Refer to the numbered drawings that relate to the numbered paragraphs

K45-55-70 GB 10 06

1.1

2.1

Contents

Introduction 1

Installation 1

Use and safety 2

Cleaning and hygiene 4

Fault-ﬁnding 4

Maintenance 4

Compliance with regulations 5

Parts list - exploded view A

Electrical diagrams M

Introduction

1.1 DESCRIPTION

• This professional food processor / emulsiﬁer can be used in

the preparation of minces, blends and emulsions, in particular

in a hospital environment, in gourmet catering and in dietetics.

It can also be used as a food processor / mixer by removing the

scraper for grinding or kneading the hardest of products.

• For special preparations which do not come under the scope

of food: (PLEASE CONTACT US)

A Removable bowl-lid scraper handle with

centre pourer hole

B Removable transparent lid with centre pourer hole

C Lid locking handle

D Bowl handle

E Bowl (capacity 4.5, 5.5 or 7 litres depending on model)

F Casing

G Non-slip pads

H Body

I Power supply lead

J Control panel

K Locking pin

Installation

2.1 DIMENSIONS - WEIGHT (INDICATION ONLY)

A Gross packaged weight (Kg)

B Net weight (Kg)

C Packaging dimensions (mm): L x W x H

D Machine dimensions: L x W x H (mm)

E Space required for opening and removal: L1 x W x H1

(mm)

09/2021

Introduction

The User Manual contains useful information for the user on

how to work correctly and in complete safety, and is designed

to make it easier to use the machine (called “machine” or “ap-

pliance” below).

What follows is in no case intended to be a long list of warnings

and constraints, but rather as a series of instructions meant to

improve the service provided by the machine in every respect,

and particularly to avoid a series of injuries or damage to equi-

pment that might result from inappropriate procedures for use

and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or dismant-

ling the machine should consult this manual and read it carefully

before proceeding with the various operations, in order to avoid

any incorrect or inappropriate handling that might be result in

damage to the machine or put people’s safety at risk.

It is just as important that the Manual should always be available

to the operator and it should be kept carefully where the machine

is used ready for easy and immediate consultation in case of any

doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who

is constantly available to ensure quick and careful service for

improved machine operation and optimum efﬁciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

ATTENTION!!

Machine storage: -25°C to +50°C

Ambient temperature during operation: +4°C to +40°C

This machine is for professional use and must be used by staff trained to use, clean and maintain it, in terms or reliability and

safety.

Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard

EN 12464-1)

When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the

lower limbs.

The machine is not designed for use in explosive atmospheres.

2.2 POSITION

• Stand the appliance on a working surface (table, base, etc.)

of a height of between 700 and 900 mm. Its 4 pads provide it

with perfect stability.

• It does not need to be ﬁxed and can easily be moved.

The reference language for these instructions is French.

• Warning to the installer:

This electronic variable speed food processor is ﬁtted with an

integral ﬁlter which does not pass through the variable speed

unit. To be effective, the machine's earth must be of good quality,

otherwise interference may pass through via the variable speed

unit and damage it.

• No earth connection = no protection = risk of failure +

DANGER for the user!

Note: The earth values are deﬁned according to the residual

differential current (See standard NFC 15100 and PROMOTELEC

guide) and must be checked by an electrician.

• This food processor is available in three versions:

- Single speed : Single phase - one voltage only.

- Two-speed : Three-phase - one voltage only.

- Variable speed : Single phase - one voltage only.

• Check that the electric mains voltage and the value shown on

the speciﬁcation plate.

• The machine must be protected by a residual current device

(RCD) and one fuse per phase, of a rating shown in column Fof

the speciﬁcations.

• Motor speciﬁcations:

A Number of phases (1 = single phase or 3 = three-phase)

B Nominal voltage in volts

C Frequency (Hertz)

D Nominal rating (Watts)

E Nominal current (Amperes)

F Rating of the fuse protecting the electric line (Amperes)

Single phase, one voltage, one speed only

• A single phase 2-pole + earth wall socket rated at 16 A will

be required.

Three-phase, one tension, two speeds

• A standard 3-phase + Earth wall socket rated at 20A will be

required and an appropriate sealed plug to be ﬁtted onto the

power lead.

• Check the direction of rotor rotation at both speeds:

- Press the On button (see § 3.1).

- Make a visual check through the lid that the rotor turns in an

anti-clockwise direction ( ) at both speeds (see arrow etched

on the rotor handle).

- If the direction of rotation is reversed, change over the 2 phase

wires on the power socket.

Single phase, one voltage, variable speed

• The food processor is powered by single phase current up to

the variable speed unit which transforms the current to power

the three-phase motor.

• An easily accessible, standard 2-pole + earth sealed wall

socket rated at 16 A will be required.

2.3

Must be earthed by green/yellow wire.

Damage caused by a lack of earth will not be covered by

the warranty

Must be earthed by green/yellow wire.

In certain cases, depending on the sensitivity of the

protective RCD, SI-type (Super Immunity) devices may

need to be ﬁtted to prevent unwanted tripping.

2.3 ELECTRICAL CONNECTION

ATTENTION!!

Connection to the electrical power supply must be done according to proper professional practice by a qualiﬁed and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than

those of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions;

- Maximum voltage variation: ±5%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Check that the electric mains voltage, the value shown on the speciﬁcation plate.

- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) by using

fuses or thermal relays of the appropriate gauge relative to the place of installation and machine speciﬁcations.

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC

60204-1) with the use of protection devices for automatic shut-off of power in the event of an insulation fault with a TN or

TT, system, or for the IT system, with the use of a permanent insulation or differentials controller for automatic shut-off.

The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TT system, a differential circuit breaker must be installed upline of the power supply, with a suitable power

cut-off (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-

dents due to direct or indirect contacts.

K45-55-70 GB 09 2021

To PAT test the Electrolux Range of Food Preparation Equipment,

the PCB board needs to be disconnected before any test is done.

This is due to the fact that the boards are ﬁtted with a grounding

diode that can give incorrect result during such a test. Also on a

standard appliance a ﬂash test of 25 amps and up to 3000v is

used but, as you would expect, to use this on equipment, which

has a printed circuit, board would be quite destructive to that

board. We would recommend the use of a PAT tester approved

for computer systems which use a lower rate of amps.

The appliance is perfectly safe and is CE certiﬁcated. There are

two ways to get overcome this problem.

· Disconnect the board as instructed and test using test for

PC’s,

· Or install the mixer on a fused spur (no plug) as this takes it

away from being a portable appliance and the PAT test is then

not needed.
