Side 1/8

Contents

Please refer to the numbered drawings which correspond to the paragraph

numbers in the instruction manual.

Introduction 1

Installation 1

Use and safety 3

Cleaning and hygiene 5

Fault nding 6

Maintenance 6

Compliance with regulations 8

Introduction

1.1 DESCRIPTION

• These beater-mixers are professional bakery/pastry maker

appliances designed for kneading, mixing and whisking all food

products. The A versions when tted in the kitchen, can be used

to power accessory machines.

A Stainless steel bowl, 20/30 litre capacity

(Depending on model)

B Removable protection screen and with additional plastic

screen

C H-type accessories hub

D Head

E Control panel

F Speed change lever

G Raising and lowering lever

H Planet gear

I Column

J Bowl support cradle

K Feet

• There are 3 standard tools available :

A A spiral hook for kneading dough

B A paddle for mixing

C A whisk for emulsifying

• Optional equipment :

- Strengthened 20 L whisk for di󰀩cult work

- Reduced bowl of 10L with 3 tools (models 20l)

- Reduced bowl of 20L and 30L with 3 tools (models 30l)

- Stainless steel table (height 480mm) for 20l table model.

•Optional equipment for A accessory hub versions only:

- Accessory machines (see § 3-6).

- Plate holder to collect products under the mincer, vegetable

slicer and sieve.

Installation

XBM20/30 GB 09 20231

09/2023

1.1b

Introduction

The User Manual contains useful information for the user on how

to work correctly and in complete safety, and is designed to make it

easier to use the machine (called “machine” or “appliance” below).

What follows is in no case intended to be a long list of warnings

and constraints, but rather as a series of instructions meant to

improve the service provided by the machine in every respect,

and particularly to avoid a series of injuries or damage to equip-

ment that might result from inappropriate procedures for use

and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or dis-

mantling the machine should consult this manual and read it

carefully before proceeding with the various operations, in order

to avoid any incorrect or inappropriate handling that might be

result in damage to the machine or put people’s safety at risk.

It is just as important that the Manual should always be available

to the operator and it should be kept carefully where the machine

is used ready for easy and immediate consultation in case of any

doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who is

constantly available to ensure quick and careful service for im-

proved machine operation and optimum e󰀩ciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

ATTENTION!!

Machine storage: -25°C to +50°C

Ambient temperature during operation: +4°C to +40°C

This machine is for professional use and must be used by sta󰀨 trained to use, clean and maintain it, in terms or reliability and safety.

Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard

EN 12464-1)

When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the

lower limbs.

The machine is not designed for use in explosive atmospheres.

The reference language for these instructions is French.

2.2 INSTALLATION

• The 20/30 litre mixers are oor-standing only.

• To chock or level the beater:

- Remove the foot end piece before adjusting.

- Screw with a screwdriver so that the adjustable pad makes

contact.

- Check it is stable by running the beater at high speed with its

beater. Where necessary, the adjustment can be ne-tuned

with the machine running.

- Ret the plug.

•

To x the beater to the oor: x by the rear feet

- Remove the end pieces from the 2 rear feet.

- Mark the 2 holes to be drilled (Ø8 max. screw, min. length 80,

plugs not supplied).

Note : It is also possible to x to the oor by the front feet,

by removing the adjustable pad.

• The 20 litre table mixers can be installed on:

- perfectly stable, non resonant support (unit, table, etc) of height

between 350 and 500 mm.

- an optional stainless steel table with storage shelf.

• To install, proceed as follows:

- Remove the adjustable pads from the front feet.

- Line up the 4 feet xing holes on the mixer with those on the

table.

- Fix the mixer on the table using the screw set provided.

• To chock or make the table level:

- Unscrew the screws xing the pads (13 mm pipe wrench).

- Adjust the pad, then lock in position.

- Check for stability by running the mixer at high speed with its

paddle.

• To embed the table in the oor :

- Counter drill the pad xing holes (plugs and screws max ø 8,

length min 30, not supplied).

2.2a

2.2c

2.2b

2.1 DIMENSIONS - WEIGHT (for information only)

A Gross weight when packaged (kg)

B Net weight equipped (kg)

C Packaging dimensions (mm) L x W x H

D Machine dimensions: L x W x H (mm)

E Dimensions for beater bedding: E x E1 x E2 (mm)

Hp Accessories hub height (A models)

. Handling - Transport

- The beater is delivered xed to a wooden pallet.

- Use a forklift truck to remove it from the pallet, slipping the

forks beneath the feet.

If unloaded manually, take all necessary precautions to

ensure the appliance does not tip at all

2.3 ELECTRICAL CONNECTION

ATTENTION!!

Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than

those of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions (EN60204-1);

- Maximum voltage variation: ±10%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Check that the electric mains voltage, the value shown on the specication plate.

- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) by using

fuses or thermal relays of the appropriate gauge relative to the place of installation and machine specications – see the spe-

cications shown in column F of gure 2.3a

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1

(IEC 60204-1) with the use of protection devices for automatic shut-o󰀨 of power in the event of an insulation fault with

a TN or TT, system, or for the IT system, with the use of a permanent insulation or di󰀨erentials controller for automatic

shut-o󰀨. The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TT system, a di󰀨erential circuit breaker must be installed upline of the power supply, with a suitable

power cut-o󰀨 (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-

dents due to direct or indirect contacts.

XBM20/30 GB 09 2023 2
