Side 1/8

Contents

Di󰀨erent models

Di󰀨erent models 1

Introduction 1

Installation 2

Use, safety 3

Cleaning and hygiene 5

Fault nding 6

Maintenance 7

Conformity with regulations 8

• Beater-mixers of 60/80 litre

capacity with accessory hub, corrosion-proofed for meat

processing. Manual or electric controls.

• All of these models are also available in stainless steel.

• Check that the model and its characteristics correspond on the

identication plate attached to the frame.

This document is to be used in conjunction with the original manufacturer’s manual.

The symbols correspond with the numbered drawings of the original manual.

1.1a

1.1b

• Beater-mixer of 60 litre capacity with manual

controls for the speed variator and the bowl cradle.

• Beater-mixers of 60/80 litre capacity with electric controls for

the speed variator and the bowl cradle.

• Beater-mixers of 60/80 litre capacity with accessory hub. Manual

or electric controls.

Introduction

1.1 DESCRIPTION

• These beater mixers are professional bakery - confectionery

machines for kneading, mixing and whisking all types of foods-

tu󰀨s. The models "A" are adapted for use in the kitchen and

can be used to drive accessories.

A Stainless steel bowl, 60/80 litre capacity

B Protective guard with removable spout and with

additional plastic screen

C Planetary gear

D Control panel

E Head

F Manual control for changing the speed

G Column

H Manual control for bowl cradle (BMX 60)

I Bowl locking knob

J Bowl cradle

K Leg

L Rubber foot

• There are 3 standard tools available as standard:

A A spiral hook for kneading dough.

B A paddle for mixing.

C A whisk for emulsifying.

•

Common optional equipment for the 60/80 l models "A":

- Strengthened 40 litre and 60 litre whisks for di󰀩cult work.

- Reduced bowl of 40 litre with 3 tools (60/80 l).

- Reduced bowl of 60 litre with 3 tools (80 l).

- 60 litre perforated paddle for light mixing.

- 40/60 litre mixer for mixing meat (meat processing).

- 60/80 litre bowl scraper.

- 60 and 80 litre bowl trolleys (supplied as standard with the 80l).

• Optional equipment for 60/80 l models "A" only:

- Machine accessories (see §3-5).

- Dish holder for collecting products under the mincer, vegetable

cutter, sieve.

11/2023

Introduction

The User Manual contains useful information for the user on how

to work correctly and in complete safety, and is designed to make

it easier to use the machine (called «machine» or «appliance»

below).

What follows is in no case intended to be a long list of warnings and

constraints, but rather a series of instructions meant to improve the

service provided by the machine in every respect, and particularly

to avoid a series of injuries or damage to equipment that might

result from inappropriate procedures for use and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or dis-

mantling the machine should consult this manual and read it

carefully before proceeding with the various operations, in order

to avoid any incorrect or inappropriate handling that might be

result in damage to the machine or put people’s safety at risk.

It is just as important that the Manual should always be available

to the operator and it should be kept carefully where the machine

is used ready for easy and immediate consultation in case of any

doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who is

constantly available to ensure quick and careful service for im-

proved machine operation and optimum e󰀩ciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

1 BMX 60/80 GB 06 2015

The reference language for these instructions is French.

2.1a-b

Installation

In the case of the machine being handled manually, take

all necessary precautions to avoid it tilting, especially

forwards (centre of gravity marked G).

- To remove it from the pallet, raise the beater with a fork lift truck

(lifting points marked F).

2. DIMENSIONS - WEIGHT (for information only)1

A Gross weight packaged (kg).

B Net weight with equipment (kg).

C Dimensions of packaging (mm).

D Size of machine: L x W x H (mm).

• Handling - transport

- The beater is supplied packed on a wooden pallet.

2.1a

ATTENTION!!

Machine storage: -25°C to +50°C

Ambient temperature during operation: +4°C to +40°C

This machine is for professional use and must be used by sta󰀨 trained to use, clean and maintain it, in terms or reliability and safety.

Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard

EN 12464-1)

When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the

lower limbs.

The machine is not designed for use in explosive atmospheres.

2.2 LOCATION

• To pack or level the machine (max. adjustment 10 mm):

- Unscrew the attachment screws of the feet (13 mm socket

spanner).

- Adjust the foot then lock in position.

- Check that it is stable by running the machine at high speed

with the paddle.

• To anchor the machine or table to the ground:

- Counter drill the attachment holes of the feet (8 mm dia. screw

max., min. length 30 mm, rawl plugs not supplied).

2.3 ELECTRICAL CONNECTION

ATTENTION!!

Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than

those of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions EN60204-1;

- Maximum voltage variation: ±10%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Check that the electric mains voltage, the value shown on the specication plate.

- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using a

circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and machine

specications – see the specications shown in column G of gure 2.3a

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC

60204-1) with the use of protection devices for automatic shut-o󰀨 of power in the event of an insulation fault with a TN or

TT, system, or for the IT system, with the use of a permanent insulation or di󰀨erentials controller for automatic shut-o󰀨.

The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TN or TT system, a di󰀨erential circuit breaker must be installed upline of the power supply, with a

suitable power cut-o󰀨 (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-

dents due to direct or indirect contacts.

BMX 60/80 GB 11 2023 2
