Side 1/8

Contents

Refer to the numbered drawings that go with the numbered paragraphs in the instructions

Introduction 1

Installation 1

Use and Safety 3

Cleaning and hygiene 5

Fault nding 6

Maintenance 6

Compliance with regulations 8

Introduction

1.1 DESCRIPTION

• These electronic beater-mixers are professional bakery and

pastry-making appliances designed for kneading, mixing and

whisking all kinds of food products. The A version appliances

are suitable for kitchens and can be used to drive accessory

appliances.

A Stainless steel bowl, 20 or 30 litre capacity

(depending on model)

B Removable safety guard and with additional plastic screen

C Type H accessories socket

D Head

E Control panel

G Lift/lower lever

H Planetary gear system

I Column

J Bowl cradle

K Feet

• 3 tools are available as standard supply:

A Hook for kneading.

B Paddle for mixing.

C Whisk for emulsions

• Optional equipment:

- 20 and 30 L reinforced whisk for heavy work.

- Reduction bowl 10 L with 3 tools (20 L model)

- Reduction bowl 10/20 L with 3 tools (30 L model)

- Stainless steel table (height 480mm) for 20l table model.

• Optional equipment for versions with accessory socket A only:

- Accessory appliances (see § 3-6)

- Plate-holders for collection of products underneath the mincer,

vegetable preparation attachment, sieve.

Installation

XBE20/30 GB 10 20231

1.1b

10/2023

Introduction

The User Manual contains useful information for the user on how

to work correctly and in complete safety, and is designed to make it

easier to use the machine (called “machine” or “appliance” below).

What follows is in no case intended to be a long list of warnings

and constraints, but rather as a series of instructions meant to

improve the service provided by the machine in every respect,

and particularly to avoid a series of injuries or damage to equip-

ment that might result from inappropriate procedures for use

and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or dis-

mantling the machine should consult this manual and read it

carefully before proceeding with the various operations, in order

to avoid any incorrect or inappropriate handling that might be

result in damage to the machine or put people’s safety at risk.

It is just as important that the Manual should always be available

to the operator and it should be kept carefully where the machine

is used ready for easy and immediate consultation in case of any

doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who is

constantly available to ensure quick and careful service for improved

machine operation and optimum e󰀩ciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

ATTENTION!!

Machine storage: -25°C to +50°C

Ambient temperature during operation: +4°C to +40°C

This machine is for professional use and must be used by sta󰀨 trained to use, clean and maintain it, in terms or reliability and safety.

Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard

EN 12464-1)

When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the

lower limbs.

The machine is not designed for use in explosive atmospheres.

The reference language for these instructions is French.

2.2 LOCATION

• The 20/30 litre mixers are oor-standing only.

• To chock or make the beater level:

- Remove the cap from the front foot to be adjusted.

- With a screw driver, turn the adjustable foot until it is in

contact.

- Check the machine is stable by running the mixer at high speed

with its paddle. If necessary the foot can be adjusted more

precisely with the machine running.

- Replace the cap.

• To embed the mixer in the oor: embedding the rear feet:

- Remove the caps from the 2 rear feet.

- Identify the 2 holes to be drilled (screw Ø8 max., length 80

min., plugs not supplied).

Note: It is also possible to embed the front feet, in which

case the adjustable foot is to be removed.

• The 20 litre table mixers can be installed on:

- perfectly stable, non resonant support (unit, table, etc) of height

between 350 and 500 mm.

- an optional stainless steel table with storage shelf.

• To install, proceed as follows:

- Remove the adjustable pads from the front feet.

- Line up the 4 feet xing holes on the mixer with those on the

table.

- Fix the mixer on the table using the screw set provided.

• To chock or make the table level:

- Unscrew the screws xing the pads (13 mm pipe wrench).

- Adjust the pad, then lock in position.

- Check for stability by running the mixer at high speed with its

paddle.

• To embed the table in the oor :

- Counter drill the pad xing holes (plugs and screws max ø 8,

length min 30, not supplied).

2.2a

2.2b

2.2c

2.1 DIMENSIONS - WEIGHT (for information only)

A Gross weight when packaged:

B Net weight when equipped (kg)

C Package dimensions (mm) L x w x h

D Overall dimensions of machine: L x w x H (mm)

E Dimensions for tting beater: E x E1 x E2 (mm)

Hp Height of accessory socket (A models)

Handling - Transport

- The beater is delivered xed to a wooden pallet.

- Use a forklift truck to remove it from the pallet, slipping the

forks beneath the feet.

If unloaded manually, take all necessary precautions to

ensure the appliance does not tip at all

2.3 ELECTRICAL CONNECTION

ATTENTION!!

Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than

those of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions (EN60204-1);

- Maximum voltage variation: ±10%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Check that the electric mains voltage, the value shown on the specication plate.

- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using a

circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and machine

specications – see the specications shown in column F of gure 2.3a

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC

60204-1) with the use of protection devices for automatic shut-o󰀨 of power in the event of an insulation fault with a TN or

TT, system, or for the IT system, with the use of a permanent insulation or di󰀨erentials controller for automatic shut-o󰀨.

The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TN or TT system, a di󰀨erential circuit breaker must be installed upline of the power supply, with a

suitable power cut-o󰀨 (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-

dents due to direct or indirect contacts.

XBE20/30 GB 10 2023 2
