, vegetables, fruits, condiments, pastry, mayon-

naise, etc.).

• For special preparations other than foodstu󰀨s, PLEASE ASK

US FOR DETAILS.

A Motor cover

B Removable funnel

C Removable lid arm assembly

D Transparent BPA-free tritan lid

E Stainless steel bowl

F Bowl locking knob

G Bowl locking clamps

Installation

2.1 DIMENSIONS - WEIGHT (FOR INFORMATION ONLY)

- Dimensions of packaging: (L x l x h) mm:

. 11,5l -17,5 modelx : 795 x 515 x 805 mm

. Optional table: 750 x 600 x 200

- Overall dimensions (mm):

2.2 LOCATION

• These machines are designed to be tted onto a work top (table,

base, etc.) of between 400 and 900 mm in height. The four feet

ensure that it remains perfectly stable.

• A stainless steel mobile table is available in option for the

cutters.

This document is to be used in conjunction with the original manufacturer’s manual.

The symbols correspond with the numbered drawings of the original manual.

04/2024

H Body

I Fascia

J Mains power switch

(17.5l model only)

K Stainless steel housing

L Rubber feet

Introduction

The User Manual contains useful information for the user on how

to work correctly and in complete safety, and is designed to make

it easier to use the machine (called «machine» or «appliance»

below).

What follows is in no case intended to be a long list of warnings and

constraints, but rather a series of instructions meant to improve the

service provided by the machine in every respect, and particularly

to avoid a series of injuries or damage to equipment that might

result from inappropriate procedures for use and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or dis-

mantling the machine should consult this manual and read it

carefully before proceeding with the various operations, in order

to avoid any incorrect or inappropriate handling that might be

result in damage to the machine or put people’s safety at risk.

It is just as important that the Manual should always be available

to the operator and it should be kept carefully where the machine

is used ready for easy and immediate consultation in case of any

doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who is

constantly available to ensure quick and careful service for im-

proved machine operation and optimum e󰀩ciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

- Gross weight when packaged : 11,5/17,5: 73/83 kg

- Net weight: 11,5/17,5: 59/69 kg

1 K120/180 GB 07 2018

ATTENTION!!

Machine storage: -25°C to +50°C

Ambient temperature during operation: +4°C to +40°C

This machine is for professional use and must be used by sta󰀨 trained to use, clean and maintain it, in terms or reliability and safety.

Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard

EN 12464-1)

When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the

lower limbs.

The machine is not designed for use in explosive atmospheres.

The reference language for these instructions is French.

K120/180 GB 04 2024 2

Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than

those of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions EN60204-1;

- Maximum voltage variation: ±10%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Before connecting the machine to the electrical power supply, check that the voltage of the electrical system is the same as that

marked on the rating plate.

- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using

a circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and

machine specications - see the specications shown in column G of gure 2.3a

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1

(IEC 60204-1) with the use of protection devices for automatic shut-o󰀨 of power in the event of an insulation fault with

a TN or TT system, or, for the IT system, with the use of a permanent insulation or di󰀨erentials controller for automatic

shut-o󰀨. The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TN or TT system, a di󰀨erential circuit breaker must be installed upline of the power supply, with a

suitable power cut-o󰀨 (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-

dents due to direct or indirect contacts.

ATTENTION !!

2.3 ELECTRICAL CONNECTION

2.3a

• The 11,5 and 17,5 litre cutters are only available as standard in

three phase, single voltage versions, with two speeds. The 11,5

litre model is also available in single phase supply with speed

variation.

• Motor characteristics:

A Motor code

B Number of phases (3 three phase)

C Nominal voltage in volts (value, range or commutation)

D Frequency (Hertz)

E Motor speed (rpm)

F Nominal power (Watts)

G Nominal current (Amperes)

H Rating of fuse for protecting the electrical line (Amperes)

I Indicative electrical consumption (kWh)

a) Three phase, single voltage 2 speed motor

• Provide an accessible wall-mounted power outlet standardized

with 3 poles + Ground, rated 20 A compliant with IEC60309, and

a corresponding waterproof plug to be mounted on the power

cord.

- If it is turning in the wrong direction, change over the two phase

wires of the plug.

b) Three phase, single voltage one speed motor with fre-

quency variator

• The cutter is supplied with a single phase current up to its

variator, which transforms the current to supply the three phase

motor.

• Provide an accessible standardized wall outlet with 2 poles

+ ground, rated at 10/16A in accordance with IEC60309, and a

corresponding waterproof plug to be installed on the power cord.

•

Check that the mains voltage matches that on the rating plate.

• Check the direction of rotation of the rotor at both speeds:

- Turn the mains power switch (depending on model) in a clo-

ckwise direction to the position.I

- Press button (pulse operation) (see § 3.1).J

- Check the direction in which the rotor is turning through the

transparent lid (anti-clockwise - as per the arrow marked

on the rotor handle).

The machine must be earthed with the green and yellow wire.

Note: The machine can only be used on TN (earthing to

neutral) and TT (earthed neutral) type supplies. Where a

machine has to be installed on an IT (impeding or isolated

neutral) supply, there is a solution which consists of inserting

an isolating transformer and locally putting on the machine

on TN or TT supply.

The machine must be earthed with the green and yellow wire.

No earth plug = no protection = risk of breakdown.

• Warning to the installer:

This cutter with electronic speed variation is equipped with a lter

built into the variator which earths any system interference without

passing through the variator. In order to be e󰀨ective, the installation

must have a good quality earth, otherwise the interference could

pass through the variator and damage it.

Damage caused by inadequate earthing is not covered by

the guarantee.

Note: The earth values are dened according to the residual

di󰀨erential current and must be checked by an electrician.
